NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2193V

ROTOR DISC » RN2193V

Specification

Type

Vented

Outter Ø

303

Num. of holes

5

Disc Thickness (Max)

28

Disc Thickness (Min)

26.4

Height

47

Centering Diameter

69

Pitch Circle Ø

114.3

Drum Ø:

141

Structure Material

G3000

Front/Rear

Front

Cross Reference

HYUNDAI

51712-39910

HYUNDAI

51712-3F000

HYUNDAI

51712-3L000

HYUNDAI

51712-3L010

HYUNDAI

51712-3L050

HYUNDAI

51712-3L060

HYUNDAI / KIA

51712-39900

HYUNDAI / KIA

517123F000

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

HYUNDAI » Azera

11.09~12.11	2700	G6EA	FB41	RN2193V	PN0377		PN0539	FN11005
02.05~12.11	3300	G6DB	FC41	RN2193V	PN0377		PN0539	FN11005

HYUNDAI » Grandeur TG

09.05~12.11

2700

L6EA

TG

RN2193V

PN0377

PN0539

FN11005

KIA » Amanti

01.04~11.06

3500

G6CU

EH

RN2193V

PN0115

PN0539

FN0763

KIA » Opirus

03.03~11.06	3000	G6CT	K3F	RN2193V	PN0853		PN0539	FN0763
03.03~05.06	3500	G6CU	EH	RN2193V	PN0115		PN0539	FN0763
