ROTOR DISC » RN1358V

RN1358V

Specification

Type
Vented
Disc Thickness (Max)
22
Num. of holes
6
Height
52
Centering Diameter
100
Front/Rear
Front
Pitch Circle Ø
127.5
Outter Ø
287
Disc Thickness (Min)
20
Drum Ø:
153.7
Structure Material
G3000

Cross Reference

TOYOTA
43512-26081
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Dyna

10.96~05.99 2800 3L LY121 RN1358V PN1237 FN2275FN2286 FN2298FN2300
10.96~05.99 2800 3L LY131 RN1358V PN1237 FN2275FN2286 FN2298

TOYOTA   »   DYNA 150/TOYOACE G15

10.96~05.99 2000 3Y YY121 RN1535VRN1358V PN1237 FN2275FN2286 FN2298
10.96~05.99 2000 3Y YY131 RN1358VRN1535V PN1237 FN2286FN2275 FN2300FN2298
10.96~05.99 2800 3L LY151 RN1358V PN1237 DN1214 FN2305
10.96~05.99 2800 3L LY161 RN1358V PN1237 DN1214 FN2305

TOYOTA   »   Hiace

01.84~12.89 2400 2L LH66LV RN1358V PN1237 DN1214 FN2305
08.86~08.89 2400 2L LH66V RN1358V PN1237 FN2305
08.87~05.95 2400 2L LH85 RN1358V PN1237 DN1214 FN2305
09.91~05.95 2400 2L LH95 RN1358V PN1237 FN2305
01.95~10.96 2800 3L LY151 RN1358V PN1237 DN1214DN1107 FN2260FN2305
04.95~10.96 2800 3L LY161 RN1358V PN1237 DN1214DN1107 FN2305FN2260

TOYOTA   »   Hiace Van

01.87~12.89 2200 4Y YH66LV RN1358V PN1237 DN1214 FN2305

TOYOTA   »   Quick Delivery

05.95~05.99 2800 3L LY151 RN1358V PN1237 FN2276
