BRAKE SHOE » FN2296

FN2296

Specification

Radius
147.5
Width
75
Thickness
6.6/8.8
Pcs In Set
4

Cross Reference

AKEBONO
NR-1060
BENDIX AUS
BS1629
KASHIYAMA
K2296
KASHIYAMA
K2301
TOYOTA
04494-36080
TOYOTA
04494-36160
TOYOTA
04494-36280
TOYOTA
04494-60030
TOYOTA
04494-60031
TOYOTA
0449537080
TOYOTA
04496-36080
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

DAIHATSU   »   Delta

05.95~05.99 3400 15B-F BU100# FN2297PN1212FN2296BL2329FN2329PN1388 FN2297FN2329FN2296
05.99~06.03 3700 4B BU301 PN1388PN1441 BL2329FN2296FN2329 FN2298
05.99~06.03 3700 4B BU306 PN1388PN1441 FN2296 FN2298
05.99~06.03 3700 4B BU346 PN1388PN1441 FN2329BL2329FN2296 FN2298
05.95~05.99 4100 15B-F BU162# BL2329FN2329FN2296 FN2297FN2329
05.95~05.99 4100 15B-F BU172N BL2329FN2329FN2296 FN2329FN2297
05.95~05.99 4100 15B-F BU212N FN2329BL2329FN2296PN1388 FN2329FN2297
05.99~06.02 4600 S05C XZU302D PN1441PN1388 FN2329BL2329FN2296
05.99~06.02 4600 S05C XZU302H PN1441PN1388 FN2329BL2329FN2296
05.99~06.03 4600 S05C XZU302N PN1441PN1388 FN2329BL2329FN2296
05.99~06.03 4600 S05C XZU307 PN1388PN1441 FN2329BL2329FN2296
05.99~06.04 4600 S05C XZU312D PN1388PN1441 FN2329BL2329FN2296
05.99~06.03 4600 S05C XZU337 PN1388PN1441 FN2296
05.99~06.03 4600 S05C XZU347 PN1388PN1441 FN2296FN2329BL2329
05.99~06.04 4600 S05C XZU352D PN1388PN1441 FN2296
05.99~06.04 4600 S05C XZU412 PN1388 FN2296BL2329FN2329
05.99~06.03 4900 S05D XZU306 PN1388PN1441 FN2296FN2329BL2329
05.99~06.03 4900 S05D XZU346 PN1441PN1388 FN2296FN2329BL2329
05.99~06.04 4900 S05D XZU411 PN1388 FN2329FN2296BL2329
05.99~06.04 4900 S05D XZU421 PN1388 FN2329FN2296BL2329

HINO   »   DUTRO

05.99~07.05 3700 4B BU301M PN1441PN1388 FN2296BL2329FN2329 FN4443FN0015
05.99~07.05 3700 4B BU301X PN1388PN1441 FN2296BL2329FN2329 FN4443FN0015
06.04~10.06 4000 N04C-T XZU314T PN1441PN1388 FN2296BL2329FN2329 FN0015

TOYOTA   »   Deliboy

07.89~11.95 1500 5K KXC10V RN1337V FN2296PN1328 DN1250 FN2232 FN2298
05.91~09.94 2000 2C CXC10V FN2296PN1328 DN1250 FN2232 FN2298

