ROTOR DISC » RN1607V

RN1607V

Specification

Type
Vented
Outter Ø
335
Num. of holes
5
Disc Thickness (Max)
18
Height
102.4
Centering Diameter
110
Front/Rear
Rear
Pitch Circle Ø
150
Drum Ø:
230
Disc Thickness (Min)
16.4
Structure Material
G3000

Cross Reference

TOYOTA
42431-60240
TOYOTA
42431-60241
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Land Cruiser 100

01.98~09.07 4200 1H-Z HZJ105 RN1604V PN1411 RN1607V FN2280FN1179PN1243 FN8905
01.98~09.07 4500 1FZ-FE FZJ105L RN1604V PN1411 DN1224RN1607V FN2280PN1243FN1179 FN8905
01.98~09.07 4500 1FZ-FE FZJ105R RN1604V PN1411 RN1607V FN1179FN2280PN1243 FN8905
