BRAKE SHOE » FN0609

Specification

Radius
101.6
Width
30
Thickness
3 / 6.7
Pcs In Set
4

Cross Reference

FMSI
S1021-1616
HYUNDAI
58305-0UA00
HYUNDAI
58305-0XA10
HYUNDAI
58305-1CA10
HYUNDAI
58305-3XA00
HYUNDAI
58305-B4A70
HYUNDAI
58305-C7A00
HYUNDAI
58350-0PA00
HYUNDAI
58350-3XA00
HYUNDAI
58350-F2A00
HYUNDAI
58350-H5A20
HYUNDAI
58350-H6A00
HYUNDAI / KIA
58350-CCA00
HYUNDAI / KIA
58350-F3A00
HYUNDAI / KIA
58350-H8A00
HYUNDAI / KIA
58350-K3A00
HYUNDAI / KIA
58350-K6A00
HYUNDAI / KIA
58350T7A80
KASHIYAMA
K11182
KASHIYAMA
K11224
KIA
58305-0UA00
KIA
58305-3XA00
KIA
58350-H9A00
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.20~ 1400 G4LC PH620 LHD RN1956V PN0537 DN1509 FN0609
03.06~08.11 1500 D4FA MC RN1370V PN0435 RN1778DN1447 FN0609PN0436
10.10~10.14 1400 G4FA PSB11 SDN LHD RN11002V PN0537 DN1456RN11003 PN0538FN0609
11.11~09.14 1400 G4FA SB HB RN11002V PN0537 DN1456 FN0609
09.11~05.14 1600 G4FC PSB11 HB LHD PR RN11002V PN0537 DN1456RN11003 PN0538FN0609
09.11~05.14 1600 G4FC PSB11 SDN RN11002V PN0537 DN1456RN11003 FN0609PN0538
09.11~05.14 1600 G4FD SB RN11002V PN0537 DN1456 FN0609
01.14~01.19 1400 G4LC CT41 RHD RN11002V PN0537 RN11003DN1456 FN0609PN0538
01.14~01.20 1400 G4LC CT41 SDN LHD RN11002V PN0537 RN11003DN1456 PN0538FN0609
09.14~02.20 1600 D4FB PSB15 LHD RN11002V PN0537 DN1456RN11003 FN0609PN0538
05.14~11.17 1600 G4FC PSB15 SDN RN11002V PN0537 DN1456RN11003 PN0538FN0609
01.18~ 1400 G4LC PH618 LHD RN1956V PN0537 FN0609
01.18~ 1400 G4LC PH618 LHD VTN RN11002VRN1956V PN0537 DN1509RN11003 FN0609PN0538
01.18~ 1400 G4LC PH618 RHD RN1956V PN0537 DN1509RN11003 PN0538FN0609
01.18~ 1600 D4FB PH618 LHD RN1956V PN0537 DN1509 FN0609
01.18~ 1600 G4FD PJ018 RN2072V PN0603 DN1509 FN0609
01.10~12.13 1600 G4FG PSD11 LHD RN1548V PN0537 RN1549DN1106 FN0609PN0538
01.10~01.15 1600 G4FG PSD11 RHD RN1548V PN0537 DN1106RN1549 FN0609PN0538
09.11~07.13 1800 G4NB PSD11 LHD RN1548V PN0537 RN1549DN1106 PN0538FN0609
09.15~07.19 1600 D4FB RPF216 RN1548V PN0772 DN1106RN1549 PN0538FN0609
09.15~07.19 1600 G4FG PF216 RHD RN1548V PN0772 DN1106RN1549 FN0609PN0538
09.15~07.19 1600 L4FA PF216 RN1548V PN0772 RN1549DN1106 PN0538FN0609
02.16~02.19 2000 G4NH PF316 US PN0772 DN1106 FN0609
08.18~08.20 1600 G4FG AD RN1548V PN0772 RN1549 FN0609PN0538
08.18~08.20 2000 G4NA PF219 RHD RN1548V PN0772 RN1549 PN0538FN0609
08.18~08.20 2000 G4NH AD RN1548V PN0772 RN1549 PN0538FN0609
01.06~09.11 1400 G4EE PN2435 PN0539FN0609
09.15~ 1600 G4FG AD LHD PR RN1548V PN0772 DN1106RN1549 FN0609PN0538
01.16~02.19 2000 G4NH PF316 US PN0772 DN1106 FN0609
