ROTOR DISC » RN1475V

Specification

Type

Vented

Disc Thickness (Max)

25

Num. of holes

5

Height

46.5

Centering Diameter

84

Front/Rear

Front

Pitch Circle Ø

110

Outter Ø

255

Disc Thickness (Min)

23

Drum Ø:

144.7

Structure Material

G3000

Cross Reference

TOYOTA

43512-04030

TOYOTA

43512-20090

TOYOTA

43512-26090

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

TOYOTA » Hiace

08.89~08.93	2400	2L	LH100G	RN1475V	PN1227	DN1209	FN2317
08.89~08.93	2400	2L	LH102V	RN1475V	PN1227	DN1209	FN2317
08.89~01.05	2400	2RZ-E	RZH113L	RN1478V RN1475V	PN1516 PN1227 PN1237	DN1209	FN2330 FN2317
08.93~08.99	2800	3L	LH103V	RN1475V RN1478V	PN1237 PN1227		FN2330
08.89~08.96	2800	3L	LH113K	RN1475V RN1266V	PN1227	DN1209	FN2317 FN2330

TOYOTA » Hiace Commuter

08.89~08.93	2000	1RZ-E	RZH102L	RN1475V	FN2251 PN1227	DN1209	FN2330 FN2317
08.89~08.04	2400	2L	LH102L	RN1475V RN1478V	PN1516 PN1227 PN1237 FN2251	DN1209
08.89~02.06	2400	2RZ	RZH103R	RN1475V RN1478V	PN1237 PN1227	DN1209	FN2330 FN2317
08.89~07.99	2800	3L	LH103L	RN1475V	PN1227		FN2330
08.89~01.00	2800	3L	LH115B	RN1475V RN1478V	PN1227		FN2317 FN2330
08.89~01.00	2800	3L	LH115R	RN1475V RN1478V	PN1227 PN1237	DN1209	FN2330 FN2317
08.89~02.06	3000	5L-E	LH174R	RN1475V RN1478V	PN1237 PN1516 PN1227		FN2330

TOYOTA » Hiace Regius

08.89~08.96	2000	1RZ-#	RZH112K	RN1475V RN1266V	PN1516 PN1237 PN1227		FN2330 FN2252 FN2335
08.89~08.96	2000	1RZ-#	RZH124B	RN1478V RN1266V RN1475V	PN1237 PN1516 PN1227		FN2330 FN2317
08.89~07.93	2000	1RZ-E	RZH100G	RN1475V RN1478V	PN1516 PN1237 PN1227	DN1209	FN2330 FN2317
08.89~08.96	2000	1RZ-E	RZH102V	RN1475V RN1266V	PN1227 PN1237 PN1516	DN1209	FN2330 FN2317
08.89~07.99	2000	1RZ-E	RZH110G	RN1475V	PN1227	DN1209	FN2317
08.89~08.96	2000	1RZ-E	RZH112V	RN1266V RN1475V	PN1227 PN1237 PN1516	DN1209	FN2335 FN2317 FN2330
08.89~08.93	2000	1RZ-E	RZH122V	RN1475V	PN1227	DN1209	FN2317
08.89~08.93	2400	2L	LH110G	RN1475V	PN1227	DN1209	FN2317
10.90~05.95	2400	2L	LH140G	RN1026V RN1475V	PN1227		FN2317
01.89~01.04	2400	2L-TE	LH100G	RN1475V	PN1227	DN1209	FN2317
10.90~08.93	2400	2L-TE	LH120G	RN1475V	PN1227	DN1209	FN2317
08.89~08.93	2400	2RZ-E	RZH101G	RN1478V RN1475V	PN1237 PN1516 PN1227	DN1209	FN2317 FN2330
08.89~08.96	2800	3L	LH113V	RN1475V RN1266V	PN1516 PN1237 PN1227	DN1209	FN2330 FN2317
08.86~08.96	2800	3L	LH123V	RN1266V RN1475V	PN1237 PN1227 PN1516	DN1209	FN2317 FN2330
08.89~07.96	2800	3L	LH125B	RN1475V RN1478V	PN1227	DN1209	FN2330 FN2317
08.98~08.04	3000	5L-E	LH162R	RN1478V RN1475V	PN1237 PN1227 PN1516		FN2330 FN2335

TOYOTA » Hiace Van

08.89~02.06	2000	1RZ-E	RZH102	RN1475V RN1478V	PN1227 PN1237	DN1209	FN2317 FN2330
08.89~02.06	2400	2L	LH112R	RN1478V RN1475V	PN1227 FN2251 PN1237 PN1516		FN2330
08.89~02.06	2400	2L	LH114R	RN1475V RN1478V	PN1227 PN1516 PN1237 FN2251	DN1209
08.89~08.05	2400	2RZ-E	RZH115L	RN1478V RN1475V	PN1516 PN1227 PN1237	DN1209	FN2330
08.89~09.05	2800	3L	LH113R	RN1478V RN1475V	PN1516 PN1227 PN1237 FN2251		FN2330

TOYOTA » Hilux

08.85~08.05	2400	2L	LN145R	RN1475V RN1026V	PN1830 PN1166	DN1209 DN1215	FN2330 FN2252
08.01~08.05	2500	2KD-FTV	KDN145	RN1475V	PN1830 PN1166	DN1215	FN2252
