BRAKE SHOE » FN2297

FN2297

Specification

Radius
130
Width
85
Thickness
7.3
Pcs In Set
4

Cross Reference

AKEBONO
NR-1058
KASHIYAMA
K2297
NISSAN
AY360-NS101
NISSAN
D4060-MA911
NISSAN
D4060-MA91A
TOYOTA
04494-36090
TOYOTA
04494-36150
TOYOTA
04495-25050
TOYOTA
04495-25130
TOYOTA
0449525070
TOYOTA
04496-36090
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

DAIHATSU   »   Delta

05.95~05.99 3400 15B-F BU100# FN2297PN1212FN2296BL2329FN2329PN1388 FN2297FN2329FN2296
05.95~05.99 3400 3B BU105N FN2329BL2329PN1330 FN2329FN2297
05.95~05.99 4100 15B-F BU102# PN1212PN1388 BL2329FN2297FN2329
10.96~05.99 4100 15B-F BU107N BL2329PN1330FN2329PN1388 FN2297FN2329
05.95~05.99 4100 15B-F BU142N FN2329PN1212PN1388FN2297BL2329 FN2297FN2329
05.95~05.99 4100 15B-F BU162# FN2329FN2296BL2329 FN2329FN2297
05.95~05.99 4100 15B-F BU172N FN2329FN2296BL2329 FN2329FN2297
05.95~05.99 4100 15B-F BU212N FN2329BL2329FN2296PN1388 FN2329FN2297

DAIHATSU   »   Delta Wide

10.96~05.99 4100 15B-F BU147N PN1388PN1330 FN2329BL2329FN2297

HINO   »   DUTRO

01.11~ 4000 N04C-UV XZU700L RN1535V PN1237 FN2297

NISSAN   »   Atlas

06.07~ 3000 ZD30DDTi TZ3F24 PN2413 FN4451FN2297BL1055

TOYOTA   »   Dyna

07.01~08.07 2000 1RZ-E RZY220 RN1535V PN1237 DN1214 FN2366FN2330FN2297FN2296FN2305 FN2298
07.01~ 2000 1TR-FE TRY220 RN1535V PN1237 DN1214 FN2305FN2296FN2330FN2297FN2366 FN2298
12.07~ 2000 1TR-FE TRY231 RN1535V PN1237 FN2296FN2297 FN2298
12.07~ 2000 1TR-FPE TRY281 RN1535V PN1237 FN2296FN2297 FN2298
09.84~05.95 2000 3Y YU60 PN1388FN2294FN2296 FN2296FN2265FN2295FN2297 FN2298FN0019
08.85~12.95 2000 3Y YY61 RN1264VRN1265V PN1212 FN2275FN2297 FN2298
08.85~08.88 2400 2L LY60 RN1265VRN1264V PN1212 FN2275FN2297 FN2298
07.04~09.07 2500 2KD-FTV KDY230 RN1535V PN1237 FN2366FN2305FN2296FN2297
10.01~09.07 2500 2KD-FTV KDY240V RN1535V PN1237 FN2297FN2296 FN2298
08.04~09.07 2500 2KD-FTV KDY280 RN1535V PN1237 DN1214 FN2305FN2297FN2362FN2296 FN2298
08.04~09.07 2500 2KD-FTV KDY290V RN1535V PN1237 FN2296FN2297
07.01~08.03 2700 3RZ-FE LY280 RN1535V PN1237 FN2297FN2296 FN2298
05.95~05.00 2700 3RZ-FP RZU100H RN1265V FN2329PN1388FN2297PN1212BL2329 FN2329FN2297 FN2298FN0015
07.01~08.04 2700 3RZ-FPE LY230 RN1535V PN1237 FN2362FN2296FN2305FN2330FN2297
08.03~08.07 2700 3RZ-FPE RZY231H RN1535V PN1237 FN2297FN2296 FN2298
08.03~08.07 2700 3RZ-FPE RZY281H RN1535V PN1237 FN2297FN2296 FN2298
01.86~01.96 2800 3L LY61 RN1264V PN1212 FN2297FN2286 FN2298
01.85~08.98 3000 11B BU61 RN1265V FN2296PN1212FN2297 FN2296FN2297 FN2298
01.85~08.88 3000 11B BU81 RN1265V FN2296FN2297PN1212 FN2297 FN2298
01.85~08.88 3000 11B BU81R RN1265V PN1212FN2295FN2296FN2297 FN2297
08.88~05.95 3000 11B BU84 RN1265V FN2296FN2297PN1212 FN2297 FN2298
09.07~ 3000 1KD-FTV KDY221 RN1535V PN1237 DN1214 FN2330FN2297FN2366FN2305FN2296 FN2298
07.10~ 3000 1KD-FTV KDY231 RN1535V PN1237 DN1214 FN2296FN2305FN2297FN2366FN2286 FN2298
09.07~ 3000 1KD-FTV KDY241V RN1535V PN1237 FN2296FN2297 FN2298
05.99~07.01 3000 5L LY212 RN1265VRN1264V PN1212 FN2286FN2362FN2297 FN2298
05.99~07.01 3000 5L LY212L PN1212 FN2275FN2297 FN2298
07.01~08.04 3000 5L LY220 RN1535V PN1237 DN1214 FN2296FN2366FN2297FN2305FN2330 FN2298
06.01~08.04 3000 5L LY230 RN1535V PN1237 FN2296FN2362FN2297FN2305FN2366 FN2298
07.01~08.04 3000 5L LY240V RN1535V PN1237 FN2296FN2297 FN2298
07.01~08.04 3000 5L LY280 RN1535V PN1237 FN2297FN2296FN2305 FN2298
07.01~08.04 3000 5L LY290V RN1535V PN1077PN1237 FN2296FN2297 FN2298
08.88~08.98 3000 B BU60 FN2296 FN2297
09.84~08.88 3000 B BU80 FN2296PN1212FN2297 FN2297
08.88~09.93 3000 B BU83 PN1212FN2297 FN2297 FN2298
09.84~08.88 3400 13B BU62 RN1265V FN2297FN2296PN1212FN2295 FN2296FN2295FN2297 FN2298
09.84~08.88 3400 13B BU62D FN2296FN2295 FN2295FN2297 FN2298
09.84~08.88 3400 13B BU82 RN1265V FN2295FN2297PN1388PN1212FN2296 FN2295FN2297 FN2298
09.84~10.89 3400 13B BU85 FN2295FN2296PN1388 FN2297FN2295 FN2298
05.95~05.99 3400 3B BU100 RN1265VRN1840V FN2296 FN2296FN2297 FN2298
08.97~05.99 3400 3B BU105 RN1840V PN1388PN1330 FN2329BL2329FN2297 FN2298
05.95~08.99 3400 3B BU140 FN2296BL2329FN2329PN1388 FN2329FN2297 FN2298
08.88~05.95 3700 14B BU66 RN1265V PN1212FN2297FN2296PN1388FN2294 FN2297FN2296FN2295 FN2298
08.88~11.98 3700 14B BU66D FN2297FN2295FN2294FN2296PN1388 FN2295FN2297 FN2298
10.89~05.95 3700 14B BU72 FN2296 FN2297 FN0015
10.89~05.95 3700 14B BU72D FN2296 FN2297 FN0015
08.88~05.95 3700 14B BU87 PN1388FN2296FN2294FN2295 FN2297FN2295 FN2298
05.95~05.99 4100 15B-F BU102 FN2296 FN2297FN2296 FN2298
05.95~05.99 4100 15B-F BU132 RN1265V PN1212FN2329BL2329PN1388FN2297 FN2297FN2329 FN0015FN2298
10.96~05.99 4100 15B-F BU137 RN1840V PN1388 FN2297 FN2298
05.95~05.99 4100 15B-F# BU212 FN2296FN2329BL2329PN1388 FN2329FN2297 FN2298
05.95~05.99 4100 15BF BU102D FN2296FN2329FN2297 FN2297BL2329FN2329 FN2298
08.97~05.99 4100 15BF BU107 RN1840V PN1388PN1330 BL2329FN2297FN2329 FN2298

