ROTOR DISC » RN1139V

Specification

Type
Vented
Disc Thickness (Max)
20
Num. of holes
6
Height
47.9
Centering Diameter
100
Front/Rear
Front
Pitch Circle Ø
139.7
Outter Ø
302
Drum Ø:
167
Structure Material
G3000
Disc Thickness (Min)
19

Cross Reference

BENDIX
561444B
OEM
4351269040
TOYOTA
43512-35170
TOYOTA
43512-60011
TOYOTA
43512-60040
TOYOTA
43512-60041
TOYOTA
43512-60100
TOYOTA
43512-69015
TOYOTA
43512-69016
VOLKSWAGEN
J4351235170
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.88~08.91 2000 3Y YN105 RN1139V PN1219PN1387 DN1108 FN2305
01.88~12.97 2400 2L LN105 RN1139V PN1387PN1219 DN1108 FN2305
09.88~08.94 2800 3L LN100 RN1139V PN1393PN1387PN1219 DN1108 FN2305
09.88~08.97 2800 3L LN106 RN1139V PN1219PN1387PN1393 DN1108 FN2305
08.88~09.99 2800 3L LN106L RN1139V PN1393PN1387PN1219 DN1108 FN2305
08.88~09.99 2800 3L LN106R RN1139V PN1219PN1387 DN1108 FN2305
04.90~04.96 2400 22R RJ77 RN1139V PN1219PN0548 DN1214 FN2305
10.85~09.96 2400 2L-T LJ73LV RN1823RN1139V PN1350PN1086PN1387PN1219 FN2252PN1243
01.85~12.96 2400 2L-T LJ77L RN1139V PN1219PN1387 DN1214 FN2305
01.90~12.96 2800 3L LJ79RV RN1139V PN1387PN1219 DN1214 FN2305
01.86~01.97 3000 1KZ-TE KZJ71W RN1139V PN1387PN1219 RN1216V PN1243 FN0642
02.79~10.84 3200 2B BJ41 RN1139V PN1086PN1350FN2255 DN1221 FN2280FN1179
01.60~10.86 3200 2B BJ41V RN1139V PN1350FN2255PN1086 FN2221 FN2298
10.85~01.90 3400 13B-T BJ71V RN1139V PN1350PN1086 DN1221 FN2280FN1179
10.85~02.90 3400 13B-T BJ74RV RN1139V PN1086 FN1179FN2280
11.84~02.92 3400 13B-T BJ74V RN1139V PN1086 FN1179FN2280
08.80~10.84 3400 3B BJ42 RN1139V PN1086PN1350 FN2280FN1179
01.81~12.92 3400 3B BJ60RG RN1139V PN1350PN1086FN2296 FN2280FN1179
08.80~12.92 3400 3B BJ60V RN1139V PN1350FN2255PN1086 FN2280FN1179
04.84~02.94 3400 3B BJ75 RN1139V FN2296PN1086PN1387PN1350 FN1179FN2280
11.84~01.90 3400 3B BJ75LP RN1139V PN1086PN1350FN2296 DN1221 FN1179FN2280
01.90~01.94 3500 1PZ PZJ70V RN1139V PN1219PN1387 DN1222 FN1179FN2280
01.90~12.01 3500 1PZ PZJ75 RN1139V FN2296PN1387PN1219 DN1222 FN1179FN2280
01.86~01.92 3500 1PZ PZJ77HV RN1139V PN1086PN1219PN1350 FN2283FN1179FN2280
01.90~01.94 3500 1PZ PZJ77HV RN1139V PN1387 FN1179FN2280
04.90~01.94 3500 1PZ PZJ77V RN1139V PN1387PN1219 DN1222 FN1179FN2280
08.80~06.85 3600 2H HJ47 RN1139V FN2255PN1086 DN1221 FN2221
10.85~01.90 4000 12H-T HJ61LG RN1139V PN1086PN1350 FN2280FN1179
01.81~12.90 4000 12H-T HJ61V RN1139V PN1350PN1086 FN1179FN2280
08.80~01.90 4000 2H HJ60LG RN1139V PN1086PN1350 FN2280FN1179
01.81~12.90 4000 2H HJ60R RN1139V PN1350PN1086 DN1221 FN1179FN2280
01.81~12.90 4000 2H HJ60V RN1139V PN1086PN1350 DN1221 FN1179FN2280
08.87~01.90 4000 3F FJ62LG RN1139V PN1086PN1350 FN1179FN2280
08.80~09.87 4000 3F FJ62V RN1139V PN1350PN1086 DN1221 FN2280FN1179
01.84~12.92 4000 3F FJ75 RN1139V FN2296PN1387 DN1222 FN1179FN2280
08.88~01.90 4000 3F-E FJ62G RN1139V PN1086PN1350 DN1221 FN2280FN1179
01.94~08.99 4200 1H-Z HZJ70 RN1139V PN1219PN1387 DN1222 FN1179FN2280
01.94~08.99 4200 1H-Z HZJ70V RN1139V PN1387PN1219 DN1222 FN1179FN2280
01.90~08.99 4200 1H-Z HZJ73HV RN1139V PN1387 RN1157V PN1243 FN0642
01.90~12.01 4200 1H-Z HZJ73V RN1139V PN1219PN1387 RN1157VDN1222 FN2280PN1243FN1179 FN0642
01.90~01.07 4200 1H-Z HZJ75 RN1139V PN1387PN1219 DN1222 FN1179FN2280
01.90~08.99 4200 1H-Z HZJ75LP RN1139V PN1387PN1219FN2296 DN1222 FN2280FN1179
01.90~01.04 4200 1H-Z HZJ75LV RN1139V PN1219FN2296PN1387 DN1222 FN1179FN2280
04.90~08.99 4200 1H-Z HZJ77HV RN1139V PN1387PN1219 RN1157V FN1179FN2280PN1243 FN0642
01.95~08.99 4200 1H-Z HZJ77V RN1139V PN1219PN1387 DN1222 FN2280FN1179
10.82~11.84 4200 2F FJ61V RN1139V PN1350PN1086 DN1221 FN1179FN2280
01.90~07.09 4500 1FZ-F FZJ75LP RN1139V PN1387PN1219 FN1179FN2280
04.90~05.93 2400 2L-TE LJ71G RN1139V PN1350 RN1216V PN1243 FN0642
04.90~05.93 2400 2L-TE LJ78G RN1139V PN1404PN1387 RN1216V PN1243 FN0642
01.90~05.96 2400 2L-TE LJ78W RN1139V PN1219PN1387 RN1216V PN1243 FN0642
11.84~12.96 2400 2LT LJ70 RN1823RN1139V PN1219PN1086 RN1216V PN1243FN2252FN2305 FN0642
05.93~04.96 3000 1KZ-TE KZJ71G RN1139V PN1387PN1219 RN1216V PN1243 FN0642
05.93~04.96 3000 1KZ-TE KZJ78W RN1139V PN1219PN1387 RN1216V PN1243 FN0642
11.84~01.90 3400 3B BJ70V RN1139V PN1086PN1350 DN1221 FN2280FN1179
11.84~01.90 3400 3B BJ73V RN1139V PN1350PN1086FN2255 DN1221 FN1179FN2280
01.90~01.94 3500 1PZ PZJ70 RN1139V PN1219PN1387 DN1222 FN2280FN1179

Exemption from liability: the catalog data is advisory and can be used for reference only
