ROTOR DISC » RN1348V
Specification
Type
Vented
Disc Thickness (Max)
28
Num. of holes
5
Height
47.8
Centering Diameter
69
Front/Rear
Front
Pitch Circle Ø
114.3
Outter Ø
300
Drum Ø:
143
Disc Thickness (Min)
25
Structure Material
G3000
Cross Reference
HYUNDAI
51712-0Z000
HYUNDAI
51712-1M500
HYUNDAI
51712-2Y000
HYUNDAI
51712-3K100
HYUNDAI
51712-3K110
HYUNDAI
51712-3K150
HYUNDAI
51712-3K160
HYUNDAI
51712-3K300
HYUNDAI
51712-3Q000
HYUNDAI
51712-A0000
HYUNDAI
51712-M0500
HYUNDAI / KIA
51712-A0000
HYUNDAI / KIA
51712-A0100
KIA
51712-0Z000
KIA
51712-1M500
KIA
51712-2Y000
KIA
51712-3K100
KIA
51712-3K110
KIA
51712-3K150
KIA
51712-3K160
KIA
51712-3K300
KIA
51712-M0500
years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
---|
06.15~06.18 | 1400 | D4FC | PA016 RHD | RN1348V | PN0799 | FN0799 | ||
06.18~08.20 | 1400 | D4FC | PA018 RHD | RN1348V | PN0799 | FN0799 | ||
12.19~ | 1500 | D4FA | PFH20 RHD | RN1348V | PN0799 | PN0538 | ||
12.19~ | 1500 | G4FL | PFH20 RHD | RN1348V | PN0799 | PN0538 | ||
07.15~06.18 | 1600 | D4FB | PA016 LHD | RN1348V | PN0799 | FN0799 | ||
07.15~06.18 | 1600 | D4FB | PA016 RHD | RN1348V | PN0592 | FN0799 | ||
08.16~05.21 | 1600 | G4FG | M017 RU | RN1348VRN1548V | PN0373 | RN1549RN2086 | PN0436 | |
07.15~06.18 | 1600 | G4FG | PA016 LHD | RN1348V | PN0799 | FN0799 | ||
07.15~06.18 | 1600 | G4FG | PA016 RHD | RN1348V | PN0799 | FN0799 | ||
06.18~08.20 | 1600 | G4FG | PA018 LHD | RN1348V | PN0799 | FN0799 | ||
06.18~08.18 | 1600 | G4FG | PA018 RHD | RN1348V | PN0799 | FN0799 | ||
07.21~ | 1600 | G4FG | PFZ21 | RN1562VRN1348V | PN0799PN0958 | RN1601RN1549RN2233 | PN0538 | |
08.16~05.21 | 2000 | G4NA | M017 RU | RN1348V | PN0373 | RN2086RN1549 | PN0436 | |
03.20~10.21 | 2000 | G4NA | M017 RU | RN1348VRN1548V | PN0373 | RN1549RN2086 | PN0436 | |
12.19~ | 2000 | G4NL | PFH20 LHD GRAND 7P | RN1348V | PN0799 | |||
07.21~ | 2000 | G4NL | PFZ21 | RN1348V | PN0799 | RN1601RN2233RN1549 | PN0538 |
01.15~01.18 | 1600 | G4FD | PDF15 SDN LHD | RN1348V | PN0052 | RN1556 | PN0538 | |
02.11~06.15 | 1700 | D4FD | DF | RN1348V | PN0052 | RN1556 | PN0538 | |
02.11~06.15 | 2000 | G4NA | PDF12 WGN LHD | RN1348V | PN0052 | RN1556 | PN0538 | |
02.11~06.15 | 2000 | G4NA | PDF12 WGN RHD | RN1348V | PN0052 | RN1556 | PN0538 | |
01.15~01.18 | 2000 | G4NA | PDF15 SDN LHD | RN1348V | PN0052 | RN1556 | PN0538 | |
02.11~06.15 | 2000 | G4NC | LC81 | RN1348V | PN0052 | RN1556 | PN0538 |
01.14~06.15 | 1600 | G4FD | TMZ10 LHD | RN1348V | PN0052 | RN1307 | PN0436 | FN11006 |
05.13~01.16 | 2000 | D4HA | PTM14 RHD | RN1348V | PN0052 | RN1307 | PN0436 | FN11006 |
10.09~08.13 | 2000 | D4HA | TM10 AUS | RN1348V | PN0052 | RN1176 | PN0436 | FN11006 |
01.10~08.13 | 2000 | D4HA | TMZ10 LHD | RN1348V | PN0052 | RN1176 | PN0436 | FN11009 |
07.13~06.15 | 2000 | D4HA | TMZ14 RUS | RN1348V | PN0052 | RN1176 | PN0436 | FN11009 |
11.09~06.15 | 2000 | G4KD | LM | RN1348V | PN0052 | RN1176 | PN0436 | FN11009 |
