DRUM BRAKE » DN1251

DN1251

Specification

Outter Ø
300
Num. of holes
6
Centering Diameter
90.9
Height
78
Pitch Circle Ø
139.7
Drum Ø
253.9
Structure Material
G3000
Hole Ø
14.5

Cross Reference

TOYOTA
42431-25070
TOYOTA
42431-35050
TOYOTA
42431-35060
TOYOTA
42431-35090
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   4 Runner

08.84~12.89 2400 22R-EC RN60LV- RN1005V PN1086 DN1251 FN2260

TOYOTA   »   Dyna

08.85~08.87 1600 1Y YY50 RN1264V PN1212 DN1251 FN2276FN2260FN2275 FN2298
08.87~09.93 1800 2Y YY51 RN1264V PN1212 DN1251 FN2275FN2260FN2276 FN2298
05.95~05.99 2800 3L LY201 RN1264V PN1212 DN1251 FN2275FN2260FN2286 FN2298

TOYOTA   »   DYNA 150/TOYOACE G15

05.95~07.01 2000 3Y YY201 RN1264V PN1212 DN1251 FN2275FN2286FN2260 FN2298
