ROTOR DISC » RN1945V
Specification
Type
Vented
Outter Ø
338
Num. of holes
6
Disc Thickness (Max)
28
Height
67.2
Centering Diameter
108
Pitch Circle Ø
139.7
Front/Rear
Front
Hole Ø:
14,5
Drum Ø:
171
Structure Material
G3000
Cross Reference
TOYOTA
43512-0K210
TOYOTA
43512-OK210
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.22~ | 2400 | 2GD-FTV | GUN155L | RN1945VRN1319V | PN1872 | RN1553VRN1216V | PN1846PN1243 | FN0642 |
| 01.16~ | 2400 | 2GD-FTV | GUN155R | RN1319VRN1945V | PN1872 | RN1553VRN1216V | PN1243PN1846 | FN0642 |
| 07.15~ | 2400 | 2GD-FTV | GUN165L | RN1945V | PN1872 | DN1102RN1216V | PN1846FN0620 | FN0642 |
| 07.20~ | 2400 | 2GD-FTV | GUN166L | RN1945V | PN1872 | RN1216V | PN1846 | FN0642 |
| 01.16~ | 2700 | 2TR-FE | TGN156L | RN1945V | PN1872 | DN1102RN1216VRN1553V | PN1846FN0620PN1243 | FN0642 |
| 05.16~ | 2700 | 2TR-FE | TGN156R | RN1945V | PN1872 | RN1553V | PN1846FN0620PN1243 | FN0642 |
| 01.16~ | 2700 | 2TR-FE | TGN166L | RN1945V | PN1872 | DN1102RN1553VRN1216V | PN1846FN0620PN1243 | FN0642 |
| 01.16~ | 2700 | 2TR-FE | TGN166R | RN1945V | PN1872 | RN1553V | FN0620PN1846PN1243 | FN0642 |
| 07.15~ | 2800 | 1GD-FTV | GUN156L | RN1945V | PN1872 | RN1216V | PN1846PN1243 | FN0642 |
| 07.15~ | 2800 | 1GD-FTV | GUN156R | RN1945V | PN1872 | RN1553V | PN1243PN1846 | FN0642 |
| 12.15~ | 4000 | 1GR-FE | GGN155L | RN1945V | PN1482PN1872 | RN1216V | PN1846FN0620 | FN0642 |