TOYOTA   »   Dyna

09.84~05.95 2000 YU70V FN2296 FN2296 FN2298
07.01~08.07 2000 1RZ-E RZY220 RN1535V PN1237 DN1214 FN2330FN2297FN2296FN2305FN2366 FN2298
07.01~ 2000 1TR-FE TRY220 RN1535V PN1237 DN1214 FN2330FN2297FN2366FN2305FN2296 FN2298
12.07~ 2000 1TR-FE TRY231 RN1535V PN1237 FN2296FN2297 FN2298
12.07~ 2000 1TR-FPE TRY281 RN1535V PN1237 FN2297FN2296 FN2298
09.84~05.95 2000 3Y YU60 FN2296PN1388FN2294 FN2265FN2295FN2297FN2296 FN2298FN0019
07.04~09.07 2500 2KD-FTV KDY230 RN1535V PN1237 FN2297FN2366FN2305FN2296
10.01~09.07 2500 2KD-FTV KDY240V RN1535V PN1237 FN2296FN2297 FN2298
08.04~09.07 2500 2KD-FTV KDY280 RN1535V PN1237 DN1214 FN2297FN2362FN2296FN2305 FN2298
08.04~09.07 2500 2KD-FTV KDY290V RN1535V PN1237 FN2296FN2297
07.01~08.03 2700 3RZ-FE LY280 RN1535V PN1237 FN2297FN2296 FN2298
05.00~05.07 2700 3RZ-FE RZU300 RN2403VRN1448V PN1441PN21004PN1388 DN1217 FN2329BL2329FN2296 FN0015FN2298
05.00~05.07 2700 3RZ-FE RZU340 RN2403V PN1441PN21004 FN2296 FN2298
07.01~08.04 2700 3RZ-FPE LY230 RN1535V PN1237 FN2362FN2296FN2305FN2330FN2297
06.03~05.07 2700 3RZ-FPE RZU301 RN2403V PN1441PN21004 FN2296 FN0015
08.03~08.07 2700 3RZ-FPE RZY231H RN1535V PN1237 FN2297FN2296 FN2298
08.03~08.07 2700 3RZ-FPE RZY281H RN1535V PN1237 FN2296FN2297 FN2298
08.21~ 2800 1GD-FTV GDY231R RN1535V PN1237 FN2296FN2366 FN2298
01.85~08.98 3000 11B BU61 RN1265V FN2296FN2297PN1212 FN2296FN2297 FN2298
01.85~08.88 3000 11B BU81 RN1265V FN2297PN1212FN2296 FN2297 FN2298
01.85~08.88 3000 11B BU81R RN1265V FN2297FN2295PN1212FN2296 FN2297
08.88~05.95 3000 11B BU84 RN1265V PN1212FN2297FN2296 FN2297 FN2298
09.07~ 3000 1KD-FTV KDY221 RN1535V PN1237 DN1214 FN2366FN2305FN2296FN2330FN2297 FN2298
07.10~ 3000 1KD-FTV KDY231 RN1535V PN1237 DN1214 FN2366FN2286FN2296FN2305FN2297 FN2298
09.07~ 3000 1KD-FTV KDY231L RN1535V PN1237 FN2286FN2296 FN2298
09.07~ 3000 1KD-FTV KDY241V RN1535V PN1237 FN2296FN2297 FN2298
07.01~08.04 3000 5L LY220 RN1535V PN1237 DN1214 FN2305FN2330FN2296FN2366FN2297 FN2298
06.01~08.04 3000 5L LY230 RN1535V PN1237 FN2362FN2297FN2305FN2366FN2296 FN2298
07.01~08.04 3000 5L LY240V RN1535V PN1237 FN2296FN2297 FN2298
07.01~08.04 3000 5L LY280 RN1535V PN1237 FN2297FN2296FN2305 FN2298
07.01~08.04 3000 5L LY290V RN1535V PN1077PN1237 FN2296FN2297 FN2298
08.88~08.98 3000 B BU60 FN2296 FN2297
09.84~06.96 3000 B BU70V FN2296 FN2296 FN2298
09.84~05.95 3000 B BU70VH FN2296 FN2296 FN2298
09.84~08.88 3000 B BU80 FN2297FN2296PN1212 FN2297
09.84~08.88 3400 13B BU62 RN1265V FN2295FN2297PN1212FN2296 FN2297FN2296FN2295 FN2298
09.84~08.88 3400 13B BU62D FN2296FN2295 FN2295FN2297 FN2298
09.84~08.88 3400 13B BU82 RN1265V FN2295PN1388FN2297PN1212FN2296 FN2295FN2297 FN2298
09.84~10.89 3400 13B BU85 PN1388FN2295FN2296 FN2295FN2297 FN2298
05.95~05.99 3400 3B BU100 RN1265VRN1840V FN2296 FN2296FN2297 FN2298
05.95~05.99 3400 3B BU120V FN2296 FN2296 FN2298
05.95~08.99 3400 3B BU140 BL2329FN2329PN1388FN2296 FN2297FN2329 FN2298
08.88~05.95 3700 14B BU66 RN1265V FN2297FN2296PN1388FN2294PN1212 FN2297FN2296FN2295 FN2298
08.88~11.98 3700 14B BU66D FN2295FN2294FN2296PN1388FN2297 FN2297FN2295 FN2298
10.89~05.95 3700 14B BU72 FN2296 FN2297 FN0015
10.89~05.95 3700 14B BU72D FN2296 FN2297 FN0015
08.88~05.95 3700 14B BU87 FN2294PN1388FN2295FN2296 FN2297FN2295 FN2298
05.99~06.04 3700 4B BU301 RN1448VRN2403V PN1441PN21004PN1388 DN1217 BL2329FN2296FN2329 FN2298
05.99~06.04 3700 4B BU306 RN2403V PN1441 FN2296 FN2298
05.99~06.04 3700 4B BU306V RN2403V PN1441 FN2296 FN2298
