BRAKE SHOE » FN8905
Specification
Radius
114.7
Width
45.3/35.5
Pcs In Set
4
Thickness
6.2
Cross Reference
BENDIX AUS
BS1745
FMSI
N1745
FMSI
S844-1574
KASHIYAMA
K2450
TOYOTA
46540-60031
TOYOTA
46540-60050
TOYOTA
46550-60041
TOYOTA
46550-60060
TOYOTA
46580-60031
TOYOTA
46580-60050
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.90~01.01 | 4200 | 1H-Z | HZJ80R | RN1090V | PN1242 | DN1222RN1157VRN1831VDN1223 | FN2280PN1243FN1179 | FN8905FN0642 |
| 01.90~01.98 | 4200 | 1H-Z | HZJ81 | RN1090VRN1066V | PN1242 | DN1222RN1157V | PN1243FN1179FN2280 | FN0642FN8905 |
| 01.90~01.98 | 4200 | 1HD-T | HDJ81V | RN1066VRN1090V | PN1242 | RN1157V | PN1243 | FN8905FN0642 |
| 01.92~12.06 | 4500 | 1FZ-F# | FZJ80L | RN1066V | PN1242 | RN1157VDN1223 | PN1243FN1179FN2280 | FN8905 |
| 01.92~01.98 | 4500 | 1FZ-F# | FZJ80R | RN1066V | PN1242 | RN1157VDN1223 | FN2280PN1243FN1179 | FN8905 |
| 01.90~01.98 | 4500 | 1FZ-FE | FZJ80 | RN1066V | PN1242 | RN1157VDN1223 | FN2280PN1243FN1179 | FN8905 |
| 01.98~09.07 | 4200 | 1H-Z | HZJ105 | RN1604V | PN1411 | RN1607V | PN1243FN2280FN1179 | FN8905 |
| 01.98~08.07 | 4200 | 1HD-FT | HDJ101K | RN1224V | PN1411 | RN1215V | PN1412 | FN8905 |
| 01.98~09.07 | 4200 | 1HD-FTE | HDJ100L | RN1224V | PN1411 | DN1224RN1215V | PN1412FN1179FN2280 | FN8905 |
| 08.00~08.07 | 4200 | 1HD-FTE | HDJ100R | RN1224V | PN1411 | RN1215V | PN1412 | FN8905 |
| 01.98~08.02 | 4200 | 1HD-T | HDJ100R | RN1224V | PN1411 | RN1215VDN1224 | FN2280PN1412FN1179 | FN8905 |
| 01.98~09.07 | 4500 | 1FZ-FE | FZJ100 | RN1224V | PN1411 | RN1215VDN1224 | FN1179PN1412FN2280 | FN8905 |
| 01.98~09.07 | 4500 | 1FZ-FE | FZJ105L | RN1604V | PN1411 | RN1607VDN1224 | FN1179FN2280PN1243 | FN8905 |
| 01.98~09.07 | 4500 | 1FZ-FE | FZJ105R | RN1604V | PN1411 | RN1607V | PN1243FN1179FN2280 | FN8905 |
| 01.98~09.07 | 4700 | 2UZ-FE | UZJ100L | RN1224V | PN1411 | RN1215VDN1224 | FN1179FN2280PN1412 | FN8905 |
| 01.98~01.04 | 4700 | 2UZ-FE | UZJ100R | RN1224V | PN1411 | RN1215V | PN1412 | FN8905 |
| 01.98~08.07 | 4700 | 2UZ-FE | UZJ100W | RN1224V | PN1411 | RN1215V | PN1412 | FN8905 |
