DRUM BRAKE » DN1379

Specification

Outter Ø
268
Num. of holes
5
Hole Ø
12.5
Centering Diameter
64.1
Height
59.7
Pitch Circle Ø
114.3
Drum Ø
220
Structure Material
G3000

Cross Reference

HONDA
42610-S70-000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
10.95~04.99 2000 B20B RD1 LHD RN1104V PN8254 DN1379 FN5524
01.97~01.01 2000 B20B RD2 JPN RN2054V PN8484 DN1379 FN5524
11.96~08.01 2000 B20B RD3 RN1104VRN1093V PN8254PN8484 DN1379 FN5524
04.99~09.01 2000 B20Z RD1 LHD RN1104V PN8254 DN1379 FN5524
04.99~09.01 2000 B20Z RD2 GR RN1104V PN8254 DN1379 FN5524
01.99~01.02 2000 B20B RD2 US RN1104V PN8254 DN1379 FN5524
07.99~12.05 1600 D16A GH3 RN1104V PN8254 DN1379 FN5524
07.99~09.05 1600 D16A GH4 JPN RN1104V PN8254 DN1379 FN5524
09.98~12.05 1600 D16W# GH# LHD RN1104V PN8254 DN1379 FN5524
09.98~12.05 1600 D16W1 GH4 LHD RN1104V PN8254 DN1379 FN5524
11.96~01.02 2000 B20B RH1 PN8254 DN1379 FN5524
11.96~01.02 2000 B20B RH2 PN8254 DN1379 FN5524
07.06~06.14 1800 R18A RN6 JPN RN1218V PN8465 DN1379RN1460 PN8506FN5524 FN0570

Exemption from liability: the catalog data is advisory and can be used for reference only
