NiBK Brakes:: Application Cross Reference and Image for NiBK : DRUM BRAKE : DN1389

DRUM BRAKE » DN1389

Specification

Outter Ø

246

Num. of holes

4

Hole Ø

12.7

Centering Diameter

61

Height

54

Pitch Circle Ø

100

Drum Ø

200

Structure Material

G3000

Cross Reference

HONDA

42610-T5G-H00

HONDA

42610-T5R-A01

HONDA

42610-T9A-T01

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

HONDA » City

10.19~	1500	L15#	GN2 RHD	RN1089V	PN8868	DN1389	FN28002
10.19~	1500	L15#	GN2 VTN	RN1089V	PN8868	DN1389	FN28002
12.16~09.20	1500	L15A	GM6	RN1089V	PN8868	DN1389	FN28002
01.14~01.17	1500	L15Z1	GM6 LHD	RN1089V	PN8868	DN1389	FN28002
01.14~01.17	1500	L15Z1	GM6 RHD	RN1089V	PN8868	DN1389	FN28002
12.16~09.20	1500	L15Z1	GM6 RHD	RN1089V	PN8868	DN1389	FN28002
12.16~09.20	1500	L15Z1/A7	GM6 LHD	RN1089V	PN8868	DN1389	FN28002
01.17~	1500	LEB-H1	GM7 MA RHD	RN1089V	PN8868	DN1389	FN28002

HONDA » Fit

01.14~06.17	1500	L15B	GK5 KP LHD	RN2348V	PN8868	DN1389	FN28002
01.14~06.17	1500	L15B	GK5 US/CND LHD	RN2348V	PN8868	DN1389	FN28002

HONDA » Jazz

01.14~02.20

1500

L15Z2

GK5 GR

RN1089V

PN8868

DN1389

FN28002

HONDA » WR-V

03.17~12.21

1500

L15Z9

GH8

RN2348V

PN8868

DN1389

FN28002

HONDA (DONGFENG) » Life

12.20~

1500

L15B5

GS2

RN1089V

PN8868

DN1389

FN28002

HONDA (GAC) » Fit

08.20~	1500	L15BU	GR9	RN1089V	PN8868	DN1389	FN28002
04.23~	1500	L15CC	GS1	RN1089V	PN8868	DN1389	FN28002
