ROTOR DISC » RN1174V
Specification
Type
Vented
Disc Thickness (Max)
26
Num. of holes
5
Height
47.4
Centering Diameter
69
Pitch Circle Ø
114.3
Front/Rear
Front
Outter Ø
280
Drum Ø:
142
Disc Thickness (Min)
24
Structure Material
G3000
Notes
Ø H-141.5
Cross Reference
HYUNDAI
51712-2C000
HYUNDAI
51712-2E300
HYUNDAI
51712-3K010
HYUNDAI
51712-3K050
KIA
51712-1D000
KIA
51712-1D100
KIA
51712-1F000
KIA
51712-2G000
KIA
51712-3K000
KIA
51712-3K050
years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
---|
11.09~12.11 | 1400 | D4FC | CW | RN1174V | PN0373 | RN1307 | PN0436 | |
03.07~12.11 | 1400 | G4FA | FD | RN1174V | PN0373 | RN1307 | PN0436 | |
03.07~12.11 | 1600 | D4FB | FD | RN1174V | PN0373 | RN1307 | PN0436 | |
03.07~12.11 | 2000 | D4EA | FD | RN1174V | PN0373 | RN1307 | PN0436 | |
03.07~12.11 | 2000 | G4GC | CW | RN1174V | PN0373 | RN1307 | PN0436 |
08.10~08.12 | 2000 | G4KD | EC41 | RN1174V | PN0704 | RN1307 | PN0436 | FN11008 |
08.12~ | 2000 | G4NA | EC41 SG RHD | RN1174V | PN0704 | RN1307 | PN0436 | FN11008 |
08.10~08.12 | 2400 | G4KE | EC41 | RN1174V | PN0704 | RN1307 | PN0436 | FN11008 |
09.04~12.07 | 2000 | G4KA | NF | RN1174VRN1348V | PN0377 | RN1386RN1476 | PN0539 | FN11004 |
09.06~12.07 | 2000 | L4KA | NF04 LHD | RN1174V | PN0377 | RN1386 | PN0539 | FN11004 |
09.04~12.07 | 2400 | G4KC | NF | RN1174V | PN0377 | RN1386 | PN0539 | FN11004 |
09.04~12.07 | 2400 | G4KC | NFA US | RN1174V | PN0377 | RN1386 | PN0539 |
12.07~10.10 | 2000 | G4KD | NF08 LHD | RN1174V | PN0377 | RN1386 | PN0591 | FN11004 |
12.07~10.10 | 2000 | G4KD | NF08 RHD | RN1174V | PN0377 | RN1386 | PN0591PN0539 | FN11004 |
12.07~01.13 | 2000 | L4KA | PNF08 LHD TAXI | RN1174V | PN0377 | RN1386 | PN0591 | FN11004 |
12.07~10.10 | 2400 | G4KC | NF | RN1174V | PN0377 | RN1386 | PN0591 | FN11004 |
12.07~10.10 | 2400 | G4KE | ET41 LHD | RN1174V | PN0377 | RN1386 | PN0591 | FN11004 |
09.09~07.12 | 2000 | G4KD | PGF10 KDOM | RN1174V | PN0704 | RN1307 | PN0436 | FN11008 |
09.09~04.14 | 2000 | G4KD | YF | RN1174V | PN0704PN0052 | RN1307 | PN0436 | FN11008 |
09.09~04.14 | 2000 | G4NA | GF | RN1174V | PN0704 | RN1307 | PN0436 | FN11008 |
09.09~04.14 | 2000 | L4KA | GF | RN1174V | PN0704 | RN1307 | PN0436 | FN11008 |
09.09~04.14 | 2000 | L4NA | GF | RN1174V | PN0704 | RN1307 | PN0436 | FN11008 |
08.10~08.14 | 2400 | G4KE | PGF10 LHD EU | RN1174V | PN0704 | RN1307 | PN0436 | FN11008 |
08.10~10.12 | 2400 | G4KE | PGF10 LHD GEN | RN1174V | PN0704 | RN1307 | PN0436 | FN11008 |
04.14~03.17 | 2000 | G4NA | KEURPC114 RHD | RN1174V | PN0704 | RN1307 | PN0436 | FN11008 |
04.14~03.17 | 2000 | G4NA | PC114 LHD | RN1174V | PN0704 | RN1307 | PN0436 | FN11008 |
