BRAKE SHOE » FN2335
Specification
Radius
127
Width
50
Thickness
6.8
Pcs In Set
4
Cross Reference
AKEBONO
NR-1076
AKEBONO
NR-1077
BENDIX AUS
BS1768
BENDIX AUS
BS5009
KASHIYAMA
K-2335A
KASHIYAMA
K2335
KASHIYAMA
K2411
TOYOTA
04495-0K010
TOYOTA
04495-0K030
TOYOTA
04495-0K040
TOYOTA
04495-0K060
TOYOTA
04495-0K100
TOYOTA
04495-0K110
TOYOTA
04495-28080
TOYOTA
04495-28090
TOYOTA
04495-28111
TOYOTA
04495-28120
TOYOTA
04495-28170
TOYOTA
04495-YZZZ2
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 11.96~05.99 | 2000 | 2C | CR51J | PN1405 | FN2335 | |||
| 12.98~08.02 | 2000 | 3S-FE | SR50N | PN1404PN1405 | FN2335 | |||
| 12.98~08.02 | 2200 | 3C-E | CR52J | PN1405 | FN2335 | |||
| 11.96~08.02 | 2200 | 3C-T# | CR50N | PN1405PN1404 | FN2335 |
| 01.92~12.99 | 2200 | 3C-T | CXR10G | RN1532V | PN1273 | DN1256 | FN2252FN2335 | |
| 01.92~12.99 | 2200 | 3C-T | CXR20G | RN1461VRN1070VRN1532V | PN1404PN1217PN1273 | RN1099VDN1256 | FN2252PN1274FN2335 | FN0567 |
| 01.92~08.99 | 2200 | 3C-T | CXR21G | RN1461VRN1532V | PN1217PN1273PN1404 | RN1099V | FN2252FN2335PN1274 | FN0567 |
| 08.93~09.98 | 2200 | 3C-TE | CXR11G | PN1273 | FN2252FN2335 | |||
| 01.92~12.99 | 2400 | 2TZ-FE | TCR10G | RN1532VRN1070V | PN1273PN1217PN1404 | RN1099VDN1256 | PN1274FN2252FN2335 | |
| 01.92~12.99 | 2400 | 2TZ-FE | TCR11G | RN1461VRN1070V | PN1273PN1217PN1404 | RN1099V | FN2252PN1274FN2335 | FN0567 |
| 01.92~12.99 | 2400 | 2TZ-FE | TCR20G | RN1461VRN1532VRN1070V | PN1404PN1217PN1273 | RN1099VDN1256 | PN1274FN2252FN2335 | FN0567 |
| 01.92~12.99 | 2400 | 2TZ-FE | TCR21G | RN1532VRN1070VRN1461V | PN1273PN1217PN1404 | RN1099V | FN2252FN2335PN1274 | FN0567 |
| 08.89~08.96 | 2000 | 1RZ-# | RZH112K | RN1475VRN1266V | PN1516PN1237PN1227 | FN2335FN2330FN2252 | ||
| 08.89~08.96 | 2000 | 1RZ-E | RZH112V | RN1475VRN1266V | PN1516PN1227PN1237 | DN1209 | FN2317FN2330FN2335 | |
| 08.98~08.04 | 3000 | 5L-E | LH162R | RN1478VRN1475V | PN1516PN1237PN1227 | FN2330FN2335 |
| 10.05~04.15 | 2000 | 1TR-FE | TGN10 | PN1801 | FN2335 | |||
| 02.05~12.15 | 2000 | 1TR-FE | TGN15L | RN1340VRN1627V | PN1801PN1802 | DN1203 | FN2335 | |
| 02.05~12.15 | 2000 | 1TR-FE | TGN15R | RN1942V | PN1831 | DN1203 | FN2335 | |
| 10.05~04.15 | 2500 | 2KD-FTV | KUN10 | PN1830PN1801PN1802 | FN0620FN2335 | |||
| 01.15~ | 2500 | 2KD-FTV | KUN122L | RN1319VRN2397VRN1627V | PN1803 | DN1203 | FN2402FN2335 | |
| 01.15~05.19 | 2500 | 2KD-FTV | KUN122R | RN2397VRN1627VRN1319V | PN1803 | DN1203 | FN2335FN2402 | |
| 10.05~09.16 | 2500 | 2KD-FTV | KUN15L | RN1340VRN1627V | PN1802PN1831PN1801 | DN1203 | FN2335 | |
| 08.04~09.08 | 2500 | 2KD-FTV | KUN15R | RN1340VRN1942V | PN1831PN1801 | DN1203 | FN2335 | |