TOYOTA   »   Dyna 150

01.95~10.01 3000 5L-E LY212R RN1265VRN1264V PN1212 FN2297FN2275FN2286 FN2298FN0015

TOYOTA   »   DYNA 150/TOYOACE G15

05.95~05.99 2800 3L LY211 RN1265VRN1264V PN1212 FN2286FN2275FN2297 FN2298

TOYOTA   »   Dyna 200

09.84~08.88 3400 13B BU62 FN2297PN1388FN2296FN2294PN1212 FN2297FN2296FN2295
10.89~05.95 3700 14B BU87R FN2296 FN2297 FN2298

TOYOTA   »   Dyna 200 / Toyoace G25

05.95~12.03 2700 3RZ-FE RZU100 RN1265V FN2297PN1212FN2296FN2329BL2329PN1388 FN2297FN2329 FN2298
08.97~05.00 2700 3RZ-FE RZU140 RN1265V PN1212FN2297 FN2297 FN2298
08.97~05.99 3400 3B BU145 RN1840V PN1330PN1388 FN2329FN2297BL2329 FN2298
05.95~05.99 4100 15B-F BU142 RN1265V FN2296PN1212FN2297PN1388FN2329 BL2329FN2297FN2329 FN2298FN0015
10.96~05.99 4100 15B-F BU147 RN1840V PN1388PN1330 FN2297BL2329FN2329 FN2298
05.95~05.99 4100 15B-F BU162 FN2329BL2329FN2296 FN2297FN2329 FN0015
05.95~05.99 4100 15B-F BU162D FN2296 FN2297 FN0015
05.95~05.99 4100 15B-F BU172 BL2329FN2329FN2296 FN2297FN2329 FN0015

TOYOTA   »   Quick Delivery

10.96~01.01 2700 3RZ-FP RZU68VH PN1212 FN2297 FN2298
08.01~07.04 3000 5L LY270 RN1535V PN1237 FN2297FN2296 FN2298
01.86~08.90 3000 5L-E BU60VH FN2297PN1212 FN2297 FN2298
08.01~07.04 3000 5L-E LY228K RN1535V PN1237 FN2296FN2297 FN2298
05.95~01.01 3400 BU68VH PN1212 FN2297 FN2298

TOYOTA   »   ToyoAce/Dyna Urbannsuporter

08.01~07.04 3000 5L-E LY228K RN1535V PN1237 FN2296FN2297 FN2298
