ROTOR DISC » RN1307

Specification

Type
Solid
Disc Thickness (Max)
10
Num. of holes
5
Height
61.1
Centering Diameter
76
Front/Rear
Rear
Pitch Circle Ø
114.3
Outter Ø
262
Drum Ø:
168
Disc Thickness (Min)
9
Structure Material
G3000

Cross Reference

HYUNDAI
58411-1H100
HYUNDAI
58411-1H300
HYUNDAI
58411-1K300
HYUNDAI
58411-3S000
HYUNDAI
584112H300
KIA
58411-1H300
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
11.06~12.11 1600 D4FB HD06 SDN LHD RN1606V PN0377 RN1307 FN11189PN0539 FN11004
04.06~09.11 1600 G4FC HD06 LHD RN1606V PN0377 RN1307 PN0539PN0591 FN11004
11.06~09.11 1600 G4FC HD06 RHD RN1606V PN0377 DN1503RN1307 FN11189PN0539 FN11004
04.06~01.07 1600 G4FC PA06 RHD RN1606V PN0377 RN1307 PN0539 FN11004
04.06~06.11 2000 G4GC PHD06 LHD US/CAN RN1606V PN0377 RN1307DN1503 PN0591FN11189 FN11004
04.06~06.11 2000 G4GC PHD06 RHD RN1606V PN0377 DN1503RN1307 PN0539FN11189 FN11004
11.09~12.11 1400 D4FC CW RN1174V PN0373 RN1307 PN0436
03.07~12.11 1400 G4FA FD RN1174V PN0373 RN1307 PN0436
03.07~12.11 1600 D4FB FD RN1174V PN0373 RN1307 PN0436
03.10~12.11 1600 G4FC D#51 5DR SDN LHD RUS RN1412V PN0373 RN1307 PN0436 FN11006
01.07~03.10 1600 G4FC DC51 5DR SDN LHD RN1412V PN0373 RN1307 PN0436 FN11006
03.10~12.11 1600 G4FC DC51 5DR SDN LHD RN1412V PN0373 RN1307 PN0436 FN11006
01.07~12.11 1600 G4FC DC51 5DR SDN RHD RN1412V PN0373 RN1307 PN0436 FN11006
04.08~03.10 1600 G4FC DC81 5DR WGN RHD RN1412V PN0373 RN1307 PN0436 FN11006
03.10~03.12 1600 G4FC DC81 5DR WGN RHD RN1412V PN0373 RN1307 PN0436 FN11006
03.07~12.11 2000 D4EA FD RN1174V PN0373 RN1307 PN0436
03.07~12.11 2000 G4GC CW RN1174V PN0373 RN1307 PN0436
08.10~08.12 2000 G4KD EC41 RN1174V PN0704 RN1307 PN0436 FN11008
08.12~ 2000 G4NA EC41 SG RHD RN1174V PN0704 RN1307 PN0436 FN11008
08.10~08.12 2400 G4KE EC41 RN1174V PN0704 RN1307 PN0436 FN11008
01.14~06.15 1600 G4FD TMZ10 LHD RN1348V PN0052 RN1307 PN0436 FN11006
05.13~01.16 2000 D4HA PTM14 RHD RN1348V PN0052 RN1307 PN0436 FN11006
11.09~08.13 2000 G4KD TM10 LHD RN1348V PN0052 RN1307RN1176 PN0436 FN11009FN11006
11.09~08.13 2000 G4KD TM10 RHD RN1348V PN0052 RN1307RN1176 PN0436 FN11006FN11009
08.09~09.13 2000 G4KD TMZ10 RUS RN1348V PN0052 RN1176RN1307 PN0436 FN11006FN11009
07.13~06.15 2000 G4NA TMZ14 RUS RN1348V PN0052 RN1176RN1307 PN0436 FN11006FN11009
09.09~04.14 2000 G4KD YF RN1174V PN0704PN0052 RN1307 PN0436 FN11008
09.09~04.14 2000 G4NA GF RN1174V PN0704 RN1307 PN0436 FN11008
09.09~04.14 2000 L4KA GF RN1174V PN0704 RN1307 PN0436 FN11008
09.09~04.14 2000 L4NA GF RN1174V PN0704 RN1307 PN0436 FN11008
08.10~10.12 2400 G4KE PGF10 LHD RN1174V PN0704 RN1307 PN0436 FN11008
04.14~03.17 2000 G4NA KEURPC114 RHD RN1174V PN0704 RN1307 PN0436 FN11008
