ROTOR DISC » RN1486

RN1486

Specification

Type
Solid
Disc Thickness (Max)
10
Num. of holes
5
Height
65
Centering Diameter
62
Front/Rear
Rear
Pitch Circle Ø
114.3
Outter Ø
269
Drum Ø:
170
Disc Thickness (Min)
9
Structure Material
G3000

Cross Reference

OEM
4243133040
TOYOTA
42431-06050
TOYOTA
42431-06090
TOYOTA
42431-32050
TOYOTA
42431-32060
TOYOTA
42431-32070
TOYOTA
42431-33010
TOYOTA
42431-33060
TOYOTA
42431-33090
TOYOTA
42431-33100
TOYOTA
4243106020
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

LEXUS   »   ES300

08.96~07.01 3000 1MZ-FE MCV20 RN1009V PN1401 RN1486 PN1321 FN0633

LEXUS   »   ES330

07.03~03.06 3300 3MZ-FE MCV31 RN1162V PN1479PN1480 RN1486 PN1458 FN0633

TOYOTA   »   Avalon

01.05~07.07 3500 2GR-FE GSX30L RN1162VRN1241V PN1480PN1521 RN1486RN1432 PN0427PN1522 FN0633

TOYOTA   »   Camry

08.01~01.06 2000 1AZ-FE ACV31L RN1009V PN1479 RN1486RN1223 PN1458 FN0633
07.90~06.94 2000 2C-T CV30 RN1499V PN1259 RN1486 FN2285PN1321 FN0633
07.90~06.94 2000 3S-#E SV33 RN1499VRN1143V PN1259PN1260 RN1486 PN1321 FN0633
07.90~06.94 2000 3S-FE SV32 RN1499V PN1259 RN1486 PN1321 FN0633
07.90~06.94 2000 3S-FE SV35 RN1499V PN1259 RN1486 PN1321 FN0633
06.91~08.98 2200 5S-FE SXV10L RN1008V PN1322 RN1486 PN1321 FN0633
06.91~01.02 2200 5S-FE SXV20L RN1009VRN1008V PN1322PN1228PN1401 RN1223RN1486 PN1321PN1431FN2333 FN0633
06.91~01.02 2200 5S-FE SXV20R RN1009VRN1008V PN1322PN1228PN1401 RN1486RN1223 PN1431PN1321 FN0633
08.01~11.06 2400 2AZ-FE ACV30L RN1009V PN1479 DN1212RN1486 PN1458FN2406FN2333 FN0633
09.01~01.06 2400 2AZ-FE ACV30R RN1009V PN1479 RN1486 PN1458 FN0633
08.02~06.06 2400 2AZ-FE ACV36 RN1009V PN0828PN1401 RN1486 PN1431PN0829 FN0633
08.93~08.96 3000 1MZ-FE MCV10 RN1009V PN1401PN1228 RN1486 PN1321 FN0633
08.96~08.01 3000 1MZ-FE MCV20L RN1009V PN1401 RN1486 PN1321 FN0633
08.02~06.06 3000 1MZ-FE MCV36 RN1009V PN1401 RN1486 PN1431 FN0633
09.91~08.96 3000 3VZ-FE VCV10L RN1009V PN1228 RN1486 PN1321 FN0633
06.91~08.96 3000 3VZ-FE VCV10R RN1009V PN1228 RN1486 PN1321 FN0633
09.03~02.06 3300 3MZ-FE MCV31L RN1162V PN1479 RN1486 PN1458

TOYOTA   »   Camry Gracia

12.96~09.01 2200 5S-FE SXV20 RN1008V PN1322 RN1486 PN1431PN1321 FN0633
12.96~09.01 2200 5S-FE SXV20W RN1008V PN1322 RN1486 PN1321PN1431 FN0633
12.96~09.01 2500 2MZ-FE MCV21 RN1009V PN1401 RN1486 PN1431PN1321

TOYOTA   »   Camry Prominent

07.90~06.92 2000 1VZ-FE VZV30 RN1143V PN1260 RN1486 PN1321 FN0633
07.90~06.92 2000 1VZ-FE VZV31 RN1143V PN1260 RN1486 PN1321 FN0633
07.90~06.92 2500 4VZ-FE VZV32 RN1143V PN1260 RN1486 PN1321 FN0633
05.91~06.94 2500 4VZ-FE VZV33 RN1143V PN1260 RN1486 PN1321 FN0633

TOYOTA   »   Mark II Wagon Qualis

04.97~12.01 2200 5S-FE SXV20W RN1008V PN1322 RN1486 PN1321PN1431 FN0633
04.97~12.01 2500 2MZ-FE MCV21W RN1009V PN1401 RN1486 PN1321PN1431 FN0633
04.97~12.01 3000 1MZ-FE MCV20W RN1009V PN1401 RN1486 PN1321 FN0633

TOYOTA   »   Scepter

11.92~08.96 2200 5S-FE SXV10 RN1008V PN1322 RN1486 PN1321 FN0633
12.92~07.96 2200 5S-FE SXV15W RN1008V PN1322 RN1486 PN1321 FN0633

TOYOTA   »   Solara coupe (USA)

07.03~08.08 2400 2AZ-FE ACV30L RN1162V PN1480 RN1486 PN0427 FN0633
06.98~07.02 3000 1MZ-FE MCV20L RN1009V PN1401 RN1486 PN1321PN0427 FN0633
07.03~12.08 3300 3MZ-FE MCV31L RN1162V PN1479PN1480 RN1486 PN0427PN1458 FN0633

TOYOTA   »   Windom

08.96~07.01 2500 2MZ-FE MCV21 RN1009V PN1401 RN1486 PN1431PN1321 FN0633
08.96~07.01 3000 1MZ-FE MCV20 RN1009V PN1401 RN1486 PN1431PN1321
07.01~02.06 3000 1MZ-FE MCV30 RN1162V PN1479PN1480 RN1486 PN1458
