ROTOR DISC » RN1218V
Specification
Type
Vented
Disc Thickness (Max)
23
Num. of holes
5
Height
47
Centering Diameter
64
Pitch Circle Ø
114.3
Front/Rear
Front
Outter Ø
282
Drum Ø:
141
Disc Thickness (Min)
21
Structure Material
G3000
Cross Reference
BENDIX
562457B
GREAT WALL
3502011XJZ08A
HONDA
45251-S7A-E10
HONDA
45251-S7A-E11
HONDA
45251-S7A-N10
HONDA
45251-S87-A00
HONDA
45251-S87-W00
HONDA
45251-SCA-E00
HONDA
45251-SDC-A00
HONDA
45251-SJH-E10
HONDA
45251-SMC-N10
HONDA
45251-SMC-N11
HONDA
45251-SMG-E31
HONDA
45251-SMG-G10
HONDA
45251-SMG-G11
HONDA
45251-SNL-T60
HONDA
45251-SNV-H00
HONDA
45251-SNV-H01
HONDA
45251-T2F-A00
HONDA
45251-T2F-A01
HONDA
45251-T6A-J00
HONDA
45251-TA0-A00
HONDA
45251-TA0-A01
HONDA
45251-TA0-A02
HONDA
45251-TA5-A00
HONDA
45251-TBA-A00
HONDA
45251-TBA-A01
HONDA
45251-TEM-M00
HONDA
45251-TET-H00
HONDA
45251-TR0-E00
HONDA
45251-TR8-M00
HONDA
45251-TSE-T10
years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
---|
10.02~12.08 | 2000 | K20A | CL7 JPN | RN1413VRN1218V | PN8465 | RN1203 | PN8398 | |
10.02~12.08 | 2000 | K20A | CL8 | RN1218V | PN8465 | RN1974 | PN8398 | |
10.02~12.08 | 2000 | K20A7 | CM4 GR | RN1218VRN1405V | PN8485PN8125PN8465 | RN1203 | PN8398PN8109 | |
01.02~01.06 | 2000 | K20A7 | CM4 RHD | RN1218V | PN8465 | RN1203 | PN8398 | |
01.06~12.08 | 2000 | K20A7 | CM4 RHD | RN1218V | PN8465 | RN1203 | PN8398 | |
06.06~12.08 | 2000 | K20Z2 | EURO | RN1218VRN1204V | PN8125PN8485 | RN1203 | PN8398PN8109 | |
02.03~11.05 | 2400 | K24A | CM5 LHD | RN1218V | PN8485 | RN1203 | PN8398 | |
11.05~12.08 | 2400 | K24A | CM5 LHD | RN1218V | PN8485PN8465 | RN1203 | PN8398 | |
01.02~12.08 | 2400 | K24A4 | CM5 RHD | RN1218V | PN8465 | RN1203 | PN8398 | |
11.05~12.08 | 2400 | K24A8 | CM5 RHD | RN1204VRN1218V | PN8465 | RN1203 | PN8398 | |
01.02~11.05 | 2400 | K24A8 | CM5 US | RN1218V | PN8485 | RN1203DN1393 | PN8398FN5524 | |
11.05~12.08 | 2400 | K24A8 | CM5 US | RN1218V | PN8485 | DN1393RN1203 | FN5524PN8398 | |
09.15~09.17 | 2400 | K24W | CR2 US | RN1418VRN1663VRN1218V | PN0647PN8485PN28005 | RN1425 | PN8864 | FN0663 |
09.12~09.15 | 2400 | K24W | CR2 US KA LX | RN1218V | PN8485 | RN1425 | PN8864 | FN0663 |
08.07~08.10 | 2400 | K24Z3 | CP2 US | RN1413VRN1218V | PN8465PN8485 | RN1409 | PN8864 | |
08.10~09.12 | 2400 | K24Z3 | CP2 US | RN1218V | PN8485 | RN1409 | PN8864 | |
09.00~01.02 | 3000 | J30A | CG1 US | RN1218V | PN8254 | RN1974 | PN8398 | |
09.97~06.03 | 3000 | J30A1 | CG1 | RN1218V | PN8254 | RN1974 | PN8398 | |
01.03~01.06 | 3000 | J30A4 | CM6 RHD | RN1413VRN1218V | PN8465 | RN1203 | PN8398 | |
11.05~11.08 | 3000 | J30A4 | CM6 US | RN1218VRN1413V | PN8465 | RN1203 | PN8398 | |
