DRUM BRAKE » DN1253
Specification
Outter Ø
343
Num. of holes
6
Hole Ø
14.4
Centering Diameter
106
Height
83.1
Pitch Circle Ø
139.7
Drum Ø
295
Structure Material
G3000
Cross Reference
TOYOTA
42431-26150
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.89~08.04 | 3000 | 1KZ-TE | KZH138V | RN1304V | PN1237 | DN1253DN1214 | FN2305 | |
| 04.95~08.04 | 3000 | 5L-E | LH178V | RN1304V | PN1237 | DN1253 | FN2305 |
| 08.89~08.99 | 2800 | 3L | LH109V | RN1304V | PN1237 | DN1214DN1253 | FN2305 | |
| 08.93~08.04 | 3000 | 1KZ-TE | KZH116G | RN1304V | PN1237 | DN1253DN1214 | FN2305 | |
| 08.93~08.99 | 3000 | 1KZ-TE | KZH126G | RN1304V | PN1237 | DN1214DN1253 | FN2305 | |
| 04.95~01.05 | 3000 | 5L-E | LH168V | RN1304V | PN1237 | DN1253 | FN2305 |
| 02.99~08.02 | 3400 | 5VZ-FE | VCK30 | RN2354V | PN1482PN1411 | DN1213DN1214DN1253 | FN0686FN2305 | |
| 02.99~08.02 | 3400 | 5VZ-FE | VCK40L | RN2354V | PN1482PN1411 | DN1213DN1214DN1253 | FN0686FN2305 | |
| 02.99~07.02 | 4700 | 2UZ-FE | UCK30L | RN2354V | PN1482PN1411 | DN1213DN1214DN1253 | FN2305FN0686 | |
| 02.99~07.02 | 4700 | 2UZ-FE | UCK40 | RN2354V | PN1482PN1411 | DN1213DN1214DN1253 | FN0686FN2305 |
