ROTOR DISC » RN1606V
Specification
Type
Vented
Outter Ø
275
Num. of holes
5
Disc Thickness (Max)
26
Height
47
Centering Diameter
69
Pitch Circle Ø
114.3
Front/Rear
Front
Drum Ø:
143
Disc Thickness (Min)
24
Structure Material
G3000
Cross Reference
HYUNDAI
517122H000
HYUNDAI / KIA
517122H000
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 11.06~12.11 | 1600 | D4FB | HD06 SDN LHD | RN1606V | PN0377 | RN1307 | PN0539FN11189 | FN11004 |
| 04.06~09.11 | 1600 | G4FC | HD06 LHD | RN1606V | PN0377 | RN1307 | PN0591PN0539 | FN11004 |
| 11.06~09.11 | 1600 | G4FC | HD06 RHD | RN1606V | PN0377 | DN1503RN1307 | FN11189PN0539 | FN11004 |
| 04.06~01.07 | 1600 | G4FC | PA06 RHD | RN1606V | PN0377 | RN1307 | PN0539 | FN11004 |
| 04.06~06.11 | 2000 | G4GC | PHD06 LHD US/CAN | RN1606V | PN0377 | RN1307DN1503 | PN0591FN11189 | FN11004 |
| 04.06~06.11 | 2000 | G4GC | PHD06 RHD | RN1606V | PN0377 | DN1503RN1307 | PN0539FN11189 | FN11004 |
