BRAKE SHOE » FN28002
Specification
Radius
100
Width
30
Thickness
6
Pcs In Set
4
Cross Reference
FMSI
S913-1618
HONDA
43153-SNA-A01
HONDA
43153-SNA-A02
HONDA
43153-SNA-A03
HONDA
43153-TXA-013
HONDA
43153TXA003
KASHIYAMA
K5547
KASHIYAMA
K5547-01
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 09.08~09.13 | 1300 | L13Z1 | GM1 | RN1089V | PN8868 | DN1377RN1642 | PN8206FN28002 | |
| 10.19~ | 1500 | L15# | GN2 RHD KU | RN1089V | PN8868 | DN1389 | FN28002 | |
| 10.19~ | 1500 | L15# | GN2 RHD MA | RN1089V | PN8868 | DN1389 | FN28002 | |
| 10.19~ | 1500 | L15# | GN2 VTN | RN1089V | PN8868 | DN1389 | FN28002 | |
| 12.16~09.20 | 1500 | L15A | GM6 | RN1089V | PN8868 | DN1389 | FN28002 | |
| 09.08~09.11 | 1500 | L15A7 | GM2 LHD | RN1089V | PN8264 | DN1377 | FN28002 | |
| 09.11~01.14 | 1500 | L15A7 | GM2 LHD | RN1089V | PN8868 | DN1377 | FN28002 | |
| 09.08~09.11 | 1500 | L15A7 | GM2 RHD | RN1089V | PN8868PN8264 | DN1377RN1642 | PN8206FN5538FN28002 | |
| 01.14~ | 1500 | L15A7 | GM2 RHD PA | RN1089V | PN8868 | DN1377 | FN28002 | |
| 01.14~01.17 | 1500 | L15Z1 | GM6 LHD | RN1089V | PN8868 | DN1389 | FN28002 | |
| 01.14~01.17 | 1500 | L15Z1 | GM6 RHD | RN1089V | PN8868 | DN1389 | FN28002 | |
| 12.16~09.20 | 1500 | L15Z1 | GM6 RHD | RN1089V | PN8868 | DN1389 | FN28002 | |
| 12.16~09.20 | 1500 | L15Z1/A7 | GM6 LHD | RN1089V | PN8868 | DN1389 | FN28002 | |
| 01.17~ | 1500 | LEB-H1 | GM7 MA RHD | RN1089V | PN8868 | DN1389 | FN28002 |
| 09.05~12.11 | 1600 | R16A2 | FD6 | RN1218VRN1468V | PN8465PN8484 | RN1362 | PN8398FN28002 | |
| 01.12~01.14 | 1800 | R18Z1 | FB2 LHD 19XF | RN1218V | PN8465 | RN1362DN1388 | PN8398FN28002 |
| 01.12~01.14 | 1800 | R18A | FB2 | RN1468VRN1218V | PN8484PN8485 | DN1388RN1362 | PN8398FN28002 | |
| 01.14~09.15 | 1800 | R18A | FB2 | RN1218V | PN8485 | DN1388RN1362 | FN28002PN8398 | |
| 09.05~02.08 | 1800 | R18A1 | FA1 | RN1468V | PN8484 | DN1388RN1362 | PN8398FN28002 | |
| 02.08~01.11 | 1800 | R18A1 | FA1 | RN1468V | PN8484 | RN1362DN1388 | FN28002PN8398 |
| 09.05~12.08 | 1800 | R18A1 | JHMFD1 LHD | RN1468VRN1218V | PN8465PN8484 | RN1362DN1388 | PN8398FN28002 | |
| 01.09~01.12 | 1800 | R18A2 | FD7 SDN LHD | RN1218V | PN8465 | RN1362 | PN8398FN28002 |
| 10.07~08.13 | 1300 | L13A | GE6 | RN1089VRN1350V | PN8264PN8868PN8263 | DN1382 | FN5534PN8206FN28002 | |