01.03~12.07 | 3000 | J30A4 | EURO | RN1218V | PN8465 | RN1203 | PN8398 |
01.02~11.05 | 2400 | K24A4 | CM7 US | RN1218V | PN8485 | RN1203 | PN8398 | |
08.10~08.12 | 2400 | K24Z3 | CS1 | RN1218V | PN8485 | RN1409 | PN8864 | |
01.98~06.03 | 3000 | J30A | CG1 US | RN1218V | PN8254 | RN1974 | PN8398 |
11.02~12.08 | 2000 | K20A | CM1 | RN1218V | PN8465 | RN2156 | PN8397 | FN0570 |
11.02~01.09 | 2400 | K24A | CM2 JPN | RN1218VRN1413V | PN8465 | RN2156 | PN8397 | FN0570 |
01.06~12.09 | 1300 | L13A7 | FK1 | RN1218V | PN8866 | RN1362 | ||
10.08~12.11 | 1400 | L13Z1 | FN4 | RN1218V | PN8866 | RN1362 | PN8867 | |
02.12~10.15 | 1400 | L13Z4 | FK1 | RN1218V | PN8465PN8484 | RN1599 | PN1840 | |
05.16~ | 1500 | L15B | FC1 JPN | RN1405VRN1218V | PN8485 | RN2157 | PN8813 | |
05.16~08.19 | 1500 | L15B | FC1 RHD | RN1405VRN1218V | PN8485 | RN2157 | PN8813 | |
03.16~07.19 | 1500 | L15C | FK7 US | RN1218V | PN8485 | RN2157 | PN8813 | |
09.21~ | 1500 | L15C8 | FE1 SDN CHINA | RN1218V | PN8811 | RN2157 | PN8813 | |
01.18~ | 1600 | N16A1 | FK9 | RN1218V | PN8485 | RN2283RN2157 | PN8813 | |
01.11~01.18 | 1600 | R16 | FB7 | RN1218V | PN8465 | RN1362 | PN8398 | |
01.05~12.08 | 1600 | R16A | FD4 RHD | RN1468VRN1218V | PN8465PN8484 | RN1362 | PN8398 | |
12.08~12.11 | 1600 | R16A | FD4 RHD | RN1468VRN1218V | PN8465PN8484 | RN1362 | PN8398 | |
09.05~12.11 | 1600 | R16A2 | FD6 | RN1218VRN1468V | PN8465PN8484 | RN1362 | PN8398FN28002 | |
01.11~01.14 | 1600 | R16B | FB1 RHD | RN1218V | PN8465 | RN1362 | PN8398 | |
01.14~09.15 | 1600 | R16B | FB1 RHD | RN1218V | PN8465 | RN1362 | PN8398 | |
01.11~01.14 | 1600 | R16B1 | FB1 LHD | RN1218V | PN8465 | RN1362 | PN8398 | |
01.12~09.15 | 1800 | R18 | NLAFB8 TR | RN1218V | PN8465 | RN1362 | PN8398 | |
09.05~01.11 | 1800 | R18A | FD1 JPN | RN1218V | PN8465 | RN1362 | PN8398 | |
09.05~12.08 | 1800 | R18A1 | FD1 RHD | RN1218V | PN8465 | RN1362 | PN8398 | |
12.08~01.12 | 1800 | R18A1 | FD1 RHD | RN1218V | PN8465 | RN1362 | PN8398 | |
09.05~12.08 | 1800 | R18A1 | JHMFD1 | RN1218VRN1468V | PN8465PN8484 | RN1362 | PN8398 | |
12.08~12.11 | 1800 | R18A1 | JHMFD1 | RN1218V | PN8465 | RN1362 | PN8398 | |
09.05~12.11 | 1800 | R18A1 | MRHFD1 | RN1468VRN1218V | PN8465PN8484 | RN1362 | PN8398 | |
09.05~01.12 | 1800 | R18A1 | PADFD1 | RN1468VRN1218V | PN8465 | RN1362 | PN8398 | |
09.05~12.11 | 1800 | R18A1 | RLHFD1 | RN1468VRN1218V | PN8465PN8484 | RN1362 | PN8398 | |
01.06~01.12 | 1800 | R18A2 | FK2 HB | RN1218V | PN8866 | RN1362 | PN8867 | |
01.06~01.12 | 1800 | R18A2 | FK2 HB RHD | RN1218V | PN8866 | RN1362 | PN8867 | |