05.99~06.04 3700 4B BU346 RN1448VRN2403V PN1441PN1388 FN2329BL2329FN2296 FN2298FN0015
10.03~06.11 4000 N04C XZU304 RN2403VRN1448V PN1388PN21004PN1441PN4543 RN1841VDN1217 BL2329FN2329FN2296 FN0015FN4443
09.02~01.06 4000 N04C XZU305R RN2403VRN1448V PN21004PN1441PN1388 DN1217 FN2329FN2296BL2329 FN0015
06.04~10.06 4000 N04C XZU308 RN2403VRN1448V PN4543PN1441PN1388 RN1841VDN1217 FN2296FN2329BL2329 FN0015
06.04~06.11 4000 N04C XZU334 RN1448VRN2403V PN4464PN21004PN1388PN4543 RN1841VRN2252V FN2329FN2296PN4464BL2329 FN0015
10.03~06.11 4000 N04C XZU338 RN1448VRN2403V PN1388PN1441PN4543 RN1841V FN2296 FN0015
10.03~06.11 4000 N04C XZU344 RN2403VRN1448V PN4464PN4543PN1441PN1388PN21004 RN2252VRN1841VDN1217 FN2329BL2329PN4464FN2296 FN2320FN0015
08.01~ 4000 N04C XZU348 RN1448VRN2403V PN1388PN4543PN1441 RN1841V FN2296 FN0015
06.04~06.11 4000 N04C XZU354D RN2403V PN1441PN21004PN4543 RN1841V FN2296 FN4443
07.11~ 4000 N04C-T XZC610D RN2497V PN1553 RN1841V FN2296PN1553 FN2320FN0015
07.11~ 4000 N04C-T XZC630D RN2497V PN1553 RN1841V PN1553FN2296 FN4443FN0015FN2320
07.11~ 4000 N04C-T XZU610D RN2403V PN21004PN1441 RN1841V FN2296PN1441 FN0015FN2320
05.95~05.99 4100 BU120BU FN2296 FN2296 FN2298
05.95~05.99 4100 15B-F BU102 FN2296 FN2296FN2297 FN2298
05.95~05.99 4100 15B-F BU122V FN2296 FN2296 FN2298
05.95~05.99 4100 15B-F# BU212 FN2329BL2329PN1388FN2296 FN2297FN2329 FN2298
05.95~05.99 4100 15BF BU102D FN2296FN2329FN2297 FN2297BL2329FN2329 FN2298
05.00~06.04 4100 15BLPG XZU302 PN1441 FN2296 FN0039
05.00~ 4100 15BLPG XZU342 PN1441 FN2296 FN0039
06.03~02.07 4100 1BZF-NE BZU340 PN1441PN4543 FN2296
06.03~02.07 4100 1BZFPE BZU300 RN2403VRN1448V PN1441PN4543PN1388PN21004 RN1841VDN1217 FN2329BL2329FN2296 FN0015
06.03~06.11 4100 1BZFPE BZU300 RN2403VRN1448V PN4543PN21004PN1388PN1441 RN1841VDN1217 FN2296FN2329BL2329 FN0015
06.04~ 4100 N04C XZU308V RN2403V PN1441 FN2296 FN0015
05.99~06.04 4600 S05C XZU302 RN1448VRN2403V PN1441PN21004PN1388 DN1217 FN2329BL2329FN2296 FN2298
05.99~06.04 4600 S05C XZU307 RN1448V PN1388 DN1217 BL2329FN2296FN2329
05.99~06.04 4600 S05C XZU307V RN2403V PN1441 FN2296 FN0015FN2298
05.99~06.04 4600 S05C XZU312D RN1448VRN2403V PN1441PN1388PN21004 FN2329FN2296BL2329 FN0015FN2298
05.99~06.06 4600 S05C XZU337 RN2403VRN1448V PN1388PN1441 FN2296FN2329BL2329 FN2298FN0015
05.00~06.04 4600 S05C XZU342 RN2403VRN1448V PN1441PN21004PN1388 DN1217 BL2329FN2329FN2296 FN2298FN0015
05.99~06.04 4600 S05C XZU347 RN2403VRN1448V PN1441PN1388 DN1217 FN2329BL2329FN2296 FN2298FN0039
05.99~06.04 4600 S05C XZU352D RN1448VRN2403V PN1441PN21004PN1388 FN2296 FN0015FN2298
05.99~06.04 4600 S05C XZU402 RN1448V PN1388 DN1217 FN2329BL2329FN2296 FN0015
05.99~06.04 4600 S05C XZU412 RN1448V FN0646PN1388 DN1217 BL2329FN2329FN2296 FN2320FN0015FN0039
05.99~08.04 4900 S05D XZU301 RN1448VRN2403V PN1441PN21004PN1388 DN1217 BL2329FN2329FN2296 FN0015
05.99~10.06 4900 S05D XZU306 RN2403V PN1388PN1441 DN1217 FN2296BL2329FN2329 FN0039FN2298FN0015
05.99~ 4900 S05D XZU311D RN1448VRN2403V PN1388PN21004PN1441 DN1217 FN2296FN2329BL2329 FN0015FN0039FN2298
06.04~10.06 4900 S05D XZU336 RN1448V PN1388 FN2296 FN0015
05.99~10.06 4900 S05D XZU346 RN1448VRN2403V PN1388PN1441 DN1217 FN2329FN2296BL2329 FN2298FN0015
05.99~10.06 4900 S05D XZU351D RN1448VRN2403V PN1441PN1388PN21004 FN2296 FN0015FN2298
05.99~10.06 4900 S05D XZU401 RN1448VDN1425RN2251V FN0646PN1388PN4464 DN1424DN1217RN2252V PN4464BL2329FN2296FN2329 FN0015FN2320
05.99~10.06 4900 S05D XZU411 RN2251VRN1448V FN0646PN1388PN4464 RN2252V FN2296PN4464FN2329BL2329 FN2320FN0015

