ROTOR DISC » RN1446V
Specification
Type
Vented
Disc Thickness (Max)
28
Num. of holes
6
Height
67.2
Centering Diameter
108
Front/Rear
Front
Pitch Circle Ø
139.7
Outter Ø
319
Drum Ø:
172
Disc Thickness (Min)
26
Structure Material
G3000
Cross Reference
TOYOTA
43512-04050
TOYOTA
43512-04051
TOYOTA
43512-04052
TOYOTA
43512-0K230
TOYOTA
43512-0K330
TOYOTA
43512-35320
TOYOTA
43512-35321
TOYOTA
43512-35322
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.01~12.04 | 3000 | 1KZ-TE | KZN205L | RN1446V | PN1482 | RN1216V | PN1243 | FN0642 |
| 11.02~09.05 | 3000 | 1KZ-TE | KZN215L | RN1446V | PN1482 | RN1216V | PN1243 | FN0642 |
| 11.02~08.09 | 4000 | 1GR-FE | GRN210 | RN1446VRN1220V | PN1482 | RN1216V | PN1243 | FN0642 |
| 11.02~08.09 | 4000 | 1GR-FE | GRN215L | RN1220VRN1446V | PN1482 | RN1216V | PN1243 | FN0642 |
| 08.02~08.09 | 4700 | 2UZ-FE | UZN210 | RN1446VRN1220V | PN1482 | RN1216V | PN1243 | FN0642 |
| 01.06~07.14 | 4000 | 1GR-FE | GSJ10L | RN1446V | PN1482 | RN1553VRN1216V | PN1243 | FN0642 |
| 07.07~12.22 | 4000 | 1GR-FE | GSJ15L | RN1446V | PN1482 | RN1216V | PN1243 | FN0642 |
| 11.10~01.18 | 4000 | 1GR-FE | GSJ15W | RN1446V | PN1482 | RN1553V | PN1243 | FN0642 |
| 05.15~ | 2400 | 2GD-FTV | GUN135L | RN1664VRN1446V | PN1482 | DN1102 | FN0686FN0620 | |
| 05.15~ | 2400 | 2GD-FTV | GUN135R | RN1664VRN1446V | PN1482 | DN1102 | FN0620FN0686 | |
| 11.15~ | 2700 | 2TR-FE | TGN126L | RN1664VRN1319VRN1446V | PN1482PN0548 | DN1102 | FN0620 | |
| 01.21~ | 2700 | 2TR-FE | TGN127L | RN1664VRN1319VRN1446V | PN0548PN1482 | DN1102 | FN0620 | |
| 07.16~ | 2700 | 2TR-FE | TGN128L | RN1664VRN1319VRN1446V | PN0548PN1482 | DN1102 | FN0620 | |
| 05.15~ | 2700 | 2TR-FE | TGN136L | RN1446V | PN1482 | DN1102 | FN0620 | |
| 05.15~07.17 | 3000 | 1KD-FTV | KUN126L | RN1446VRN1664V | PN1482 | DN1102 | FN0686FN0620 |
| 08.04~07.09 | 2700 | 2TR-FE | TRN210W | RN1446V | PN1482 | RN1216V | PN1243 | FN0642 |
| 08.04~08.09 | 2700 | 2TR-FE | TRN215W | RN1446V | PN1482 | RN1216V | PN1243 | FN0642 |
| 10.02~08.04 | 2700 | 3RZ-FE | RZN210W | RN1446V | PN1482 | RN1216V | PN1243 | FN0642 |
| 11.02~08.04 | 2700 | 3RZ-FE | RZN215W | RN1446V | PN1482 | RN1216V | PN1243 | FN0642 |
| 11.02~08.05 | 3000 | 1KD-FTV | KDN215W | RN1446V | PN1482 | RN1216V | PN1243 | |
| 11.02~08.05 | 3400 | 5VZ-FE | VZN210W | RN1446V | PN1482 | RN1216V | PN1243 | FN0642 |
| 11.02~08.05 | 3400 | 5VZ-FE | VZN215W | RN1446V | PN1482 | RN1216V | PN1243 | |
| 08.05~08.09 | 4000 | 1GR-FE | GRN215W | RN1446V | PN1482 | RN1216V | PN1243 | FN0642 |
| 09.04~08.14 | 2700 | 2TR-FE | TRN240 | RN1446V | PN1482 | DN1236 | FN2378 | |
| 09.04~ | 2700 | 2TR-FE | TRN245 | RN1446V | PN1482 | DN1236 | FN2378 | |
| 09.04~06.10 | 2700 | 2TR-FE | TRN260L | RN1446V | PN1482 | DN1236 | FN2378 | |
| 09.04~09.19 | 2700 | 2TR-FE | TRN265L | RN1446V | PN1482 | FN2378 | ||
| 08.15~ | 3500 | 2GR-FKS | GRN305L | RN1446V | PN1482 | DN1236 | FN2378 | |
| 08.15~ | 3500 | 2GR-FKS | GRN310L | RN1446V | PN1482 | DN1236 | FN2378 | |
| 08.15~ | 3500 | 2GR-FKS | GRN325L | RN1446V | PN1482 | DN1236 | FN2378 | |
| 01.04~10.11 | 4000 | 1GR-FE | GRN245 | RN1446V | PN1482 | FN2378 | ||
| 10.11~08.15 | 4000 | 1GR-FE | GRN245L | RN1446V | PN1482 | DN1236 | FN2378 | |
| 09.04~05.08 | 4000 | 1GR-FE | GRN250L | RN1446V | PN1482 | FN2378 | ||
| 01.06~01.08 | 4000 | 1GR-FE | GRN265L | RN1446V | PN1482 | FN2378 |