09.02~10.05 1500 D3EA PA02 RN1199V PN0091 DN1508 FN0609
10.05~09.11 1500 D4FA BT51 5DR RN1199V PN0091 DN1508RN1778 PN0539FN0609 FN0661
09.02~10.06 1600 G4ED BU31 3DR RHD RN1199V PN0091 DN1508 FN0609
10.06~09.11 1600 G4ED BU31 3DR RHD RN1199V PN0091 DN1508 FN0609
09.02~10.05 1600 G4ED BU51 RN1199V PN0091 DN1508 FN0609
10.07~01.16 1000 G3LA PA PN0438 FN0609PN0526
01.17~01.20 1000 G3LA PB417 RHD GRAND RN2405V PN0858 DN1447 FN0609
01.14~ 1000 G3LA VTN RN2405V PN0858 PN0538FN0609
08.19~ 1000 G3LD PGQ20 EU LHD RN2405V PN0858 DN1447 FN0609PN0538
08.19~ 1200 PHQ20 FN0609
09.13~01.17 1200 G4LA B9 RN2405V PN0858 DN1447 FN0609
10.07~09.10 1200 G4LA PA07 RN11001V PN0448PN0438 RN1791DN1447 FN11186PN0526FN0609
09.10~09.13 1200 G4LA PA07 RN11001V PN0448 RN1791DN1447 PN0526FN11186FN0609
09.13~01.17 1200 G4LA PB414 LHD GRAND HB RN2405V PN0858 DN1447 FN0609
09.13~01.17 1200 G4LA PB414 LHD GRAND SDN RN2405V PN0858 DN1447 FN0609
09.13~01.17 1200 G4LA PB414 RHD HB RN2405V PN0858 DN1447 FN0609
01.17~10.20 1200 G4LA PB417 RHD GRAND HB RN2405V PN0858 DN1447 FN0609
01.17~10.20 1200 G4LA PB417 RHD GRAND SDN RN2405V PN0858 DN1447 FN0609
08.19~ 1200 G4LA PHQ20 LHD GRAND RN2405V PN0858 DN1447 FN0609
08.19~ 1200 G4LF PGQ20 PN0858 FN0609PN0538
01.16~06.18 1000 G3LC HB EU RN1956VRN2072V PN0537 DN1456RN11003 FN0609PN0538
06.18~03.20 1000 G3LC PC818 5DR HB EL RN1956VRN2072V PN0537 RN11003DN1456 PN0538FN0609
03.20~ 1000 G3LC PSV20 HB RHD FN0609
11.14~06.18 1100 D3FA HB EU RN2072VRN1956V PN0537 DN1456RN11003 PN0538FN0609
03.12~12.15 1200 G4LA BA51 5DR RHD PN0448 DN1447 FN0609
12.14~06.18 1200 G4LA BL51 5DR RHD RN11002V PN0537 DN1456 FN0609
11.14~06.18 1200 G4LA HB EU RN1956VRN2072V PN0537 RN11003DN1456 PN0538FN0609
10.08~12.12 1200 G4LA PB08 5DR RHD PN0448 DN1447 FN0609 FN0661
10.08~06.12 1200 G4LA PBT10 LHD PN0448 DN1447 FN0609
06.12~12.14 1200 G4LA PBT12 LHD PN0448 DN1447 FN0609 FN0661
11.14~06.18 1200 G4LA PC715 RHD RN11002VRN2072V PN0537 RN11003DN1456 FN0609PN0538
11.14~06.18 1400 D4FC HB EU RN2072VRN1956V PN0537 DN1456RN11003 FN0609PN0538
11.14~06.18 1400 D4FC PC715 RHD RN11002V PN0537 DN1456 FN0609
06.18~03.20 1400 G4LC GB RN1956VRN2072V PN0537 DN1456RN11003 FN0609PN0538
11.14~06.18 1400 G4LC HB EU RN2072VRN1956V PN0537 DN1456RN11003 PN0538FN0609
11.14~06.18 1400 G4LC PC715 RHD RN11002V PN0537 DN1456RN11003 PN0538FN0609
06.18~08.20 1400 G4LC PC718 RHD RN11002V PN0603PN0537 DN1456 FN0609
10.18~12.21 1400 G4LC CB RN11002V PN0537 RN11003DN1509 FN0609PN0538
02.20~ 1400 G4LC H520 RN1956V PN0537 RN11003DN1509 FN0609PN0538
