NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2606V

ROTOR DISC » RN2606V

Specification

Type

Vented

Outter Ø

256

Num. of holes

4

Hole Ø:

12.7

Disc Thickness (Max)

18

Disc Thickness (Min)

16

Height

46.8

Centering Diameter

62.2

Pitch Circle Ø

100

Drum Ø:

126

Front/Rear

Front

Structure Material

G3000

Cross Reference

HYUNDAI

51712-1J500

HYUNDAI / KIA

517121J500

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

HYUNDAI » i20

03.12~12.15	1200	G4LA	BA51 5DR RHD	RN2606V	PN0448	DN1447	FN0609
10.08~12.12	1200	G4LA	PB08 5DR RHD	RN2606V	PN0448	DN1447	FN0609	FN0661
10.08~06.12	1200	G4LA	PBT10 LHD	RN2606V	PN0448	DN1447	FN0609
01.10~06.12	1200	G4LA	PBT10 LHD	RN2606V	PN0448	DN1447	FN0609
06.12~12.14	1200	G4LA	PBT12 LHD	RN2606V	PN0448	DN1447	FN0609	FN0661
06.12~12.14	1200	G4LA	PPB12 LHD	RN2606V	PN0448	DN1447	FN0609