04.14~03.17 2000 G4NA PC114 LHD RN1174V PN0704 RN1307 PN0436 FN11008
04.14~03.17 2000 L4NA PC114 RN1174V PN0704 RN1307 PN0436 FN11008
04.14~03.17 2400 G4KE PC114 LHD RN1644VRN1174V PN0704PN0052 RN1307RN1601 PN0538PN0436 FN11008
04.14~03.17 2400 G4KJ LF RN1174V PN0704PN0052 RN1307RN1601 PN0436PN0538 FN11008
03.17~01.20 2000 G4NA KEURPC117 RN1174V PN0704 RN1307 PN0436 FN11008
03.17~01.20 2400 G4KE PC117 LHD RN1653VRN1174V PN0578PN0704 RN1601RN1307RN1476 PN0436PN0538 FN11008
10.09~08.13 2000 D4HA TM10 LHD RN1348V PN0052 RN1307RN1176 PN0436 FN11006FN11009
11.09~08.13 2000 G4KD TM10 LHD RN1348V PN0052 RN1307RN1176 PN0436 FN11006FN11009
11.09~08.13 2000 G4KD TM10 RHD RN1174VRN1348V PN0704PN0052 RN1307 PN0436 FN11006
08.13~06.15 2000 G4NA PTM14 LHD RN1348V PN0052 RN1176RN1307 PN0436 FN11006FN11009
08.13~05.15 2000 G4NA PTM14 RHD RN1348V PN0052 RN1307RN1176 PN0436 FN11006FN11009
01.10~07.12 1400 G4FA ED RN1412V PN0373 RN1307 PN0436
09.06~11.12 1600 D4FB ED 5DR HB LHD RN1412V PN0373 RN1307 PN0436 FN11006
09.09~11.12 1600 D4FB PED10 3DR HB LHD RN1412V PN0373 RN1307 PN0436 FN11006
01.10~08.12 1600 G4FC BS RN1412V PN0373 RN1307 PN0436
01.07~01.13 2000 D4EA ED RN1412V PN0373 RN1307 PN0436 FN11006
05.10~06.13 2000 G4KD PTF11 RN1174V PN0635 RN1307 PN0591 FN0716
06.13~07.15 2000 G4KH PTF14 RN1644V PN11001 RN1601RN1307 PN0591PN0538 FN0716
05.10~06.13 2000 G4NA PTF11 RN1174V PN0635PN11001 RN1307RN1601 PN0591PN0538 FN0716
05.10~06.13 2000 L4KA PTF11 RN1174V PN0635 RN1601RN1307 PN0538PN0591 FN0716
07.15~02.18 2000 L4NA PD416 RN1174V PN0704 RN1307 PN0436 FN11008
02.18~01.20 2000 L4NA PD418 RN1174V PN0704 RN1307 PN0436 FN11008
06.13~07.15 2000 L4NA PTF14 RN1174V PN0635 RN1601RN1307 PN0591PN0538 FN0716
01.10~01.13 2000 G4KD PTF11 RHD RN1174VRN1644V PN11001PN0635 RN1307RN1476 PN0591 FN0716
08.13~02.16 2000 G4NA GM41 RN1174V PN0635 RN1307 PN0591 FN0716
10.15~02.18 2000 G4NA PD416 LHD RN1174V PN0704 RN1307 PN0436 FN11008
10.15~02.18 2400 G4KE PD416 SDN LHD RN1174V PN0704 RN1307 PN0436 FN11008
09.06~03.12 2000 G4GC ED RN1412V PN0373 RN1307 PN0436 FN11006
08.10~04.14 2000 D4HA PSL10 LHD RN1348VRN1174V PN0052PN0704 RN1307 PN0436 FN11009FN11008
09.09~04.14 2000 D4HA PSL10 RHD RN1348V PN0052 RN1307 PN0436 FN11008
08.10~04.14 2000 G4KD PSL10 RHD RN1348VRN1174V PN0052PN0704 RN1176RN1307 PN0436 FN11009FN11008
08.10~10.15 2000 G4KD SL10 LHD RN1174VRN1348V PN0704PN0052 RN1307RN1176 PN0436 FN11008FN11009
08.10~04.14 2400 G4KE PSL10 LHD RN1348V PN0052 RN1307 PN0436 FN11009FN11008
01.14~03.16 2000 D4HA SL14 RN1348V PN0052 RN1176RN1307 PN0436 FN11008FN11009
01.14~03.16 2000 G4NA PSL14 RHD RN1348V PN0052 RN1307 PN0436 FN11008

Exemption from liability: the catalog data is advisory and can be used for reference only