02.20~ 1600 G4FG H520 RN1956V PN0537 DN1509RN11003 FN0609PN0538
03.11~05.14 1400 G4FA SBR11 RUS RN11002V PN0537 RN11003DN1509 FN0609PN0538
05.14~12.16 1400 G4FA SBR14  RUS RN11002V PN0537 DN1509 FN0609
05.14~12.16 1600 G4FC SBR14  RUS RN11002V PN0537 RN11003DN1509 FN0609
01.17~08.20 1400 G4LC H517 RN1956V PN0537 DN1509RN11003 PN0538FN0609
01.17~08.20 1600 G4FG H517 RN1956V PN0537 DN1509RN11003 PN0538FN0609
10.18~06.22 1000 G3LC PSP19 RHD PN0958 FN0609
06.22~ 1000 G3LC PSP22 RHD PN0958 FN0609
01.18~ 1400 G4LC PH618 LHD PR RN1956V PN0537 FN0609
01.20~ 1400 G4LC PH820 HB RHD RN1956V PN0537 DN1509 FN0609
03.11~05.15 1200 G4LA DN511 5DR HB RHD RN11002V PN0537 DN1456 FN0609
03.11~05.15 1200 G4LA PIH12 4DR SDN RHD RN11002V PN0537 DN1456 FN0609
09.11~ 1400 D4FC UB RN11002V PN0537 RN11003 FN0609PN0538
01.11~01.14 1400 G4FA PIH12 3DR HB RN11002V PN0537 DN1456RN11003 PN0538FN0609
03.11~05.15 1400 G4FA PIH12 4DR SDN LHD RN11002V PN0537 DN1456 FN0609
03.11~05.15 1400 G4FA PIH12 4DR SDN RHD RN11002V PN0537 DN1456 PN0538FN0609
03.11~05.15 1400 G4FA PIH12 5DR HB LHD RN11002V PN0537 RN11003DN1456 FN0609PN0538
03.11~05.15 1400 G4FA PIH12 5DR HB RHD RN11002V PN0537 DN1456RN11003 FN0609PN0538
01.15~04.17 1200 G4LA DN511 5DR HB RHD RN11002V PN0537 DN1456 FN0609
07.15~03.17 1200 G4LA PIH15 5DR HB LHD RN11002V PN0537 DN1456 FN0609
07.15~03.17 1200 G4LA PIH15 SDN LHD RN11002V PN0537 DN1456 FN0609
01.15~06.17 1400 G4FA DXR15 RUS RN11002V PN0537 DN1509 FN0609
11.14~06.17 1400 G4FA PIH15 5DR HB RN11002V PN0537 DN1456RN11003 PN0538FN0609
01.15~06.17 1400 G4FA PIH15 SDN RN11002V PN0537 DN1456 FN0609
11.16~01.20 1200 G4LA PH817 HB RHD RN1956V PN0537 DN1509 FN0609
11.16~08.20 1400 G4LC PH817 HB RHD RN1956V PN0537 DN1509RN11003 PN0538FN0609
01.17~ 1400 G4LC PH917 HB LHD RN1956V PN0537 DN1509 FN0609
01.17~ 1400 G4LC PH917 SDN LHD RN1956V PN0537 DN1509 FN0609
01.17~ 1600 G4FG PH917 HB LHD RN1956V PN0537 DN1509 FN0609
01.17~ 1600 G4FG PH917 SDN LHD RN1956V PN0537 DN1509 FN0609
06.17~10.20 1400 G4LC H018 HB RU RN1956V PN0537 DN1509 FN0609
06.17~ 1400 G4LC SDN LHD RN1956V PN0537 DN1509 FN0609
06.17~10.20 1600 G4FG PH018 RN1956V PN0537 DN1509 FN0609
10.20~ 1600 G4FG PH021 RN1956V PN0537 DN1509 FN0609
01.18~ 1400 G4LC PH718 LHD RN11002V PN0537 RN11003DN1509 PN0538FN0609
01.18~ 1400 G4LC PH718 RHD RN11002V PN0537 DN1509 FN0609
08.20~ 1000 G3LC PSX21 RN1548V PN0958 FN0609
08.20~ 1500 G4FL PSX21 LHD RN1548V PN0958 FN0609
08.20~ 1500 G4FL PSX21 RHD RN1548V PN0958 FN0609

Exemption from liability: the catalog data is advisory and can be used for reference only
