BRAKE SHOE » FN0686
Specification
Radius
147.5
Width
50
Thickness
6 / 8.5
Pcs In Set
4
Variation
Cross Reference
FMSI
S764-1397
KASHIYAMA
K2441
TOYOTA
04495-0K160
TOYOTA
04495-35220
TOYOTA
04495-35250
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 05.15~ | 2400 | 2GD-FTV | GUN135L | RN1664VRN1446V | PN1482 | DN1102 | FN0620FN0686 | |
| 05.15~ | 2400 | 2GD-FTV | GUN135R | RN1664VRN1446V | PN1482 | DN1102 | FN0620FN0686 | |
| 05.15~ | 2500 | 2KD-FTV | KUN135R | RN1664V | PN1482 | DN1102 | FN0686 | |
| 05.15~07.17 | 3000 | 1KD-FTV | KUN126L | RN1664VRN1446V | PN1482 | DN1102 | FN0686FN0620 | |
| 05.15~01.18 | 3000 | 1KD-FTV | KUN126R | RN1664V | PN1482 | DN1102 | FN0686 | |
| 07.05~12.15 | 3000 | 5L-E | LAN125L | RN1319V | PN0548 | DN1102 | FN0686 | |
| 01.16~ | 4000 | 1GRFE | GGN135R | RN1664V | PN1482 | DN1102 | FN0686 |
| 01.94~01.04 | 2700 | 3RZ-FE | RZN171 | RN1830V | PN1219PN1830 | DN1214 | FN2305FN0686 | |
| 08.98~09.04 | 2700 | 3RZ-FE | RZN191 | RN1830V | PN1830 | DN1214 | FN2305FN0686 | |
| 02.98~09.04 | 2700 | 3RZ-FE | RZN196 | RN1830V | PN1830PN1219 | DN1214 | FN0686FN2305 | |
| 01.95~09.04 | 3400 | 5VZ-FE | VZN170 | RN1128VRN1830V | PN1387PN1219PN1830 | DN1214 | FN0686FN2305 | |
| 02.98~09.04 | 3400 | 5VZ-FE | VZN195L | RN1830V | PN1830PN1219PN1387 | DN1214 | FN0686FN2305 |
| 02.99~08.04 | 3400 | 5VZ-FE | VCK30 | RN2354V | PN1482PN1411 | DN1253DN1213DN1214 | FN2305FN0686 | |
| 02.99~08.04 | 3400 | 5VZ-FE | VCK40L | RN2354V | PN1411PN1482 | DN1213DN1214DN1253 | FN2305FN0686 | |
| 08.04~08.06 | 4000 | 1GR-FE | GSK30L | RN2354V | PN1482 | DN1213 | FN0686 | |
| 02.99~12.06 | 4700 | 2UZ-FE | UCK30L | RN2354V | PN1411PN1482 | DN1214DN1253DN1213 | FN0686FN2305 | |
| 10.03~12.06 | 4700 | 2UZ-FE | UCK31L | RN2354V | PN1482 | DN1213 | FN0686 | |
| 02.99~12.06 | 4700 | 2UZ-FE | UCK40 | RN2354V | PN1482PN1411 | DN1214DN1253DN1213 | FN0686FN2305 | |
| 08.02~12.06 | 4700 | 2UZ-FE | UCK41L | RN2354V | PN1482 | DN1213 | FN0686 |
