ROTOR DISC » RN1157V
Specification
Type
Vented
Disc Thickness (Max)
18
Num. of holes
6
Height
102
Centering Diameter
106
Pitch Circle Ø
139.7
Front/Rear
Rear
Outter Ø
335
Drum Ø:
229
Disc Thickness (Min)
16
Structure Material
G3000
Cross Reference
OEM
4243160170
TOYOTA
42431-60170
TOYOTA
42431-60171
TOYOTA
42431-60180
TOYOTA
4243160090
years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
---|
01.90~08.99 | 4200 | 1H-Z | HZJ73HV | RN1139V | PN1387 | RN1157V | PN1243 | FN0642 |
01.90~12.01 | 4200 | 1H-Z | HZJ73V | RN1139V | PN1219PN1387 | DN1222RN1157V | PN1243FN1179FN2280 | FN0642 |
04.90~08.99 | 4200 | 1H-Z | HZJ77HV | RN1139V | PN1387PN1219 | RN1157V | PN1243FN1179FN2280 | FN0642 |
01.90~01.01 | 4200 | 1H-Z | HZJ80R | RN1090V | PN1242 | RN1157VDN1223RN1831VDN1222 | FN1179PN1243FN2280 | FN8905FN0642 |
01.90~01.98 | 4200 | 1H-Z | HZJ81 | RN1090VRN1066V | PN1242 | DN1222RN1157V | FN1179FN2280PN1243 | FN0642FN8905 |
01.90~01.98 | 4200 | 1HD-#T | HDJ80L | RN1066VRN1090V | PN1242 | DN1223RN1831VRN1157VDN1222 | FN1179FN2280PN1243 | FN0642 |
01.90~01.98 | 4200 | 1HD-#T | HDJ80R | RN1066VRN1090V | PN1242 | DN1223DN1222RN1157VRN1831V | FN2280PN1243FN1179 | FN0642 |
01.90~08.98 | 4200 | 1HD-T | HDJ81V | RN1090VRN1066V | PN1242 | RN1157V | PN1243 | FN0642FN8905 |
01.92~12.06 | 4500 | 1FZ-F# | FZJ80L | RN1066V | PN1242 | RN1157VDN1223 | FN2280PN1243FN1179 | FN8905 |
01.92~01.98 | 4500 | 1FZ-F# | FZJ80R | RN1066V | PN1242 | RN1157VDN1223 | FN2280PN1243FN1179 | FN8905 |
01.90~01.98 | 4500 | 1FZ-FE | FZJ80 | RN1066V | PN1242 | RN1157VDN1223 | PN1243FN2280FN1179 | FN8905 |