| 10.07~08.13 | 1300 | L13A | GE7 | RN1089V | PN8264PN1322 | DN1377 | FN28002 | |
| 09.13~01.20 | 1300 | L13B | GK3 JPN | RN1089V | PN8868PN8815 | FN5549FN28002 | ||
| 09.13~06.17 | 1300 | L13B | GK3 RHD | RN1089V | PN8868 | FN28002 | ||
| 09.13~01.20 | 1300 | L13B | GK4 | RN1089V | PN8868 | FN28002 | ||
| 10.10~09.13 | 1300 | LDA | GP1 | RN1089V | PN8868 | DN1377 | FN28002 | |
| 10.07~08.13 | 1500 | L15A | GE8 JPN | RN1089V | PN8868PN8264 | RN1642DN1377 | FN28002PN8206 | |
| 10.07~08.13 | 1500 | L15A | GE9 | RN1089V | PN8264 | DN1377 | FN28002 | |
| 09.13~01.20 | 1500 | L15B | GK5 JPN | RN1089V | PN8868 | RN2411 | FN28002PN8206 | |
| 01.14~06.17 | 1500 | L15B | GK5 KP LHD | RN2348V | PN8868 | DN1389 | FN28002 | |
| 01.14~06.17 | 1500 | L15B | GK5 US/CND LHD | RN2348V | PN8868 | DN1389 | FN28002 | |
| 09.13~01.20 | 1500 | L15B | GK6 | RN1089V | PN8868 | FN28002 | ||
| 09.13~01.20 | 1500 | LEB-H1 | GP5 | RN1089V | PN8868 | FN28002 | ||
| 09.13~01.20 | 1500 | LEB-H1 | GP6 | RN1089V | PN8868 | FN28002 |
| 06.11~03.15 | 1300 | LDA | GP2 | RN1089V | PN8868 | DN1377 | FN28002 | |
| 06.11~03.15 | 1500 | L15A | GG7 | RN1089V | PN8868 | DN1377 | FN28002 | |
| 06.11~04.15 | 1500 | L15A | GG8 | RN1089V | PN8868 | DN1377 | FN28002 |
| 09.15~08.20 | 1500 | L15B | GM6 | RN1089V | PN8868 | FN28002 | ||
| 09.15~07.20 | 1500 | L15B | GM9 | RN1089V | PN8868 | FN28002 | ||
| 12.14~07.20 | 1500 | LEB-H1 | GM4 | RN1089V | PN8868 | FN28002 | ||
| 12.14~07.20 | 1500 | LEB-H1 | GM5 | RN1089V | PN8868 | FN28002 |
| 02.09~03.14 | 1300 | LDA | ZE2 JPN | RN1089V | PN8868 | DN1377 | FN28002 | |
| 01.10~03.14 | 1300 | LDA3 | ZE2 | RN1089V | PN8868 | RN2408DN1377 | PN8398FN28002 | |
| 11.11~04.14 | 1500 | LEA | ZE3 | RN1089V | PN8868 | DN1377 | FN28002 |
| 12.14~09.17 | 1300 | L13B | GK3 | RN1089V | PN8868 | FN28002 | ||
| 09.17~02.20 | 1300 | L13B | GK3 | RN1089V | PN8868 | FN28002 | ||
| 04.11~10.13 | 1300 | L13Z1 | GG6 | RN1089V | PN8868PN8265 | RN1642 | PN8206FN28002 | |
| 01.11~01.14 | 1300 | LDA3 | GP1 | RN1089V | PN8868 | DN1377RN2408 | FN28002PN8398 | |
| 01.12~03.14 | 1500 | L15A7 | GE9 | RN1089V | PN8868 | DN1377 | FN28002 | |
| 01.14~02.20 | 1500 | L15Z2 | GK5 GR | RN1089V | PN8868 | DN1389 | FN28002 | |
| 01.15~ | 1500 | LEB-H1 | GP# | RN1089V | PN8868 | FN28002 |