11.09~08.13 | 2000 | G4KD | TM10 LHD | RN1348V | PN0052 | RN1176RN1307 | PN0436 | FN11009FN11006 |
11.09~08.13 | 2000 | G4KD | TM10 RHD | RN1348V | PN0052 | RN1176RN1307 | PN0436 | FN11006FN11009 |
08.09~09.13 | 2000 | G4KD | TMZ10 RUS | RN1348V | PN0052 | RN1307RN1176 | PN0436 | FN11006FN11009 |
07.13~06.15 | 2000 | G4NA | TMZ14 RUS | RN1348V | PN0052 | RN1307RN1176 | PN0436 | FN11009FN11006 |
11.10~12.15 | 2400 | G4KE | LM | RN1348V | PN0052 | RN1176 | PN0436 | FN11009 |
09.06~12.07 | 2000 | D4EA | NF04 RHD | RN1348V | PN0377 | RN1476 | PN0591PN0539 | FN11004 |
09.04~09.06 | 2000 | D4EA | PA04 LHD | RN1348V | PN0377 | RN1476 | PN0539 | FN11004 |
09.04~12.07 | 2000 | G4KA | NF | RN1348VRN1174V | PN0377 | RN1386RN1476 | PN0539 | FN11004 |
12.07~01.13 | 2000 | D4EA | NF | RN1348V | PN0377 | RN1476 | PN0591 | FN11004 |
12.07~10.10 | 2400 | G4KE | EU41 LHD | RN1348V | PN0377 | RN1476 | PN0591 | FN11004 |
12.07~10.10 | 3300 | G6DB | NF | RN1348V | PN0377 | PN0539 | FN11004 |
09.09~06.14 | 2000 | G4KH | PGFA10 US | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
07.12~04.14 | 2000 | G4NE | YF | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
09.09~07.12 | 2400 | G4KJ | PGFA10 US | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
09.09~03.14 | 2400 | G4KJ | YF | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
11.10~07.12 | 2400 | G4KK | PGFE11 US | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
10.06~12.09 | 2000 | D4EA | JM04 LHD | RN1174VRN1348V | PN0377 | RN1176 | PN0539PN0591 | FN0644 |
10.06~12.09 | 2000 | G4GC | JM04 LHD EU | RN1174VRN1348V | PN0377 | RN1386RN1176 | PN0539PN0591 | FN0644FN11004 |
10.09~08.13 | 2000 | D4HA | TM10 LHD | RN1348V | PN0052 | RN1176RN1307 | PN0436 | FN11006FN11009 |
10.09~08.13 | 2000 | D4HA | TM10 RHD | RN1348V | PN0052 | RN1176 | PN0436 | FN11006FN11009 |
11.09~08.13 | 2000 | G4KD | TM10 LHD | RN1348V | PN0052 | RN1176RN1307 | PN0436 | FN11006FN11009 |
11.09~08.13 | 2000 | G4KD | TM10 RHD | RN1174VRN1348V | PN0704PN0052 | RN1307 | PN0436 | FN11006 |
10.09~08.13 | 2400 | G4KE | TM10 LHD GL | RN1348V | PN0052 | RN1176 | PN0436 | FN11009 |
10.09~08.13 | 2400 | G4KE | TM10 LHD US | RN1348V | PN0052 | RN1176 | PN0436 | FN11009 |
10.09~08.13 | 2400 | G4KE | TM10 RHD | RN1348V | PN0052 | RN1176 | PN0436 | FN11009 |
08.13~05.15 | 2000 | D4HA | PTM14 LHD | RN1348V | PN0052 | RN1176 | PN0436 | FN11009FN11006 |
08.13~06.15 | 2000 | G4NA | PTM14 LHD | RN1348V | PN0052 | RN1176RN1307 | PN0436 | FN11006FN11009 |
08.13~05.15 | 2000 | G4NA | PTM14 RHD | RN1348V | PN0052 | RN1176RN1307 | PN0436 | FN11006FN11009 |
08.13~06.15 | 2400 | G4KE | PTM14 LHD | RN1348V | PN0052 | RN1176 | PN0436 | FN11009 |
08.13~06.15 | 2400 | G4KE | PTM14 RHD | RN1348V | PN0052 | RN1176 | PN0436 | FN11009 |
08.13~06.15 | 2400 | G4KJ | PTM14 US | RN1348V | PN0052 | RN1176 | PN0436 | FN11009 |
03.11~01.15 | 1600 | G4FJ | PGS11 US | RN1348V | PN11001PN0739 | RN1549 | PN0538 | |