01.06~12.08 | 1800 | R18A2 | FN1 | RN1218V | PN8866 | RN1362 | PN8867 | |
12.08~12.12 | 1800 | R18A2 | FN1 | RN1218V | PN8866 | RN1362 | PN8867 | |
01.12~01.14 | 1800 | R18Z1 | FB2 LHD 19XF | RN1218V | PN8465 | RN1362DN1388 | PN8398FN28002 | |
01.12~01.14 | 1800 | R18Z1 | FB2 LHD JHM | RN1218V | PN8465 | RN1362 | PN8398 | |
10.11~01.17 | 1800 | R18Z1 | FB2 RHD | RN1218V | PN8465 | RN1362 | PN8398 | |
05.16~08.18 | 1800 | R18Z1 | FC6 | RN1218V | PN8485 | PN8813 | ||
09.06~09.08 | 2000 | K20A | FD2 JPN | RN1218V | PN8465 | RN1362 | PN8398 | |
09.08~01.11 | 2000 | K20A | FD2 JPN | RN1218V | PN8465 | RN1362 | PN8398 | |
09.15~09.18 | 2000 | K20C2 | FC2 GL | RN1218V | PN8485 | RN2157 | PN8813 | |
03.21~ | 2000 | K20C2 | FL2 | RN1218V | PN8823 | RN2157 | PN8813 | |
09.05~12.08 | 2000 | K20Z | FD2 LHD | RN1218V | PN8465 | RN1362 | PN8398 | |
09.05~12.08 | 2000 | K20Z# | FD2 RHD | RN1218V | PN8465 | RN1362 | PN8398 | |
12.08~01.12 | 2000 | K20Z# | FD2 RHD | RN1218V | PN8465 | RN1362 | PN8398 | |
01.12~12.17 | 2000 | R20 | FB2 | RN1218V | PN8465 | RN1362 | PN8398 | |
01.12~01.14 | 2000 | R20A5 | FB3 | RN1218V | PN8465 | RN1362 | PN8398 | |
09.05~12.09 | 2200 | N22A2 | FK3 | RN1218V | PN8866 | RN1362 | PN8867 | |
09.05~01.12 | 2200 | N22A2 | FN3 | RN1218V | PN8866 | RN1362 | PN8867 |
09.15~09.18 | 1500 | L15B | FC1 | RN1218V | PN8485 | RN2157 | PN8813 | |
09.18~06.21 | 1500 | L15B | FC1 | RN1218V | PN8485 | RN2157 | PN8813 | |
11.20~ | 1500 | L15C | FE1 | RN1218VRN2227V | PN8819PN8823 | RN2157RN2470 | PN8813 | |
11.20~ | 1500 | L15C | FL1 | RN1218V | PN8823 | RN2157 | PN8813 | |
01.12~01.14 | 1800 | R18A | FB2 | RN1468VRN1218V | PN8484PN8485 | DN1388RN1362 | PN8398FN28002 | |
01.14~09.15 | 1800 | R18A | FB2 | RN1218V | PN8485 | DN1388RN1362 | PN8398FN28002 | |
11.20~ | 2000 | K20C | FE2 | RN1218V | PN8823 | RN2157 | PN8813 | |
11.20~ | 2000 | K20C | FL2 | RN1218V | PN8823 | RN2157 | PN8813 | |
09.15~09.18 | 2000 | K20C2 | FC2 US | RN1218V | PN8485 | RN2157 | PN8813 | |
09.18~06.21 | 2000 | K20C2 | FC2 US | RN1218V | PN8485 | RN2157 | PN8813 |
10.08~12.11 | 1300 | L13Z1 | FK1 | RN1218VRN1468V | PN8866PN8484 | RN1362 | PN8398PN8867 | |
09.05~12.08 | 1800 | R18A1 | FD1 LHD | RN1468VRN1218V | PN8484PN8465 | DN1388RN1362 | PN8398FN28002 | |
12.08~01.12 | 1800 | R18A1 | FD1 LHD | RN1218VRN1468V | PN8484PN8465 | RN1362 | PN8398 | |
09.05~01.09 | 1800 | R18A2 | FD7 | RN1218V | PN8465 | RN1362 | PN8398 | |
01.09~01.12 | 1800 | R18A2 | FD7 SDN LHD | RN1218V | PN8465 | RN1362 | FN28002PN8398 |
08.01~09.04 | 2000 | K20A | RD4 LHD PH | RN1218V | PN8485 | RN1460 | PN8397 | FN0570 |
