ROTOR DISC » RN1535V

RN1535V

Specification

Type
Vented
Disc Thickness (Max)
28
Num. of holes
6
Height
49
Centering Diameter
100
Front/Rear
Front
Outter Ø
287
Disc Thickness (Min)
26
Pitch Circle Ø
127
Drum Ø:
154
Structure Material
G3000

Cross Reference

TOYOTA
43512-25060
TOYOTA
43512-25061
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HINO   »   DUTRO

01.11~ 4000 N04C-UV XZU700L RN1535V PN1237 FN2297

TOYOTA   »   Dyna

07.01~08.07 2000 1RZ-E RZY220 RN1535V PN1237 DN1214 FN2366FN2330FN2297FN2296FN2305 FN2298
07.01~08.03 2000 1RZ-E RZY230 RN1535V PN1237 FN2330
07.01~ 2000 1TR-FE TRY220 RN1535V PN1237 DN1214 FN2305FN2296FN2330FN2297FN2366 FN2298
08.01~ 2000 1TR-FE TRY230 RN1535V PN1237 FN2366 FN2298
12.07~ 2000 1TR-FE TRY231 RN1535V PN1237 FN2296FN2297 FN2298
12.07~ 2000 1TR-FPE TRY281 RN1535V PN1237 FN2296FN2297 FN2298
08.04~09.07 2500 2KD-FTV KDY220 RN1535V PN1237 FN2330FN2366 FN2298
07.04~09.07 2500 2KD-FTV KDY230 RN1535V PN1237 FN2297FN2366FN2305FN2296
10.01~09.07 2500 2KD-FTV KDY240V RN1535V PN1237 FN2296FN2297 FN2298
08.04~09.07 2500 2KD-FTV KDY270 RN1535V PN1237 DN1214 FN2305
08.04~09.07 2500 2KD-FTV KDY280 RN1535V PN1237 DN1214 FN2305FN2297FN2362FN2296 FN2298
08.04~09.07 2500 2KD-FTV KDY290V RN1535V PN1237 FN2296FN2297
07.01~08.03 2700 3RZ-FE LY280 RN1535V PN1237 FN2296FN2297 FN2298
07.01~08.04 2700 3RZ-FPE LY230 RN1535V PN1237 FN2330FN2297FN2362FN2296FN2305
08.03~08.07 2700 3RZ-FPE RZY231H RN1535V PN1237 FN2297FN2296 FN2298
08.03~08.07 2700 3RZ-FPE RZY281H RN1535V PN1237 FN2297FN2296 FN2298
08.21~ 2800 1GD-FTV GDY231R RN1535V PN1237 FN2296FN2366 FN2298
09.07~ 3000 1KD-FTV KDY221 RN1535V PN1237 DN1214 FN2330FN2297FN2366FN2305FN2296 FN2298
09.06~02.15 3000 1KD-FTV KDY221R RN1535V PN1237 DN1214 FN2305FN2286
07.10~ 3000 1KD-FTV KDY231 RN1535V PN1237 DN1214 FN2305FN2297FN2366FN2286FN2296 FN2298
09.07~ 3000 1KD-FTV KDY231L RN1535V PN1237 FN2286FN2296 FN2298
09.07~ 3000 1KD-FTV KDY241V RN1535V PN1237 FN2296FN2297 FN2298
01.07~ 3000 1KD-FTV KDY271 RN1535V PN1237 DN1214 FN2305
01.07~ 3000 1KD-FTV KDY281 RN1535V PN1237 DN1214 FN2362FN2305
05.99~07.01 3000 5L LY122 RN1535V PN1237 FN2286FN2362 FN2298
05.99~07.01 3000 5L LY132 RN1535V PN1237 FN2286FN2362 FN2298
05.99~07.01 3000 5L LY152 RN1535V PN1237 DN1214 FN2305FN2260
05.99~07.01 3000 5L LY162 RN1535V PN1237 DN1214DN1107 FN2260FN2280FN2276FN2305FN1179
07.01~08.04 3000 5L LY220 RN1535V PN1237 DN1214 FN2366FN2297FN2305FN2330FN2296 FN2298
06.01~08.04 3000 5L LY230 RN1535V PN1237 FN2366FN2296FN2362FN2297FN2305 FN2298
07.01~08.04 3000 5L LY240V RN1535V PN1237 FN2297FN2296 FN2298
07.01~08.04 3000 5L LY270 RN1535V PN1237 DN1214 FN2305FN2330
07.01~08.04 3000 5L LY280 RN1535V PN1237 FN2297FN2296FN2305 FN2298
07.01~08.04 3000 5L LY290V RN1535V PN1237 FN2296FN2297 FN2298

TOYOTA   »   Dyna 150

09.06~09.11 3000 1KD-FTV KDY221 RN1535V PN1237 FN2260
09.06~ 3000 1KD-FTV KDY231R RN1535V PN1237 FN2286 FN2298
07.01~ 3000 5L LY230R RN1535V FN2298 FN2296 FN2298

TOYOTA   »   DYNA 150/TOYOACE G15

10.96~07.01 2000 3Y YY121 RN1535VRN1358V PN1237 FN2275FN2286 FN2298
10.96~07.01 2000 3Y YY131 RN1358VRN1535V PN1237 FN2286FN2275 FN2300FN2298

TOYOTA   »   Dyna 350

01.09~ 3000 1KD-FTV YT54Y RN1535V PN1237 FN2296 FN2298

TOYOTA   »   Quick Delivery

08.01~07.04 3000 5L LY270 RN1535V PN1237 FN2296FN2297 FN2298
05.99~08.01 3000 5L-E LY152 RN1535V PN1237 FN2276
08.01~07.04 3000 5L-E LY228K RN1535V PN1237 FN2297FN2296 FN2298

TOYOTA   »   ToyoAce/Dyna Urbannsuporter

08.01~07.04 3000 5L-E LY228K RN1535V PN1237 FN2297FN2296 FN2298
