ROTOR DISC » RN1090V
Specification
Type
Vented
Disc Thickness (Max)
25
Num. of holes
6
Height
58
Centering Diameter
105
Front/Rear
Front
Outter Ø
286
Disc Thickness (Min)
23
Pitch Circle Ø
139.7
Drum Ø:
156
Structure Material
G3000
Cross Reference
TOYOTA
43512-60050
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.90~09.92 | 4000 | 3F-E | FJ80G | RN1090V | PN1242 | RN1831V | PN1243 | FN0642 |
| 01.90~09.92 | 4000 | 3F-E | FJ80L | RN1090V | PN1242 | DN1222RN1831V | FN2280FN1179PN1243 | FN0642 |
| 01.90~09.92 | 4000 | 3F-E | FJ80R | RN1090V | PN1242 | RN1831VDN1222 | FN1179PN1243FN2280 | FN0642 |
| 01.90~07.00 | 4200 | 1H-Z | HZJ70R | RN1090V | PN1219 | FN1179FN2280 | ||
| 04.90~08.99 | 4200 | 1H-Z | HZJ75RV | RN1090V | PN1219 | FN2280FN1179 | ||
| 01.90~01.98 | 4200 | 1H-Z | HZJ80L | RN1090V | PN1242 | DN1223DN1222RN1831V | FN2280PN1243FN1179 | FN0642 |
| 01.90~01.01 | 4200 | 1H-Z | HZJ80R | RN1090V | PN1242 | DN1222RN1157VRN1831VDN1223 | FN1179PN1243FN2280 | FN8905FN0642 |
| 01.90~08.92 | 4200 | 1H-Z | HZJ81 | RN1090VRN1066V | PN1242 | DN1222RN1157V | PN1243FN1179FN2280 | FN0642FN8905 |
| 01.90~08.92 | 4200 | 1HD-#T | HDJ80L | RN1066VRN1090V | PN1242 | RN1831VDN1222RN1157VDN1223 | FN2280PN1243FN1179 | FN0642 |
| 01.90~08.92 | 4200 | 1HD-#T | HDJ80R | RN1090VRN1066V | PN1242 | RN1831VDN1223DN1222RN1157V | FN2280PN1243FN1179 | FN0642 |
| 01.90~08.92 | 4200 | 1HD-T | HDJ81V | RN1066VRN1090V | PN1242 | RN1157V | PN1243 | FN0642FN8905 |
