NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1779V

ROTOR DISC » RN1779V

Specification

Type

Vented

Outter Ø

241

Num. of holes

4

Disc Thickness (Max)

19

Height

47.8

Centering Diameter

62.2

Pitch Circle Ø

100

Front/Rear

Front

Disc Thickness (Min)

17

Drum Ø:

126

Structure Material

G3000

Cross Reference

HYUNDAI

51712-1C000

HYUNDAI

51712-1C300

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

HYUNDAI » Getz

06.06~09.11	1100	G4HG	5DR HB VTN	RN1199V RN1779V	PN0091	DN1508 DN1507	FN0609 FN0610
07.02~12.06	1100	G4HG	BT51 5DR RHD	RN1199V RN1779V	PN0091	DN1507	FN0610
11.06~09.11	1100	G4HG	BT51 5DR RHD	RN1199V RN1779V	PN0091	DN1507	FN0610
07.02~10.06	1300	G4EA	BT51 5DR LHD	RN1779V	PN0091	DN1507	FN0610
07.02~10.06	1300	G4EA	BU51 5DR RHD	RN1779V	PN0091	DN1507	FN0610
10.05~09.11	1400	G4EE	BT51 5DR LHD	RN1779V	PN0091	DN1507	FN0610
10.05~09.11	1400	G4EE	BT51 5DR RHD	RN1779V	PN0091	DN1507	FN0610
09.02~10.06	1400	G4EE	BU31 3DR RHD	RN1779V	PN0091	DN1507	FN0610
09.02~10.06	1400	G4EE	BU51 5DR RHD	RN1779V	PN0091	DN1507	FN0610
10.06~09.11	1400	G4EE	BU51 5DR RHD	RN1779V	PN0091	DN1507	FN0610
