ROTOR DISC » RN1343V

Specification

Type
Vented
Disc Thickness (Max)
18
Num. of holes
5
Height
32.4
Centering Diameter
96
Front/Rear
Front
Pitch Circle Ø
118
Outter Ø
277
Disc Thickness (Min)
17
Drum Ø:
142

Cross Reference

BENDIX
561557B
DAIHATSU
4351287604000
DAIHATSU
4351287608000
OEM
4351287605000
TOYOTA
43512-87608
TOYOTA
4351287604
TOYOTA
4351287605
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.89~12.97 1600 HD-# F310 RN1343V PN1291 DN1432 FN0022
01.89~12.97 1600 HD-E F300 RN1343V PN1291 DN1432 FN0022
04.84~12.98 2800 DL# F70 RN1343V PN1291 FN0022
01.93~12.98 2800 DL# F73 RN1343V PN1291 FN2317
04.84~12.98 2800 DL# F75 RN1343V PN1291 FN0022
04.84~12.93 2800 DL# F77 RN1343V PN1291 FN0022
01.93~12.98 2800 DL# F78 RN1343V PN1291 FN2317
09.87~04.93 2800 DL-T F76G RN1343V PN1098PN1291 FN0022
04.93~05.97 2800 DL-T F78RG RN1343V PN1291 FN2317

Exemption from liability: the catalog data is advisory and can be used for reference only
