NiBK Brakes:: Application Cross Reference and Image for NiBK : DRUM BRAKE : DN1507

DRUM BRAKE » DN1507

Specification

Outter Ø

219.7

Num. of holes

4

Centering Diameter

62.5

Height

57.7

Pitch Circle Ø

100

Drum Ø

180

Structure Material

G3000

Hole Ø

12.5

Cross Reference

HYUNDAI

58411-1C000

HYUNDAI / KIA

58411-1C010

HYUNDAI / KIA

584111C010-DS

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

HYUNDAI » Getz

06.06~09.11	1100	G4HG	5DR HB VTN	RN1199V RN1779V	PN0091	DN1507 DN1508	FN0610 FN0609
07.02~12.06	1100	G4HG	BT51 5DR RHD	RN1199V RN1779V	PN0091	DN1507	FN0610
11.06~09.11	1100	G4HG	BT51 5DR RHD	RN1779V RN1199V	PN0091	DN1507	FN0610
07.02~10.06	1300	G4EA	BT51 5DR LHD	RN1779V	PN0091	DN1507	FN0610
07.02~10.06	1300	G4EA	BU51 5DR RHD	RN1779V	PN0091	DN1507	FN0610
10.05~09.11	1400	G4EE	BT51 5DR LHD	RN1779V	PN0091	DN1507	FN0610
10.05~09.11	1400	G4EE	BT51 5DR RHD	RN1779V	PN0091	DN1507	FN0610
09.02~10.06	1400	G4EE	BU31 3DR RHD	RN1779V	PN0091	DN1507	FN0610
09.02~10.06	1400	G4EE	BU51 5DR RHD	RN1779V	PN0091	DN1507	FN0610
10.06~09.11	1400	G4EE	BU51 5DR RHD	RN1779V	PN0091	DN1507	FN0610