TOYOTA   »   Dyna 150

07.01~ 3000 5L LY230R RN1535V FN2298 FN2296 FN2298

TOYOTA   »   Dyna 200

09.84~08.88 3400 13B BU62 FN2296FN2294PN1212FN2297PN1388 FN2297FN2296FN2295
10.89~05.95 3700 14B BU87R FN2296 FN2297 FN2298

TOYOTA   »   Dyna 200 / Toyoace G25

05.95~12.03 2700 3RZ-FE RZU100 RN1265V PN1212FN2296FN2329BL2329PN1388FN2297 FN2297FN2329 FN2298
05.95~05.99 4100 15B-F BU142 RN1265V FN2297PN1388FN2329FN2296PN1212 BL2329FN2297FN2329 FN2298FN0015
05.95~05.99 4100 15B-F BU162 BL2329FN2296FN2329 FN2297FN2329 FN0015
05.95~05.99 4100 15B-F BU162D FN2296 FN2297 FN0015
05.95~05.99 4100 15B-F BU172 FN2296BL2329FN2329 FN2329FN2297 FN0015

TOYOTA   »   Dyna 350

01.09~ 3000 1KD-FTV YT54Y RN1535V PN1237 FN2296 FN2298

TOYOTA   »   Land Cruiser

01.81~03.92 3400 3B BJ60RG RN1139V FN2296PN1350PN1086 FN1179FN2280
04.84~02.94 3400 3B BJ75 RN1139V PN1086PN1350FN2296PN1387 FN1179FN2280
11.84~01.90 3400 3B BJ75LP RN1139V PN1086FN2296PN1350 DN1221 FN1179FN2280
01.90~12.01 3500 1PZ PZJ75 RN1139V PN1219FN2296PN1387 DN1222 FN1179FN2280
01.84~12.92 4000 3F FJ75 RN1139V PN1387FN2296 DN1222 FN1179FN2280
01.90~08.99 4200 1H-Z HZJ75LP RN1139V FN2296PN1387PN1219 DN1222 FN2280FN1179
01.90~01.04 4200 1H-Z HZJ75LV RN1139V PN1219FN2296PN1387 DN1222 FN2280FN1179

TOYOTA   »   Quick Delivery

06.03~10.06 2700 3RZ-FP RZU280K PN1441 FN2296 FN0039
06.03~10.06 2700 3RZ-FP XZU281K PN1441 FN2296 FN0039
01.00~06.03 2700 3RZ-FPE BU280K PN1237 FN2296
08.01~07.04 3000 5L LY270 RN1535V PN1237 FN2296FN2297 FN2298
08.01~07.04 3000 5L-E LY228K RN1535V PN1237 FN2296FN2297 FN2298
08.99~06.04 3700 4B BU280K PN1441 FN2296
03.00~06.04 3700 4B BU281K PN1441 FN2296
06.04~10.06 4000 N04C-TN XZU280K PN1441 FN2296 FN0039
06.04~10.06 4000 N04C-TN XZU281K PN1441 FN2296 FN0039
06.04~10.06 4000 N04C-TN XZU282K RN2403V PN1441PN21004 FN2296 FN0015

TOYOTA   »   ToyoAce/Dyna Urbannsuporter

08.01~07.04 3000 5L-E LY228K RN1535V PN1237 FN2297FN2296 FN2298
