ROTOR DISC » RN1534V

RN1534V

Specification

Type
Vented
Disc Thickness (Max)
25
Num. of holes
4
Height
43.6
Centering Diameter
74
Front/Rear
Front
Pitch Circle Ø
94
Outter Ø
230
Drum Ø:
107
Disc Thickness (Min)
23
Structure Material
G3000

Cross Reference

TOYOTA
43512-28150
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Lite/Townace

11.96~12.98 1500 5K KR41V RN1534V PN1404 DN1243 FN2339
08.90~10.96 1500 5K-J KR27V RN1534V PN1404PN1328 DN1243 FN2232
01.92~10.96 1800 2Y-J YR25V RN1534V PN1404PN1328 DN1243 FN2232
09.84~12.96 2000 2C CR27V RN1534VRN1336V PN1404PN1328 DN1243 FN2232FN2220
11.96~12.04 2200 3C-E CR42R RN1534V PN1404 DN1243 FN2339

TOYOTA   »   Lite/Townace Truck

06.99~08.07 1800 7K-E KM70 RN1534V PN1404 DN1243 FN2339
06.99~08.07 1800 7K-E KM70/KM75 RN1532VRN1534V PN1273PN1405PN1404 DN1243 FN2339
06.99~08.04 2200 3C-E CM70 RN1534V PN1404 DN1243 FN2339
06.99~08.04 2200 3C-E CM70/CM75 RN1534V PN1404 FN2339
06.99~08.04 2200 3C-E CM75 RN1534V PN1404 DN1243 FN2339

TOYOTA   »   Liteace

10.96~08.07 1800 7K-E KR42 RN1534V PN1404 DN1243 FN2339

TOYOTA   »   Liteace Noah

11.96~12.98 2000 2C CR41V RN1534V PN1404 DN1243 FN2339
10.96~12.98 2000 3S-FE SR40G RN1533VRN1534V PN1404 DN1243 FN2339
12.98~07.04 2200 3C-E CR42V RN1534V PN1404 DN1243 FN2339

TOYOTA   »   Town / Masterace

08.88~10.96 1800 2Y-J YR25V RN1534V PN1404PN1328 DN1243 FN2232

TOYOTA   »   Townace

06.99~08.07 1800 7K-E KM70/KM75 RN1534VRN1532V PN1273PN1404PN1405 FN2339FN2335
06.99~08.04 2200 3C-E CM70/CM75 RN1534V PN1404 FN2339