09.01~08.04 | 2000 | K20A | RD5 JPN | RN1218VRN2054VRN1177V | PN8485PN8484 | RN1460 | PN8807 | FN0570 |
01.04~08.09 | 2000 | K20A4 | RD8 | RN1218VRN1177V | PN8485 | RN1259RN1460 | PN8807PN8397 | FN0570FN8003 |
09.01~01.05 | 2400 | K24A1 | RD6 | RN1218V | PN8485 | RN1460 | PN8397 | FN0570 |
09.01~09.04 | 2400 | K24A1 | RD7 | RN1218V | PN8485 | RN1460 | PN8397 | FN0570 |
07.04~12.06 | 1700 | D17A | BE2 | RN1218V | PN8465 | RN1355 | PN8397 | FN0570 |
01.04~06.12 | 2000 | K20A | BE3 | RN1218V | PN8465 | RN1355 | PN8397 | FN0570 |
07.04~08.09 | 2000 | K20A | BE4 | RN1218V | PN8465 | RN1355 | PN8397 | FN0570 |
12.06~08.09 | 2400 | K24A | BE8 | RN1218V | PN8465 | RN1355 | PN8397 | FN0570 |
04.03~07.05 | 2400 | K24A | YH2 JPN | RN1218V | PN8485 | RN2226 | PN8397 | FN0570 |
12.02~08.08 | 2400 | K24A | YH2 US | RN1218V | PN8485 | RN2226 | PN8397 | FN0570 |
08.08~05.11 | 2400 | K24A | YH2 US | RN1218V | PN8485 | RN2226 | PN8397 | FN0570 |
06.04~08.06 | 1700 | D17A2 | BE1 | RN1218V | PN8465 | RN1355 | PN8807 | FN0570 |
08.06~11.09 | 1800 | R18A1 | BE1 | RN1218V | PN8465 | RN1355 | PN8807 | FN0570 |
01.05~11.09 | 2000 | K20A9 | BE3 | RN1218V | PN8465 | RN1355 | PN8807 | FN0570 |
01.05~11.09 | 2200 | N22A1 | BE5 | RN1218V | PN8465 | RN1355 | PN8807 | FN0570 |
01.15~01.18 | 1500 | L15 | JHMRU1 RHD | RN1218V | PN28005 | RN1409 | PN8812 | |
01.18~ | 1500 | L15 | JHMRU1 RHD | RN1218V | PN28005 | RN1409 | PN8812 | |
05.22~ | 1500 | L15# | RV3 GL | RN1218V | PN28005 | RN1409 | PN8812 | |
05.22~ | 1500 | L15ZB | RV3 RHD SG | RN1218V | PN28005 | RN1409 | PN8812 |
05.15~07.20 | 1500 | L15B | FR5 JPN | RN1218V | PN8485 | RN1460 | PN8807 | FN0570 |
02.15~07.20 | 1500 | L15B | FR5 RHD | RN1218V | PN8485 | RN1460 | PN8807 | FN0570 |
02.15~07.20 | 1500 | LEB-H1 | FR4 | RN1218V | PN8485 | RN1460 | PN8807 | FN0570 |
05.15~07.20 | 1800 | R18A | FR5 | RN1218V | PN8485 | RN1460 | PN8807 | FN0570 |
10.13~ | 2400 | K24W | MRC1 | RN1418VRN1218V | PN28005 | RN1259 | PN8807 | FN8003 |
10.13~ | 2400 | K24W | RC1 JPN | RN1218V | PN28005 | RN1259 | PN8807 | FN8003 |
11.13~ | 2400 | K24W | RC2 | RN1218V | PN28005 | RN1259 | PN8807 | FN8003 |
04.15~10.21 | 1500 | L15B | RP1 | RN1218V | PN28005 | RN2156 | PN8807 | FN0570 |
04.15~10.21 | 1500 | L15B | RP2 | RN1218V | PN28005 | RN1259 | PN8807 | FN8003 |
05.05~10.09 | 2000 | K20 | RG1 JPN | RN1218V | PN8465 | RN2156 | PN8506 | FN0570 |
05.05~10.09 | 2000 | K20 | RG2 | RN1218V | PN8465 | RN2156 | PN8506 | FN0570 |
04.01~10.05 | 2000 | K20A | RF3 | RN1218V | PN8254 | RN2156 | PN8397PN8398 | FN0570 |
04.01~05.05 | 2000 | K20A | RF4 | RN1218V | PN8254 | RN2156 | PN8397 | FN0570 |