01.15~02.18 | 1600 | G4FJ | PGS15 US | RN1348V | PN0739 | RN1549 | PN0538 |
01.13~09.16 | 1600 | G4FD | HU81 RHD | RN1348V | PN0799 | RN1947 | PN0538 | |
12.12~08.16 | 1700 | D4FD | WAGON - 5DR 7P | RN1348V | PN0799 | RN1947 | PN0538 | |
01.13~ | 2000 | G4NA | MPV LHD | RN1348V | PN0799PN0537 | RN1947 | PN0538 | |
01.13~09.16 | 2000 | G4NC | HU | RN1348V | PN0799 | RN1947 | PN0538 | |
01.13~09.16 | 2000 | G4ND | RPA412 | RN1348V | PN0799 | RN1947 | PN0538 | |
01.13~09.16 | 2000 | L4NA | DOMPA412 | RN1348V | PN0799 | RN1947 | PN0538 |
05.15~07.18 | 1000 | G3LC | HB/SW/PRO | RN1348VRN1562V | PN11001PN0537PN0592 | RN1563RN1549 | PN6148PN0538 | |
03.12~07.18 | 1400 | D4FC | HB/SW/PRO | RN1562VRN1348V | PN0592PN11001PN0537 | RN1563RN1549 | PN0538PN6148 | |
03.12~07.18 | 1600 | D4FB | HB/SW/PRO | RN1562VRN1348V | PN11001PN0592PN0537 | RN1549RN1563 | PN6148PN0538 |
01.13~03.16 | 1600 | G4FJ | FZ61 LHD | RN1348V | PN0739 | RN1549 | PN0538 | |
01.13~03.16 | 1600 | G4FJ | FZ61 RHD | RN1348V | PN0739 | RN1549 | PN0538 |
05.18~10.19 | 1600 | D4FE | SDN EU | RN1348V | PN0052 | RN1601 | PN0538 | |
05.18~ | 1600 | D4FE | WGN EU RHD | RN1348V | PN0052 | RN1601 | PN0538 | |
03.10~03.14 | 2000 | G4NE | PTFE11 | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
03.14~03.16 | 2000 | G4NE | PTFE14 | RN1348V | PN0536 | RN1601 | PN0538 |
03.10~09.13 | 2400 | G4KJ | PTF11 | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
12.11~09.13 | 2400 | G4KJ | TFA12 | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
04.13~02.16 | 2400 | G4KJ | TFA14 | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
04.13~02.16 | 2400 | G4KK | PTFE14 | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
03.10~09.13 | 2400 | G4KK | TF | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
06.19~ | 1400 | G4LD | PTI20 | RN1348V | PN0799 | RN1549 | PN0538 | |
06.19~ | 1600 | G4FG | PTI20 LHD | RN1348V | PN0799 | RN1549 | PN0538 | |
06.19~ | 1600 | G4FG | PTI20 RHD | RN1348V | PN0799 | RN1549 | PN0538 |
08.10~04.14 | 1700 | D4FD | SL | RN1348V | PN0052 | RN1176 | PN0436 | FN11009 |
01.14~03.16 | 1700 | D4FD | SL | RN1348V | PN0052 | RN1176 | PN0436 | FN11006FN11009 |
04.08~07.10 | 2000 | D4EA | FQZ ER | RN1348V | PN0052 | RN1176 | PN0436 | FN11009 |
08.10~04.14 | 2000 | D4HA | PSL10 LHD | RN1348VRN1174V | PN0704PN0052 | RN1307 | PN0436 | FN11008FN11009 |
09.09~04.14 | 2000 | D4HA | PSL10 RHD | RN1348V | PN0052 | RN1307 | PN0436 | FN11008 |
08.10~04.14 | 2000 | D4HA | SLZ10 LHD | RN1348V | PN0052 | RN1176 | PN0436 | FN11009 |
08.10~04.14 | 2000 | G4KD | PSL10 RHD | RN1348VRN1174V | PN0052PN0704 | RN1176RN1307 | PN0436 | FN11009FN11008 |
08.10~10.15 | 2000 | G4KD | SL10 LHD | RN1174VRN1348V | PN0704PN0052 | RN1307RN1176 | PN0436 | FN11009FN11008 |
06.10~04.14 | 2000 | G4KD | SLZ10 LHD | RN1348V | PN0052 | RN1176 | PN0436 | FN11009 |
08.10~04.14 | 2400 | G4KE | PSL10 LHD | RN1348V | PN0052 | RN1307 | PN0436 | FN11009FN11008 |
