ROTOR DISC » RN1104V
Specification
Type
Vented
Disc Thickness (Max)
23
Num. of holes
5
Height
47
Centering Diameter
70
Front/Rear
Front
Pitch Circle Ø
114.3
Outter Ø
282
Drum Ø:
148
Structure Material
G3000
Disc Thickness (Min)
21
Cross Reference
ACURA
45251SZ3E00
BENDIX
562143B
BENDIX EUR
562143B
HONDA
45251-S2H-N00
HONDA
45251-SP0-000
HONDA
45251-SZ3-000
OEM
5862030550
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 12.98~10.02 | 2300 | H23A | CH9 | RN1104V | PN8254 | RN1974 | PN8398 | |
| 06.00~10.02 | 2300 | H23A | CL2 | RN1104V | PN8254 | RN1974 | PN8398 |
| 01.99~07.03 | 2300 | F23A | TA1 | RN1104V | PN8254 | RN1460 | PN8397 | FN0570 |
| 09.99~07.03 | 3000 | J30A | TA3 | RN1104V | PN8254 | RN1460 | PN8397 | FN0570 |
| 10.95~09.01 | 2000 | B20B | RD1 JPN | RN1104VRN1093V | PN8254PN8484 | DN1387 | FN5524 | |
| 10.95~04.99 | 2000 | B20B | RD1 LHD | RN1104V | PN8254 | DN1379 | FN5524 | |
| 10.95~08.01 | 2000 | B20B | RD1 RHD | RN1104VRN1093V | PN8254PN8484 | DN1387 | FN5524 | |
| 11.96~08.01 | 2000 | B20B | RD3 | RN1104VRN1093V | PN8254PN8484 | DN1379 | FN5524 | |
| 04.99~09.01 | 2000 | B20Z | RD1 LHD | RN1104V | PN8254 | DN1379 | FN5524 | |
| 04.99~09.01 | 2000 | B20Z | RD2 GR | RN1104V | PN8254 | DN1379 | FN5524 |
| 09.98~10.03 | 1600 | D16A | GH1 JPN | RN1104V | PN8254 | DN1376 | FN5520 | |
| 09.98~12.05 | 1600 | D16A | GH2 | RN1104V | PN8254 | DN1376 | FN5520 | |
| 07.99~12.05 | 1600 | D16A | GH3 | RN1104V | PN8254 | DN1379 | FN5524 | |
| 07.99~09.05 | 1600 | D16A | GH4 JPN | RN1104V | PN8254 | DN1379 | FN5524 | |
| 09.98~12.05 | 1600 | D16W# | GH# LHD | RN1104V | PN8254 | DN1379 | FN5524 | |
| 09.98~08.01 | 1600 | D16W# | GH2 3DR LHD | RN1104V | PN8254 | DN1376 | FN5520 | |
| 09.98~08.01 | 1600 | D16W# | GH2 3DR RHD | RN1104V | PN8254 | DN1376 | FN5520 | |
| 09.98~12.05 | 1600 | D16W1 | GH4 LHD | RN1104V | PN8254 | DN1379 | FN5524 |
| 10.97~10.00 | 1800 | B18C6 | DC2 (TYPE R) LHD | RN1104V | PN8254 | PN8398 | ||
| 10.97~10.00 | 1800 | B18C7 | DC2 (TYPE R) RHD | RN1104V | PN8254 | PN8398 |
| 01.94~12.97 | 2200 | F22# | EURO | RN1104V | PN8254 | RN1383 | PN8397 | FN0570 |
| 01.94~01.99 | 2200 | F22B | RA1 | RN1104V | PN8254 | RN1383 | PN8397 | FN0570 |
| 09.94~09.97 | 2200 | F22B | RA2 | RN1104V | PN8254 | RN1383 | PN8397 | FN0570 |
| 01.98~12.99 | 2300 | F23A | EURO | RN1104V | PN8254 | RN1383 | PN8397 | FN0570 |
| 07.97~12.99 | 2300 | F23A | RA3 | RN1104V | PN8254 | RN1383 | PN8397 | FN0570 |
| 08.97~12.99 | 2300 | F23A | RA3 JPN | RN1104V | PN8254 | RN1383 | PN8397 | FN0570 |
| 07.97~12.99 | 2300 | F23A | RA4 | RN1104V | PN8254 | RN1383 | PN8397 | FN0570 |
| 10.97~01.00 | 3000 | J30A | RA5 | RN1104VRN1322V | PN8254 | RN1383 | PN8397 | FN0570 |
| 11.96~10.01 | 2200 | H22A | BB6 JPN | RN1104V | PN8254 | PN8398 | ||
| 01.96~09.00 | 2200 | H22A | BB8 JPN | RN1104V | PN8254 | PN8398 | ||
| 11.96~10.01 | 2200 | H22A# | BB8 | RN1104V | PN8254 | PN8398 | ||
| 11.96~10.01 | 2200 | H22Z2 | BB6 | RN1104V | PN8254 | PN8398 |
| 01.95~01.00 | 2200 | F22B8 | RA1 | RN1104V | PN8254 | RN1383 | PN8397 | FN0570 |
| 01.98~10.00 | 2300 | F23A7 | RA3 | RN1104V | PN8254 | RN1383 | PN8397 | FN0570 |
