ROTOR DISC » RN1265V

RN1265V

Specification

Type
Vented
Disc Thickness (Max)
30
Num. of holes
6
Height
101
Centering Diameter
114
Pitch Circle Ø
147
Front/Rear
Front
Outter Ø
262
Disc Thickness (Min)
27
Drum Ø:
117
Structure Material
G3000

Cross Reference

TOYOTA
4351225050
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Dyna

08.85~12.95 2000 3Y YY61 RN1265VRN1264V PN1212 FN2275FN2297 FN2298
08.85~08.88 2400 2L LY60 RN1264VRN1265V PN1212 FN2297FN2275 FN2298
05.95~05.00 2700 3RZ-FE RZU100A RN1265V PN1388FN2329BL2329 FN2329 FN2298
05.95~05.00 2700 3RZ-FP RZU100H RN1265V FN2297PN1388PN1212FN2329BL2329 FN2297FN2329 FN0015FN2298
01.85~08.98 3000 11B BU61 RN1265V PN1212FN2296FN2297 FN2296FN2297 FN2298
01.85~08.88 3000 11B BU81 RN1265V FN2297PN1212FN2296 FN2297 FN2298
01.85~08.88 3000 11B BU81R RN1265V FN2297FN2295PN1212FN2296 FN2297
08.88~05.95 3000 11B BU84 RN1265V FN2297FN2296PN1212 FN2297 FN2298
05.99~07.01 3000 5L LY212 RN1265VRN1264V PN1212 FN2297FN2286FN2362 FN2298
09.84~08.88 3400 13B BU62 RN1265V FN2297PN1212FN2295FN2296 FN2296FN2295FN2297 FN2298
09.84~08.88 3400 13B BU82 RN1265V PN1388FN2297PN1212FN2296FN2295 FN2295FN2297 FN2298
05.95~05.99 3400 3B BU100 RN1265VRN1840V FN2296 FN2297FN2296 FN2298
08.88~05.95 3700 14B BU66 RN1265V FN2297FN2296PN1388FN2294PN1212 FN2296FN2295FN2297 FN2298
05.95~05.99 4100 15B-F BU132 RN1265V PN1388FN2297PN1212FN2329BL2329 FN2329FN2297 FN2298FN0015

TOYOTA   »   Dyna 150

01.95~10.01 3000 5L-E LY212R RN1265VRN1264V PN1212 FN2275FN2286FN2297 FN2298FN0015

TOYOTA   »   DYNA 150/TOYOACE G15

05.95~05.99 2800 3L LY211 RN1265VRN1264V PN1212 FN2297FN2286FN2275 FN2298

TOYOTA   »   Dyna 200 / Toyoace G25

05.95~12.03 2700 3RZ-FE RZU100 RN1265V FN2296FN2329BL2329PN1388FN2297PN1212 FN2329FN2297 FN2298
08.97~05.00 2700 3RZ-FE RZU140 RN1265V FN2297PN1212 FN2297 FN2298
05.95~05.99 4100 15B-F BU142 RN1265V FN2329FN2296PN1212FN2297PN1388 FN2329BL2329FN2297 FN0015FN2298
