BRAKE SHOE » FN0716
Specification
Radius
83
Width
26
Thickness
4.6
Pcs In Set
4
Cross Reference
FMSI
S982-1661
HYUNDAI
58305-2TA00
HYUNDAI
58305-3LA10
HYUNDAI
58305-3QA00
HYUNDAI / KIA
583053QA01
KIA
58305-2TA00
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.11~07.14 | 3000 | G6DE | FH41 | RN1644VRN1547V | PN0536PN0537 | RN1601RN1476 | PN0591PN0778 | FN0716 |
| 09.11~06.16 | 3300 | G6DH | HG | RN1644VRN1547V | PN11001PN0536 | RN1601RN1476 | PN0778PN0591 | FN0716 |
| 05.14~10.16 | 2200 | D4HB | PHG15 | RN1644V | PN0799 | RN1476RN1601 | PN0591PN0778 | FN0716 |
| 06.14~10.16 | 2400 | G4KE | HG | PN11001PN0537 | PN0778 | FN0716 | ||
| 11.11~06.14 | 3000 | G6DG | HG | PN11001PN0537 | PN0778 | FN0716 | ||
| 06.14~10.16 | 3000 | G6DG | HG | PN11001PN0537 | PN0778 | FN0716 | ||
| 11.11~06.14 | 3000 | L6DB | PHG11 | RN1547V | PN0536 | RN1476 | PN0591 | FN0716 |
| 11.11~06.14 | 3300 | G6DH | HG | PN11001PN0537 | PN0778 | FN0716 | ||
| 06.14~10.16 | 3300 | G6DH | HG | PN11001PN0537 | PN0778 | FN0716 |
| 09.09~06.14 | 2000 | G4KH | PGFA10 US | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
| 07.12~04.14 | 2000 | G4NE | YF | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
| 09.09~07.12 | 2400 | G4KJ | PGFA10 US | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
| 09.09~03.14 | 2400 | G4KJ | YF | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
| 11.10~07.12 | 2400 | G4KK | PGFE11 US | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
| 05.10~06.13 | 2000 | G4KD | PTF11 | RN1174V | PN0635 | RN1307 | PN0591 | FN0716 |
| 06.13~07.15 | 2000 | G4KH | PTF14 | RN1644V | PN11001 | RN1307RN1601 | PN0591PN0538 | FN0716 |
| 05.10~06.13 | 2000 | G4NA | PTF11 | RN1174V | PN0635PN11001 | RN1307RN1601 | PN0591PN0538 | FN0716 |
| 02.18~12.20 | 2000 | G4ND | PD418 | RN1644V | PN11001PN0578 | RN1601 | PN0538 | FN0716 |
| 05.10~06.13 | 2000 | L4KA | PTF11 | RN1174V | PN0635 | RN1307RN1601 | PN0591PN0538 | FN0716 |
| 06.13~07.15 | 2000 | L4NA | PTF14 | RN1174V | PN0635 | RN1601RN1307 | PN0538PN0591 | FN0716 |
| 05.10~06.13 | 2400 | G4KJ | PTF11 | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
| 03.12~ | 2000 | G4KD | GN | RN1644V | PN0739PN11001 | RN1476 | PN0591 | FN0716 |
| 03.10~03.13 | 2000 | G4KD | PTF11 LHD | RN1174V | PN0635 | RN1307 | PN0591 | FN0716 |
| 01.10~01.13 | 2000 | G4KD | PTF11 RHD | RN1644VRN1174V | PN0635PN11001 | RN1476RN1307 | PN0591 | FN0716 |
| 08.13~02.16 | 2000 | G4NA | GM41 | RN1174V | PN0635 | RN1307 | PN0591 | FN0716 |
| 03.10~09.13 | 2000 | G4NA | PTF11 LHD | RN1644V | PN11001 | RN1476 | PN0591 | FN0716 |
| 08.13~02.16 | 2000 | G4ND | GN | RN1644V | PN11001 | RN1601 | PN0538 | FN0716 |
| 03.10~03.14 | 2000 | G4NE | PTFE11 | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
| 03.10~09.13 | 2400 | G4KE | PTF11 LHD | RN1174V | PN0635 | RN1307 | PN0591 | FN0716 |
| 03.10~09.13 | 2400 | G4KE | PTF11 RHD | RN1644V | PN11001 | RN1476 | PN0591 | FN0716 |
| 04.13~03.16 | 2400 | G4KE | PTF14 LHD | RN1174V | PN0635 | RN1307 | PN0591 | FN0716 |
| 04.13~03.16 | 2400 | G4KE | PTF14 RHD | RN1644V | PN11001 | RN1476 | PN0591 | FN0716 |
| 03.10~09.13 | 2400 | G4KJ | PTF11 | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
| 12.11~09.13 | 2400 | G4KJ | TFA12 | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
| 04.13~02.16 | 2400 | G4KJ | TFA14 | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
| 04.13~02.16 | 2400 | G4KK | PTFE14 | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
| 03.10~09.13 | 2400 | G4KK | TF | RN1348V | PN0536 | RN1476 | PN0591 | FN0716 |