| 10.05~04.15 | 2700 | 2TR-FE | TGN11L | RN1340VRN1627V | PN1802PN1801 | DN1203 | FN2335 | |
| 08.08~07.11 | 2700 | 2TR-FE | TGN16 | RN1340VRN1627V | PN1802PN1801 | DN1203 | FN2335 | |
| 07.11~04.15 | 2700 | 2TR-FE | TGN16L | RN1627V | PN1802 | DN1203 | FN2335 | |
| 08.04~02.15 | 3000 | 1KD-FTV | KUN16R | RN1627VRN1340V | PN1801PN1802 | DN1203 | FN2335 | |
| 08.04~07.11 | 3000 | 5L-E | LAN15L | RN1340VRN1942V | PN1831 | DN1203 | FN2335 | |
| 08.04~07.11 | 4000 | 1GR-FE | GGN15R | RN1340V | PN1801 | DN1203 | FN2335 |
| 08.04~07.11 | 2000 | 1TR-FE | TGN40 | PN1801PN1831 | FN2335 | |||
| 02.03~07.11 | 2000 | 1TR-FE | TGN40L | RN1340V | PN1801 | DN1204 | FN2335 | |
| 08.04~11.16 | 2000 | 1TR-FE | TGN40R | RN1627VRN1340V | PN1831PN1801PN1802 | DN1204 | FN2335 | |
| 01.05~03.16 | 2500 | 2KD-FTV | KUN40L | RN1340V | PN1801 | DN1204 | FN2335 | |
| 08.04~03.16 | 2500 | 2KD-FTV | KUN40R | RN1340VRN1942V | PN1831 | DN1204 | FN2335 | |
| 08.04~07.11 | 2500 | 2KD-FTV | TGN40 | RN1340V | PN1831 | FN2335 | ||
| 08.04~07.11 | 2700 | 2TR-FE | TGN40 | RN1340V | PN1801 | FN2335 | ||
| 07.11~10.15 | 2700 | 2TR-FE | TGN41L | RN1942V | PN1831 | DN1203 | FN2335 | |
| 08.04~07.11 | 2700 | 2TR-FE | TGN41R | RN1340V | PN1801 | FN2335 |
| 06.99~08.07 | 1800 | 7K-E | KM80 | RN1532V | PN1405PN1273 | FN2335 | ||
| 06.99~08.07 | 1800 | 7K-E | KM85 | RN1532V | PN1405PN1273 | DN1256 | FN2335 | |
| 06.99~08.04 | 2200 | 3C-E | CM80 | RN1532V | PN1405PN1273 | DN1256 | FN2335 | |
| 06.99~08.04 | 2200 | 3C-E | CM85 | RN1532V | PN1273PN1405 | FN2335 |
| 01.96~01.07 | 1800 | 7K-E | KR52V | RN1532V | PN1405 | DN1256 | FN2335 | |
| 11.96~12.98 | 2000 | 2C | CR51V | RN1532V | PN1405PN1273 | FN2335 | ||
| 10.96~08.07 | 2000 | 3S-FE | SR50G | RN1070VRN1532V | PN1405PN1404PN1273 | DN1256 | FN2335 | |
| 12.98~07.04 | 2200 | 3C-E | CR52V | RN1532V | PN1405PN1273 | FN2335 | ||
| 10.96~11.01 | 2200 | 3C-T | CR50G | RN1532V | PN1273PN1405 | FN2335 |
| 01.90~10.96 | 2400 | 2TR-FE | TCR21R | PN1217 | FN2252FN2335PN1274 | FN0567 | ||
| 01.90~12.99 | 2400 | 2TZ-FE | TCR10L | RN1461VRN1532VRN1070V | PN1217PN1273 | RN1099VDN1256 | PN1274FN2252FN2335 | FN0567 |
| 01.90~12.99 | 2400 | 2TZ-FE | TCR20L | RN1070VRN1532VRN1461V | PN1217PN1404PN1273 | DN1256RN1099V | FN2252FN2335PN1274 | FN0567 |
| 01.90~04.94 | 2400 | 2TZ-FE | TCR20R | RN1070V | PN1217PN1404PN1273 | DN1256 | FN2335PN1274FN2252 | FN0567 |
| 05.90~12.99 | 2400 | 2TZ-FE | TCR21L | PN1273PN1404 | FN2252PN1274FN2335 | FN0567 | ||
| 01.90~12.99 | 2400 | 2TZ-FZE | TCR10L | RN1070V | PN1273PN1404 | DN1256 | FN2252FN2335PN1274 | FN0567 |