04.14~03.17 | 2000 | L4NA | PC114 | RN1174V | PN0704 | RN1307 | PN0436 | FN11008 |
04.14~03.17 | 2400 | G4KE | PC114 LHD | RN1174VRN1644V | PN0704PN0052 | RN1601RN1307 | PN0538PN0436 | FN11008 |
04.14~03.17 | 2400 | G4KJ | LF | RN1174V | PN0704PN0052 | RN1307RN1601 | PN0538PN0436 | FN11008 |
03.17~01.20 | 2000 | G4NA | KEURPC117 | RN1174V | PN0704 | RN1307 | PN0436 | FN11008 |
03.17~09.17 | 2400 | G4KE | PC117 LHD | RN1174VRN1653V | PN0578PN0704 | RN1476RN1601RN1307 | PN0436PN0538 | FN11008 |
10.06~01.08 | 2000 | D4EA | JM04 LHD | RN1174VRN1348V | PN0377 | RN1176 | PN0591PN0539 | FN0644 |
10.06~12.09 | 2000 | D4EA | JM04 RHD | RN1174V | PN0377 | RN1176 | PN0539 | FN0644 |
04.04~10.06 | 2000 | D4EA | PA04 | RN1174V | PN0377 | RN1176 | PN0539 | FN0644 |
07.04~10.06 | 2000 | D4EA | PA04 LHD DOM | RN1174V | PN0377 | RN1176 | PN0539 | FN0644 |
10.06~12.09 | 2000 | G4GC | JM04 | RN1174V | PN0377 | RN1176 | PN0539 | |
04.04~10.06 | 2000 | G4GC | PA04 | RN1174V | PN0377 | RN1176RN1386 | PN0539 | FN0644FN11004 |
04.04~10.06 | 2000 | G4GC | PA04 RUS | RN1174V | PN0377 | RN1176 | PN0539 | FN0644 |
04.04~10.06 | 2000 | G4GC | PA04 US | RN1174V | PN0377 | RN1176RN1386 | PN0539 | FN0644FN11004 |
10.06~12.09 | 2700 | G6BA | JM04 | RN1174V | PN0377 | RN1176 | PN0539 | |
04.04~10.06 | 2700 | G6BA | PA04 | RN1174V | PN0377 | RN1176 | PN0539 | FN0644 |
06.10~12.12 | 1600 | D4FB | UN | RN1174VRN1412V | PN0052 | PN0426 | FN0731 | |
08.09~12.12 | 1600 | G4FC | UN | RN1174VRN1412V | PN0052 | PN0426 | FN0731 | |
10.06~08.09 | 2000 | D4EA | FG | RN1174V | PN0052 | PN0426 | FN0731 | |
01.06~11.06 | 2000 | G4KA | BK | RN1174V | PN0052 | PN0426 | FN0731 | |
10.06~12.12 | 2000 | G4KA | FG LHD | RN1174V | PN0052 | PN0426 | FN0731 | |
10.06~08.09 | 2000 | G4KA | FG RHD | RN1174V | PN0052 | PN0426 | FN0731 |
05.10~06.13 | 2000 | G4KD | PTF11 | RN1174V | PN0635 | RN1307 | PN0591 | FN0716 |
05.10~06.13 | 2000 | G4NA | PTF11 | RN1174V | PN11001PN0635 | RN1307RN1601 | PN0591PN0538 | FN0716 |
03.16~02.18 | 2000 | G4ND | PD416 KDOM | RN1174V | PN0704 | RN1307 | PN0436 | FN11008 |
05.10~06.13 | 2000 | L4KA | PTF11 | RN1174V | PN0635 | RN1307RN1601 | PN0591PN0538 | FN0716 |
07.15~02.18 | 2000 | L4NA | PD416 | RN1174V | PN0704 | RN1307 | PN0436 | FN11008 |
02.18~01.20 | 2000 | L4NA | PD418 | RN1174V | PN0704 | RN1307 | PN0436 | FN11008 |
06.13~07.15 | 2000 | L4NA | PTF14 | RN1174V | PN0635 | RN1307RN1601 | PN0591PN0538 | FN0716 |
10.05~11.10 | 2000 | G4KA | GE | RN1174V | PN0377 | RN1386 | PN0539 | FN11004 |
06.09~01.11 | 2000 | G4KD | GG | RN1174V | PN0377 | RN1386 | PN0539 | FN11004 |
06.09~01.11 | 2000 | L4KA | GH | RN1174V | PN0377 | RN1386 | PN0539 | FN11004 |
