ROTOR DISC » RN1305V
Specification
Type
Vented
Disc Thickness (Max)
25
Pitch Circle Ø
114.3
Front/Rear
Front
Outter Ø
275
Height
47.5
Num. of holes
5
Centering Diameter
62
Drum Ø:
143
Disc Thickness (Min)
23
Structure Material
G3000
Variation
Cross Reference
TOYOTA
43512-22220
TOYOTA
43512-22250
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 10.98~07.05 | 2000 | 1G-FE | GXE10 | RN1305VRN1150V | PN1324PN1550PN1228 | RN1485RN1225 | PN1421 | FN0692 |
| 06.01~07.05 | 2000 | 1G-FE | GXE10W | RN1305VRN1150V | PN1550PN1324 | RN1485RN1225 | PN1421 | FN0692 |
| 01.02~07.05 | 2000 | 1G-FE | GXE15W | RN1150VRN1305V | PN1228PN1324 | RN1225RN1485 | PN1421 | FN0692 |
| 10.98~07.05 | 2000 | 3S-GE | SXE10 | RN1150VRN1305V | PN1324PN1550 | RN1485RN1225 | PN1421 | FN0567 |
| 06.01~02.02 | 3000 | 2JZ-GE | JCE15W | RN1150VRN1305V | PN1324 | RN1225 | PN1421 | FN0567 |
| 05.01~06.07 | 2500 | 1JZ-FSE | JCG10 | RN1305V | PN1550 | RN1485 | PN1421 | FN0692 |
| 01.01~06.07 | 2500 | 1JZ-FSE | JCG15 | RN1305V | PN1228 | RN1485 | PN1421 | FN0692 |
| 05.01~06.07 | 3000 | 2JZ-FSE | JCG11 | RN1305V | PN1550 | RN1485 | PN1421 | FN0692 |
| 08.98~07.01 | 2000 | 1G-FE | GX105 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 10.92~09.96 | 2400 | 2L-TE | LX90 | RN1305V | PN1322 | RN1487 | PN1323 | |
| 10.92~09.96 | 2500 | 1JZ-G## | JZX90 | RN1150VRN1305V | PN1324PN1228 | RN2029VRN1487 | PN1323PN1363 | FN0669 |
| 08.96~06.01 | 2500 | 1JZ-GE | JZX100 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 09.96~07.01 | 2500 | 1JZ-GE | JZX105 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 10.93~09.96 | 2500 | 1JZ-GE | JZX93 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 09.96~07.01 | 3000 | 2JZ-GE | JZX101 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 10.93~09.96 | 3000 | 2JZ-GE | JZX91 | RN1305V | PN1228 | RN1487 | PN1323 | FN0669 |
| 08.98~06.01 | 2000 | 1G-FE | GX105 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 09.96~07.01 | 2500 | 1JZ-GE | JZX100 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 09.96~07.01 | 2500 | 1JZ-GE | JZX105 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 10.92~09.96 | 2500 | 1JZ-GE | JZX90 | RN1305V | PN1228 | RN1487 | PN1363PN1323 | FN0669 |
| 10.93~09.96 | 2500 | 1JZ-GE | JZX93 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 09.96~07.01 | 3000 | 2JZ-GE | JZX101 | RN1305V | PN1322PN1228 | RN1487 | PN1363 | FN0669 |
| 08.95~12.01 | 2000 | 1G-FE | GS151H | RN1305V | PN1228 | RN1487 | PN1363 | |
| 08.95~09.99 | 2400 | 2L-TE | LS151H | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 08.95~08.01 | 2500 | 1JZ-GE | JZS151 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 09.99~06.07 | 3000 | 2JZ-FSE | JZS175W | RN1305V | PN1550 | RN1485 | PN1421 | |
| 12.95~12.01 | 3000 | 2JZ-GE | JZS155L | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 01.00~12.03 | 3000 | 2JZ-GE | JZS175R | RN1305V | PN1550 | RN1485 | PN1421 | FN0692 |
| 09.99~12.03 | 3000 | 2JZ-GE | JZS179 | RN1305V | PN1228 | RN1485 | PN1421 | FN0692 |
| 09.99~12.03 | 2500 | 1JZ-G## | JZS171 | RN1305VRN1150V | PN1324PN1550 | RN1485RN1225 | PN1421 | FN0567FN0692 |
| 01.99~01.04 | 2500 | 1JZ-GE | JZS173 | RN1305V | PN1228 | RN1485 | PN1421 | FN0692 |
| 12.99~06.07 | 2500 | 1JZ-GE | JZS173W | RN1305V | PN1228 | RN1485 | PN1421 | FN0692 |
| 09.99~12.03 | 3000 | 2JZ-FSE | JZS175 | RN1305V | PN1550 | RN1485 | PN1421 | FN0692 |
| 01.95~12.01 | 3000 | 2JZ-GE | JZS155 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 08.98~01.01 | 2000 | 1G-FE | GX105 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 10.00~06.07 | 2000 | 1G-FE | GX110 | RN1305V | PN1550 | RN1485 | PN1421 | FN0692 |
| 10.00~06.07 | 2000 | 1G-FE | GX115 | RN1305V | PN1228 | RN1485 | PN1421 | FN0692 |
| 10.00~11.04 | 2500 | 1JZ-FSE | JZX110 | RN1305V | PN1550 | RN1485 | PN1421 | FN0692 |
| 09.96~07.01 | 2500 | 1JZ-GE | JZX100 | RN1305VRN1150V | PN1228PN1324 | RN1487RN2029V | PN1409PN1363PN1421 | FN0669 |
| 09.96~10.00 | 2500 | 1JZ-GE | JZX105 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 10.92~09.96 | 2500 | 1JZ-GE | JZX90 | RN1305VRN1150V | PN1228PN1324 | RN1487RN2029V | PN1323 | FN0669 |
| 01.92~09.96 | 2500 | 1JZ-GE | JZX93 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
| 10.92~09.95 | 3000 | JZX91 | RN1305V | PN1228 | RN1487 | PN1363PN1323 | ||
| 09.96~07.01 | 3000 | 2JZ-GE | JZX101 | RN1305V | PN1228 | RN1487 | PN1363 | FN0669 |
