DRUM BRAKE » DN1223

DN1223

Specification

Outter Ø
345
Num. of holes
6
Hole Ø
14.4
Centering Diameter
106
Height
108.6
Pitch Circle Ø
139.7
Drum Ø
295
Structure Material
G3000

Cross Reference

TOYOTA
42431-60060
TOYOTA
42431-60140
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Land Cruiser

01.90~01.98 4200 1H-Z HZJ80L RN1090V PN1242 DN1222RN1831VDN1223 FN1179FN2280PN1243 FN0642
01.90~01.01 4200 1H-Z HZJ80R RN1090V PN1242 DN1222RN1157VRN1831VDN1223 PN1243FN2280FN1179 FN8905FN0642
01.90~08.98 4200 1HD-#T HDJ80L RN1066VRN1090V PN1242 RN1157VDN1222DN1223RN1831V FN1179FN2280PN1243 FN0642
01.90~03.01 4200 1HD-#T HDJ80R RN1090VRN1066V PN1242 DN1222RN1157VRN1831VDN1223 PN1243FN1179FN2280 FN0642
01.92~12.06 4500 1FZ-F# FZJ80L RN1066V PN1242 DN1223RN1157V PN1243FN1179FN2280 FN8905
01.92~01.98 4500 1FZ-F# FZJ80R RN1066V PN1242 DN1223RN1157V PN1243FN1179FN2280 FN8905
01.90~01.98 4500 1FZ-FE FZJ80 RN1066V PN1242 RN1157VDN1223 FN1179FN2280PN1243 FN8905