01.10~01.13 | 2000 | G4KD | PTF11 RHD | RN1644VRN1174V | PN0635PN11001 | RN1476RN1307 | PN0591 | FN0716 |
08.13~02.16 | 2000 | G4NA | GM41 | RN1174V | PN0635 | RN1307 | PN0591 | FN0716 |
10.15~02.18 | 2000 | G4NA | PD416 LHD | RN1174V | PN0704 | RN1307 | PN0436 | FN11008 |
10.15~02.18 | 2400 | G4KE | PD416 SDN LHD | RN1174V | PN0704 | RN1307 | PN0436 | FN11008 |
03.10~09.13 | 2400 | G4KE | PTF11 LHD | RN1174V | PN0635 | RN1307 | PN0591 | FN0716 |
04.13~03.16 | 2400 | G4KE | PTF14 LHD | RN1174V | PN0635 | RN1307 | PN0591 | FN0716 |
09.06~08.08 | 2000 | D4EA | DD | RN1174V | PN0377 | RN1386 | PN0539 | |
05.08~05.10 | 2000 | D4EA | DD | RN1174V | PN0377 | RN1386 | PN0539 | |
04.06~06.09 | 2000 | D4EA | MG | RN1174V | PN0377 | RN1386 | PN0539 | |
06.09~01.11 | 2000 | D4EA | MG | RN1174V | PN0377 | RN1386 | PN0539 | |
09.06~08.08 | 2000 | G4KA | DD | RN1174V | PN0377 | RN1386 | PN0539 | FN11004 |
05.08~05.10 | 2000 | G4KA | DD | RN1174V | PN0377 | RN1386 | PN0539 | FN11004 |
03.05~03.08 | 2000 | G4KA | GE22 | RN1174V | PN0377 | RN1386 | PN0539 | FN11004 |
05.08~01.11 | 2000 | G4KD | PMG09 LHD | RN1174V | PN0377 | RN1386 | PN0539 | FN11004 |
05.08~01.11 | 2000 | G4KD | PMG09 RHD | RN1174V | PN0377 | RN1386 | PN0539 | FN11004 |
04.06~06.09 | 2400 | G4KC | GE22 | RN1174V | PN0377 | RN1386 | PN0539 | FN11004 |
10.05~09.06 | 2700 | G6EA | DD | RN1174V | PN0377 | RN1386 | PN0539 | FN11004 |
04.06~06.09 | 2700 | G6EA | MG | RN1174V | PN0377 | RN1386 | PN0539 | FN11004 |
06.09~01.11 | 2700 | G6EA | MG | RN1174V | PN0377 | RN1386 | PN0539 | FN11004 |
06.06~01.12 | 2400 | G4KE | UN06 | RN1174V | PN0052 | PN0426 | FN0731 | |
06.06~01.12 | 2700 | G6EA | UN06 | RN1174V | PN0052 | PN0426 | FN0731 |
03.06~08.10 | 2000 | D4EA | FQ | RN1174V | PN0377 | RN1176 | PN0539 | FN0644 |
09.06~07.10 | 2000 | D4EA | FQ RHD | RN1174V | PN0377 | RN1176 | PN0539 | FN0644 |
08.10~05.11 | 2000 | D4HA | PSL10 LHD | RN1348VRN1174V | PN0704PN0052 | RN1307 | PN0436 | FN11008FN11009 |
09.06~07.10 | 2000 | G4GC | FQ LHD | RN1174V | PN0377 | RN1176 | PN0539 | FN0644 |
09.06~07.10 | 2000 | G4GC | FQ RHD | RN1174VRN1412V | PN0377 | RN1386RN1176DN1510 | PN0539FN0820 | FN0644FN11004 |
03.06~04.08 | 2000 | G4GC | K1F | RN1174VRN1412V | PN0377 | RN1176DN1510 | PN0539FN0820 | FN0644FN11004 |
08.10~04.14 | 2000 | G4KD | PSL10 RHD | RN1348VRN1174V | PN0052PN0704 | RN1307RN1176 | PN0436 | FN11009FN11008 |
08.10~10.15 | 2000 | G4KD | SL10 LHD | RN1348VRN1174V | PN0052PN0704 | RN1307RN1176 | PN0436 | FN11009FN11008 |
12.04~09.08 | 2700 | G6BA | FQ | RN1174V | PN0377 | RN1176 | PN0539 | FN0644 |
03.06~04.08 | 2700 | G6BA | FQ | RN1174V | PN0377 | RN1176 | PN0539 | FN0644 |
