BRAKE SHOE » FN0669
Specification
Radius
88.5
Width
47.2
Thickness
4.8
Pcs In Set
4
Cross Reference
TOYOTA
46540-22020
TOYOTA
46540-22030
TOYOTA
46540-22040
TOYOTA
46550-22040
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 04.97~06.01 | 1800 | 4S-FE | SX100 | RN1499V | PN1322PN1434 | RN1489 | PN1409 | FN0669 |
| 10.92~09.96 | 1800 | 4S-FE | SX90 | RN1499V | PN1322 | RN1489 | PN1323 | FN0669 |
| 08.96~07.01 | 2000 | 1G-FE | GX100 | RN1499V | PN1322PN1434 | RN1489 | PN1409 | FN0669 |
| 08.98~07.01 | 2000 | 1G-FE | GX105 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 10.92~09.96 | 2000 | 1G-FE | GX90 | RN1499V | PN1322 | RN1489 | PN1431PN1323 | FN0669 |
| 10.92~09.96 | 2500 | 1JZ-G## | JZX90 | RN1150VRN1305V | PN1228PN1324 | RN2029VRN1487 | PN1363PN1323 | FN0669 |
| 08.90~02.93 | 2500 | 1JZ-G#E | JZX81 | PN1246 | PN1142 | FN0669 | ||
| 08.96~06.01 | 2500 | 1JZ-GE | JZX100 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 09.96~07.01 | 2500 | 1JZ-GE | JZX105 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 10.93~09.96 | 2500 | 1JZ-GE | JZX93 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 09.96~07.01 | 2500 | 1JZ-GTE | JZX100 (TOURER V) | RN1150V | PN1228PN1324 | RN2029V | PN1421PN1409 | FN0669 |
| 09.96~07.01 | 3000 | 2JZ-GE | JZX101 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 10.93~09.96 | 3000 | 2JZ-GE | JZX91 | RN1305V | PN1228 | RN1487 | PN1323 | FN0669 |
| 01.89~12.96 | 2400 | 22R | RX81 | RN1301V | PN1246 | PN1142 | FN0669 | |
| 08.88~02.93 | 3000 | 7M-GE | MX83L | PN1246 | PN1142 | FN0669 |
| 08.98~06.01 | 2000 | 1G-FE | GX105 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 08.88~10.92 | 2000 | 1G-FE | GX81 | RN1301V | PN1246 | PN1142 | FN0669 | |
| 10.92~01.96 | 2000 | 1G-FE | GX90 | RN1499V | PN1322 | RN1489 | PN1323 | FN0669 |
| 08.88~08.90 | 2000 | 1G-GTE | GX81 | PN1246 | PN1142 | FN0669 | ||
| 09.96~07.01 | 2500 | 1JZ-GE | JZX100 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 09.96~07.01 | 2500 | 1JZ-GE | JZX105 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 08.90~10.92 | 2500 | 1JZ-GE | JZX81 | PN1246 | PN1142 | FN0669 | ||
| 10.92~09.96 | 2500 | 1JZ-GE | JZX90 | RN1305V | PN1228 | RN1487 | PN1323PN1363 | FN0669 |
| 10.93~09.96 | 2500 | 1JZ-GE | JZX93 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 09.96~07.01 | 2500 | 1JZ-GTE | JZX100 | RN1150V | PN1228PN1324 | RN2029V | PN1409PN1421 | FN0669 |
| 10.92~09.96 | 2500 | 1JZ-GTE | JZX90 | RN1150V | PN1324 | RN2029V | PN1323 | FN0669 |
| 09.96~07.01 | 3000 | 2JZ-GE | JZX101 | RN1305V | PN1228PN1322 | RN1487 | PN1363 | FN0669 |
| 08.95~09.99 | 2400 | 2L-TE | LS151H | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 08.95~08.01 | 2500 | 1JZ-GE | JZS151 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 12.95~12.01 | 3000 | 2JZ-GE | JZS155L | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 09.96~10.00 | 2000 | 1G-FE | GX100 | RN1499V | PN1322PN1434 | RN1489 | PN1409 | FN0669 |
| 08.98~01.01 | 2000 | 1G-FE | GX105 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 10.92~09.96 | 2000 | 1G-FE | GX90 | RN1499V | PN1322 | RN1489 | PN1323 | FN0669 |
| 10.92~09.96 | 2400 | 2L-TE | LX90 | RN1499V | PN1322 | RN1489 | PN1323 | FN0669 |
| 09.96~07.01 | 2500 | 1JZ-GE | JZX100 | RN1150VRN1305V | PN1324PN1228 | RN1487RN2029V | PN1363PN1421PN1409 | FN0669 |
| 09.96~10.00 | 2500 | 1JZ-GE | JZX105 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 10.92~09.96 | 2500 | 1JZ-GE | JZX90 | RN1305VRN1150V | PN1228PN1324 | RN1487RN2029V | PN1323 | FN0669 |
| 01.92~09.96 | 2500 | 1JZ-GE | JZX93 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 09.96~07.01 | 3000 | 2JZ-GE | JZX101 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
