NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1499V

ROTOR DISC » RN1499V

Specification

Type

Vented

Disc Thickness (Max)

22

Num. of holes

5

Height

50.7

Centering Diameter

62

Front/Rear

Front

Pitch Circle Ø

114.3

Outter Ø

255

Drum Ø:

141.4

Disc Thickness (Min)

20

Structure Material

G3000

Cross Reference

TOYOTA

43512 22240

TOYOTA

43512-22230

TOYOTA

43512-32220

TOYOTA

43512-32240

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

TOYOTA » Camry

07.90~06.94	1800	4S-FE	SV30	RN1499V	PN1259		FN2285
07.90~06.94	2000	2C-T	CV30	RN1499V	PN1259	RN1486	PN1321 FN2285	FN0633
07.90~06.94	2000	3S-#E	SV33	RN1499V RN1143V	PN1259 PN1260	RN1486	PN1321	FN0633
07.90~06.94	2000	3S-FE	SV32	RN1499V	PN1259	RN1486	PN1321	FN0633
07.90~06.94	2000	3S-FE	SV35	RN1499V	PN1259	RN1486	PN1321	FN0633

TOYOTA » Chaser

04.97~06.01	1800	4S-FE	SX100	RN1499V	PN1434 PN1322	RN1489	PN1409	FN0669
10.92~09.96	1800	4S-FE	SX90	RN1499V	PN1322	RN1489	PN1323	FN0669
08.96~07.01	2000	1G-FE	GX100	RN1499V	PN1322 PN1434	RN1489	PN1409	FN0669
10.92~09.96	2000	1G-FE	GX90	RN1499V	PN1322	RN1489	PN1323 PN1431	FN0669
09.96~08.99	2400	2L-TE	LX100	RN1499V	PN1322 PN1434	RN1489	PN1409

TOYOTA » Cresta

09.96~10.00	2000	1G-FE	GX100	RN1499V	PN1322 PN1434	RN1489	PN1409
10.92~01.96	2000	1G-FE	GX90	RN1499V	PN1322	RN1489	PN1323	FN0669
01.92~09.96	2400	2L-TE	LX90	RN1499V	PN1322	RN1489	PN1323

TOYOTA » Mark II

10.92~09.96	1800	4S-FE	SX90	RN1499V	PN1322	RN1489	PN1323 PN1431
09.96~10.00	2000	1G-FE	GX100	RN1499V	PN1322 PN1434	RN1489	PN1409	FN0669
10.92~09.96	2000	1G-FE	GX90	RN1499V	PN1322	RN1489	PN1323	FN0669
10.92~09.96	2400	2L-TE	LX90	RN1499V	PN1322	RN1489	PN1323	FN0669
