ROTOR DISC » RN1319V
Specification
Type
Vented
Disc Thickness (Max)
25
Num. of holes
6
Height
67.3
Centering Diameter
108
Front/Rear
Front
Pitch Circle Ø
139.7
Outter Ø
297
Drum Ø:
170
Disc Thickness (Min)
23
Structure Material
G3000
Cross Reference
TOYOTA
43512-0K060
TOYOTA
43512-0K070
TOYOTA
43512-0K071
TOYOTA
43512-0K080
TOYOTA
43512-0K250
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.16~ | 2400 | 2GD-FTV | GUN155R | RN1319VRN1945V | PN1872 | RN1216VRN1553V | PN1846PN1243 | FN0642 |
| 07.15~04.21 | 2400 | 2GD-FTV | GUN165R | RN1319V | PN1872 | RN1553V | PN1243 | FN0642 |
| 03.16~ | 2400 | 2GD-FTV | GUN166R | RN1319V | PN1872 | RN1553VDN1102 | FN0620PN1846PN1243 | FN0642 |
| 01.05~04.12 | 2500 | 2KD-FTV | KUN50 | RN1319V | PN1830PN1482 | FN0620 | ||
| 01.05~04.16 | 2500 | 2KD-FTV | KUN60L | RN1664VRN1319V | PN1482PN1830PN0548 | DN1102 | FN0620 | |
| 01.05~04.16 | 2500 | 2KD-FTV | KUN60R | RN1319V | PN1830PN1482PN0548 | DN1102 | FN0620 | |
| 01.05~07.11 | 2700 | 2TR-FE | GGN60 | RN1319V | PN1482 | FN0620 | ||
| 06.06~07.11 | 2700 | 2TR-FE | KUN6 | RN1319V | PN1482 | FN0620 | ||
| 01.05~08.07 | 2700 | 2TR-FE | TGN51R | RN1319V | PN1830 | FN0620 | ||
| 01.05~10.15 | 2700 | 2TR-FE | TGN61R | RN1319V | PN1482PN1830PN0548 | FN0620 | ||
| 01.05~07.11 | 2700 | 2TR-FE | TGN65 | RN1319V | PN1482 | FN0620 | ||
| 01.05~08.08 | 3000 | 1KD-FTV | KUN51R | RN1319VRN1664V | PN1482PN1830 | FN0620 | ||
| 05.06~11.13 | 3000 | 5L-E | LAN50R | RN1319V | PN1482 | FN0620 | ||
| 02.05~12.15 | 4000 | 1GR-FE | GGN50R | RN1319V | PN1482 | FN0620 |