06.03~05.05 | 2000 | K20A | RF5 | RN1218V | PN8254 | RN2156 | PN8397 | FN0570 |
06.03~05.05 | 2000 | K20A | RF6 | RN1218V | PN8254 | RN2156 | PN8397 | FN0570 |
10.09~04.15 | 2000 | R20A | RK1 JPN | RN1218V | PN8485 | RN2156 | PN8807 | FN0570 |
10.09~04.15 | 2000 | R20A | RK2 | RN1218V | PN8485 | RN2156 | PN8807 | FN0570 |
10.09~04.15 | 2000 | R20A | RK3 | RN1218V | PN8485 | RN2156 | PN8807 | FN0570 |
10.09~04.15 | 2000 | R20A | RK4 | RN1218V | PN8485 | RN2156 | PN8807 | FN0570 |
10.09~04.15 | 2000 | R20A | RK5 JPN | RN1218V | PN8485 | RN2156 | PN8807 | FN0570 |
01.13~04.15 | 2000 | R20A1 | RK1 GR | RN1218V | PN8485 | RN2156 | PN8807 | FN0570 |
05.05~10.09 | 2400 | K24 | RG3 | RN1218V | PN8465 | RN2156 | PN8506 | FN0570 |
06.03~05.05 | 2400 | K24A | RF7 | RN1218V | PN8254 | RN2156 | PN8397 | FN0570 |
06.03~05.05 | 2400 | K24A | RF8 | RN1218V | PN8254 | RN2156 | PN8397 | FN0570 |
05.05~10.09 | 2400 | K24A | RG4 JPN | RN1218V | PN8465 | RN2156 | PN8506 | FN0570 |
04.15~10.21 | 1500 | L15B | RP3 JPN | RN1218V | PN28005 | RN1259 | PN8807 | FN8003 |
04.15~10.21 | 1500 | L15B | RP3 RHD | RN1218V | PN28005 | RN1259 | PN8807 | FN8003 |
04.15~10.21 | 1500 | L15B | RP4 | RN1218V | PN28005 | RN1259 | PN8807 | FN8003 |
04.12~04.15 | 2000 | R20A | RK5 GR | RN1218V | PN8485 | RN2156 | PN8807 | FN0570 |
10.09~04.15 | 2000 | R20A | RK6 | RN1218V | PN8485 | RN2156 | PN8807 | FN0570 |
10.09~04.15 | 2000 | R20A | RK7 | RN1218V | PN8485 | RN2156 | PN8807 | FN0570 |
10.00~07.06 | 1700 | D17A# | RN1 GR | RN1218VRN1468V | PN8465PN8264 | RN1355DN1380 | FN5524PN8397 | FN0570 |
10.00~07.06 | 1700 | D17A# | RN1 JPN | RN1218VRN1468V | PN8264PN8465 | RN1355DN1380 | PN8397FN5524 | FN0570 |
07.06~06.14 | 1800 | R18A | RN6 JPN | RN1218V | PN8465 | DN1379RN1460 | FN5524PN8506 | FN0570 |
07.06~05.14 | 1800 | R18A | RN7 | RN1218V | PN8465 | RN1460 | PN8506 | FN0570 |
12.05~01.15 | 1800 | R18A# | RN6 RHD | RN1218V | PN8465 | RN1460 | FN5524PN8506 | FN0570 |
10.00~07.06 | 2000 | K20A | RN3 JPN | RN1218V | PN8465 | RN1355 | PN8397 | FN0570 |
10.00~07.06 | 2000 | K20A | RN4 | RN1218V | PN8465 | RN1355 | PN8397 | FN0570 |
10.00~07.06 | 2000 | K20A1 | RN3 LHD | RN1218V | PN8465 | RN1355 | PN8397 | FN0570 |
10.00~09.03 | 2000 | K20A1 | RN3 RHD | RN1218V | PN8465 | RN1355 | PN8397 | FN0570 |
09.03~07.06 | 2000 | K20A1 | RN3 RHD | RN1218V | PN8465 | RN1355 | PN8397 | FN0570 |
12.03~07.06 | 2000 | K20B | RN5 | RN1218V | PN8465 | RN1355 | PN8397 | FN0570 |
07.06~05.14 | 2000 | R20A | RN8 | RN1218V | PN8465 | RN1460 | PN8506 | FN0570 |
07.06~05.14 | 2000 | R20A | RN9 | RN1218V | PN8465 | RN1460 | PN8506 | FN0570 |
