DRUM BRAKE » DN1102
Specification
Outter Ø
344.6
Centering Diameter
108
Height
76.6
Pitch Circle Ø
139.7
Drum Ø
295
Structure Material
G3000
Num. of holes
6
Cross Reference
TOYOTA
42431-0K120
TOYOTA
42431-0K130
TOYOTA
42431-0K180
TOYOTA
42431-0K250
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 07.15~08.17 | 2400 | 2GD-FTV | GUN165L | RN1945V | PN1872 | RN1216VDN1102 | PN1846FN0620 | FN0642 |
| 03.16~ | 2400 | 2GD-FTV | GUN166R | RN1319V | PN1872 | RN1553VDN1102 | FN0620PN1846PN1243 | FN0642 |
| 01.05~04.16 | 2500 | 2KD-FTV | KUN60L | RN1664VRN1319V | PN1830PN0548PN1482 | DN1102 | FN0620 | |
| 01.05~04.16 | 2500 | 2KD-FTV | KUN60R | RN1319V | PN1482PN0548PN1830 | DN1102 | FN0620 | |
| 01.16~ | 2700 | 2TR-FE | TGN156L | RN1945V | PN1872 | RN1216VRN1553VDN1102 | PN1243PN1846FN0620 | FN0642 |
| 01.16~ | 2700 | 2TR-FE | TGN166L | RN1945V | PN1872 | DN1102RN1553VRN1216V | FN0620PN1243PN1846 | FN0642 |
| 01.05~04.12 | 2700 | 2TR-FE | TGN51L | RN1664V | PN1482PN1830 | DN1102 | FN0620 | |
| 01.06~11.16 | 2700 | 2TR-FE | TGN61L | RN1664V | PN1482 | DN1102 | FN0620 | |
| 09.05~12.15 | 3000 | 1KD-FTV | KUN61 | RN1664V | PN1482 | DN1102 | FN0620 |
| 05.17~ | 2400 | 2GD-FTV | GUN125 | RN1664V | PN1482 | DN1102 | FN0620 | |
| 05.15~ | 2400 | 2GD-FTV | GUN125L | RN1664V | PN1482PN0548 | DN1102 | FN0620 | |
| 05.15~ | 2400 | 2GD-FTV | GUN125R | RN1319VRN1664V | PN1482PN0548 | DN1102 | FN0620 | |
| 05.15~ | 2400 | 2GD-FTV | GUN135L | RN1446VRN1664V | PN1482 | DN1102 | FN0620FN0686 | |
| 05.15~ | 2400 | 2GD-FTV | GUN135R | RN1664VRN1446V | PN1482 | DN1102 | FN0686FN0620 | |
| 05.15~07.17 | 2500 | 2KD-FTV | KUN125R | RN1664VRN1319V | PN1482PN0548 | DN1102 | FN0620 | |
| 05.15~ | 2500 | 2KD-FTV | KUN135L | RN1664V | PN1482 | DN1102 | FN0620 | |
| 05.15~ | 2500 | 2KD-FTV | KUN135R | RN1664V | PN1482 | DN1102 | FN0686 | |
| 02.05~12.15 | 2500 | 2KD-FTV | KUN25L | RN1319V | PN0548PN1482PN1830 | DN1102 | FN0620 | |
| 03.05~01.16 | 2500 | 2KD-FTV | KUN25R | RN1664VRN1319V | PN1830PN0548PN1482 | DN1102 | FN0620 | |
| 07.11~ | 2500 | 2KD-FTV | KUN35R | RN1319V | PN0548 | DN1102 | FN0620 | |
| 11.15~ | 2700 | 2TR-FE | TGN126L | RN1664VRN1319VRN1446V | PN1482PN0548 | DN1102 | FN0620 | |
| 01.21~ | 2700 | 2TR-FE | TGN127L | RN1664VRN1319VRN1446V | PN1482PN0548 | DN1102 | FN0620 | |
| 07.16~ | 2700 | 2TR-FE | TGN128L | RN1664VRN1446VRN1319V | PN1482PN0548 | DN1102 | FN0620 | |
| 05.15~ | 2700 | 2TR-FE | TGN136L | RN1446V | PN1482 | DN1102 | FN0620 | |
| 07.16~ | 2700 | 2TR-FE | TGN138L | RN1664V | PN1482 | DN1102 | FN0620 | |
| 08.04~12.08 | 2700 | 2TR-FE | TGN26L | RN1319V | PN1830 | DN1102 | FN0620 | |
| 01.04~01.18 | 2700 | 2TR-FE | TGN36R | RN1664VRN1319V | PN1482PN0548 | DN1102 | FN2305FN0620 | |
| 05.15~ | 2800 | 1GD-FTV | GUN126L | RN1664V | PN1482 | DN1102 | FN0620 | |
| 05.15~ | 2800 | 1GD-FTV | GUN126R | RN1664V | PN1482 | DN1102 | FN0620 | |
| 05.15~ | 2800 | 1GD-FTV | GUN136R | RN1664V | PN1482 | DN1102 | FN0620 | |
| 05.15~07.17 | 3000 | 1KD-FTV | KUN126L | RN1446VRN1664V | PN1482 | DN1102 | FN0686FN0620 | |
| 05.15~01.18 | 3000 | 1KD-FTV | KUN126R | RN1664V | PN1482 | DN1102 | FN0686 | |
| 07.11~04.15 | 3000 | 1KD-FTV | KUN26L | RN1664V | PN1482 | DN1102 | FN0620 | |
| 08.04~04.15 | 3000 | 1KD-FTV | KUN26R | RN1664VRN1319V | PN0548PN1482PN1830 | DN1102 | FN0620 | |
| 01.04~10.11 | 3000 | 1KD-FTV | KUN36L | RN1319V | PN1830PN1482 | DN1102 | FN0620 | |
| 05.04~12.15 | 3000 | 1KD-FTV | KUN36R | RN1319VRN1664V | PN1830PN0548 | DN1102 | FN0620 | |
| 07.05~12.15 | 3000 | 5L-E | LAN125L | RN1319V | PN0548 | DN1102 | FN0686 | |
| 04.01~10.13 | 3000 | 5L-E | LAN25R | RN1319V | PN0828PN0548PN1830 | DN1102 | FN0620 | |
| 05.05~10.13 | 3000 | 5L-E | LAN35R | RN1319V | PN0548PN1830 | DN1102 | FN0620FN2305 | |
| 08.17~ | 4000 | 1GRFE | GGN125L | RN1664V | PN1482 | DN1102 | FN0620 | |
| 05.15~ | 4000 | 1GRFE | GGN125R | RN1664V | PN1482 | DN1102 | FN0620 | |
| 01.16~ | 4000 | 1GRFE | GGN135R | RN1664V | PN1482 | DN1102 | FN0686 |
