ROTOR DISC » RN2397V

Specification

Type

Vented

Outter Ø

296

Num. of holes

5

Disc Thickness (Max)

30

Disc Thickness (Min)

27

Height

58.6

Centering Diameter

62

Pitch Circle Ø

114.3

Front/Rear

Front

Structure Material

G3000

Cross Reference

TOYOTA

43512-0K170

TOYOTA

43512-0K180

TOYOTA

43512-0K290

TOYOTA

43512-0K300

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

TOYOTA » Hilux

09.18~	2400	2GD-FTV	GUN120R	RN1664V RN2397V	PN1803	DN1203	FN2402
05.15~	2400	2GD-FTV	GUN122L	RN2397V RN1664V	PN1803	DN1203	FN2402
05.15~	2400	2GD-FTV	GUN122R	RN1664V RN2397V	PN1803	DN1203	FN2402
05.15~	2500	2KD-FTV	KUN112	RN2397V RN1664V	PN1803	DN1214	FN2402
01.15~	2500	2KD-FTV	KUN122L	RN1319V RN2397V RN1627V	PN1803	DN1203	FN2402 FN2335
01.15~05.19	2500	2KD-FTV	KUN122R	RN1627V RN1319V RN2397V	PN1803	DN1203	FN2335 FN2402
06.15~	2700	2TR-FE	TGN121L	RN2397V RN1664V	PN1803	DN1203	FN2402
06.15~	2700	2TR-FE	TGN121R	RN1664V RN2397V	PN1803		FN2402
05.15~05.20	2800	1GD-FTV	GUN123R	RN2397V RN1664V	PN1803	DN1203	FN2402
05.15~05.18	4000	1GRFE	GGN120R	RN2397V	PN1803	DN1203	FN2402

TOYOTA » Innova

07.16~	2000	1TR-FE	TGN140L	RN2397V	PN1803	DN1203	FN2402
11.15~	2700	2TR-FE	TGN141L	RN2397V	PN1803	DN1203	FN2402
04.16~	2800	1GD-FTV	GUN143L	RN2397V	PN1803	DN1203	FN2402
