BRAKE SHOE » FN2276
Specification
Radius
112
Width
60
Thickness
4
Pcs In Set
4
Cross Reference
AKEBONO
NR-1047
KASHIYAMA
K2276
TOYOTA
04495-26030
TOYOTA
04495-26031
TOYOTA
04495-26170
TOYOTA
04497-26041
TOYOTA
0449726040
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.85~08.87 | 1600 | 1Y | YY50 | RN1264V | PN1212 | DN1251 | FN2275FN2276FN2260 | FN2298 |
| 08.87~09.93 | 1800 | 2Y | YY51 | RN1264V | PN1212 | DN1251 | FN2260FN2276FN2275 | FN2298 |
| 08.87~05.95 | 2400 | 2L | LY50 | RN1264V | PN1212 | FN2260FN2276 | ||
| 05.99~07.01 | 3000 | 5L | LY162 | RN1535V | PN1237 | DN1214DN1107 | FN2305FN1179FN2260FN2280FN2276 |
| 08.85~08.87 | 1600 | 1Y-J | YH80 | RN1026V | PN1166 | DN1107 | FN2276FN2260 | |
| 08.87~05.95 | 1800 | 2Y | YH81 | RN1026V | PN1166 | DN1107 | FN2276FN2260 | |
| 01.84~08.89 | 2400 | 2L | LH61V | PN1166 | FN2260FN2276 | |||
| 08.85~01.97 | 2400 | 2L | LH80 | RN1026V | PN1166 | FN2276FN2260 | ||
| 09.91~05.95 | 2400 | 2L | LH90 | RN1026V | PN1166 | DN1107 | FN2260FN2276 | |
| 08.85~05.95 | 2400 | 2RZ-E | LH90 | PN1227PN1166 | FN2260FN2276 | |||
| 01.84~05.95 | 2400 | 2RZ-E | LH90V | PN1166 | FN2276 |
