BRAKE SHOE » FN2317

FN2317

Specification

Radius
135
Width
55
Thickness
5.6
Pcs In Set
4

Cross Reference

AKEBONO
NR-1067
BENDIX AUS
BS1678
DAIHATSU
04495-87608
DAIHATSU
04495-87608-000
KASHIYAMA
K2317
TOYOTA
04047-26080
TOYOTA
04495-26130
TOYOTA
04495-26140
TOYOTA
04495-26150
TOYOTA
04495-26160
TOYOTA
04497-26080
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

DAIHATSU   »   Fourtrak

05.93~06.01 2800 DL-T F73 PN1291 FN2317
05.93~06.01 2800 DL-T F78 PN1291 FN2317

DAIHATSU   »   Rocky

01.93~12.98 2800 DL# F73 RN1343V PN1291 FN2317
01.93~12.98 2800 DL# F78 RN1343V PN1291 FN2317

DAIHATSU   »   Rugger

04.93~05.97 2800 DL-T F73# PN1291 FN2317
04.93~05.97 2800 DL-T F78RG RN1343V PN1291 FN2317

DAIHATSU   »   Wildcat

09.91~05.94 2200 PN1291 FN2317FN0022
04.84~04.93 2800 F6# PN1291 FN2317FN0022
05.93~ 2800 F6# PN1291 FN2317

TOYOTA   »   Hiace

08.89~08.93 2400 2L LH100G RN1475V PN1227 DN1209 FN2317
08.89~08.93 2400 2L LH102V RN1475V PN1227 DN1209 FN2317
08.89~08.93 2400 2RZ-E RZH113L RN1475VRN1478V PN1237PN1516PN1227 DN1209 FN2317FN2330
08.89~08.98 2800 3L LH113K RN1266VRN1475V PN1227 DN1209 FN2330FN2317

TOYOTA   »   Hiace Commuter

08.89~08.93 2000 1RZ-E RZH102L RN1475V FN2251PN1227 DN1209 FN2317FN2330
08.89~02.06 2400 2RZ RZH103R RN1475VRN1478V PN1227PN1237 DN1209 FN2317FN2330
08.89~01.00 2800 3L LH115B RN1475VRN1478V PN1227 FN2317FN2330
08.89~07.93 2800 3L LH115R RN1478VRN1475V PN1227PN1237 DN1209 FN2317FN2330
08.89~08.00 2800 3L LH125R RN1026V PN1227PN1237 FN2335FN2330FN2317FN2252

TOYOTA   »   Hiace Regius

08.89~08.93 2000 1RZ-# RZH124B RN1478VRN1266VRN1475V PN1237PN1516PN1227 FN2330FN2317
08.89~07.93 2000 1RZ-E RZH100G RN1475VRN1478V PN1227PN1516PN1237 DN1209 FN2330FN2317
08.89~08.93 2000 1RZ-E RZH102V RN1475VRN1266V PN1227PN1237PN1516 DN1209 FN2330FN2317
08.89~07.99 2000 1RZ-E RZH110G RN1475V PN1227 DN1209 FN2317
08.89~08.95 2000 1RZ-E RZH112V RN1475VRN1266V PN1227PN1237PN1516 DN1209 FN2317FN2330FN2335
08.89~08.93 2000 1RZ-E RZH122V RN1475V PN1227 DN1209 FN2317
08.89~08.93 2400 2L LH110G RN1475V PN1227 DN1209 FN2317
10.90~05.95 2400 2L LH140G RN1475VRN1026V PN1227 FN2317
01.89~01.04 2400 2L-TE LH100G RN1475V PN1227 DN1209 FN2317
10.90~08.93 2400 2L-TE LH120G RN1475V PN1227 DN1209 FN2317
08.89~08.93 2400 2RZ-E RZH101G RN1478VRN1475V PN1237PN1516PN1227 DN1209 FN2317FN2330
08.89~07.93 2800 3L LH113V RN1266VRN1475V PN1237PN1227PN1516 DN1209 FN2330FN2317
08.86~07.93 2800 3L LH123V RN1475VRN1266V PN1227PN1237PN1516 DN1209 FN2317FN2330
08.89~07.93 2800 3L LH125B RN1475VRN1478V PN1227 DN1209 FN2330FN2317

TOYOTA   »   Hiace Van

08.89~08.93 2000 1RZ-E RZH102 RN1475VRN1478V PN1237PN1227 DN1209 FN2317FN2330

TOYOTA   »   Lite/Townace Truck

10.91~07.95 2000 2C CM52 PN1217 FN2317
10.91~06.99 2000 2C CM61 PN1217 FN2317

TOYOTA   »   Liteace Truck

10.91~06.99 2000 2C CM52 PN1217 FN2317
