BRAKE SHOE » FN8003

FN8003

Specification

Radius
99
Width
35
Thickness
4.5
Pcs In Set
4

Cross Reference

DONGFENG
4626002
GREAT WALL
3502710XKZ16A
HAVAL
3502710XKZ16A
HONDA
43053-S9A-E50
HONDA
43053-S9A-E51
HONDA
43053-S9A-E52
HONDA
43053-S9A-E53
HONDA
43053-SWW-000
HONDA
43053-SWW-010
HONDA
43053-T1G-G00
HONDA
43154-S9A-E03
HONDA
43154-SFE-J01
HONDA
43154-SFE-J02
HONDA
43154-STK-A01
HONDA
43154-SWA-003
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

ACURA   »   CDX

05.16~ 1500 L15B9 RH4 RN2227V PN0647 RN1603 PN8807 FN8003

ACURA   »   RDX

04.06~03.12 2300 K23A1 TB1 RN1415V PN8802 RN1259 PN8397 FN8003
04.12~04.18 3500 J35Z2 TB3 RN1663V PN0647 RN1259 PN8807 FN8003
04.12~04.18 3500 J35Z2 TB4 RN1663V PN0647 RN1259 PN8807 FN8003

DONGFENG   »   AX7

04.14~10.20 2000 EW10A D02 PN8802 PN8397 FN8003

Great Wall Motors   »   Hover H6

08.11~12.14 2000 GW4D20 H6 RN1415V PN8802 RN2492 PN8397 FN8003

HAVAL   »   H6

09.14~ 1500 GW4G15 H6 RN1415VRN2556V PN8802 RN2492 PN8397PN8813 FN8003
09.14~ 2000 GW4D20 H6 RN1415V PN8802 RN2492 PN8397 FN8003

HONDA   »   CR-V

11.11~10.14 1600 N16A1 RE6 RN1243V PN8808 RN1618 PN8809 FN8003
10.14~08.18 1600 N16A1 RE6 RN2353V PN8802 RN1618 PN8809 FN8003
11.01~11.04 2000 K20A RD5 RHD RN2054VRN1177V PN8484PN8485 RN1460 PN8807PN8397 FN0570FN8003
11.04~04.07 2000 K20A RD5 RHD RN2054VRN1177V PN8485PN8484 RN1460RN1259 PN8397PN8807 FN0570FN8003
01.04~08.09 2000 K20A4 RD8 RN1177VRN1218V PN8485 RN1259RN1460 PN8397PN8807 FN8003FN0570
01.07~01.11 2000 R20A RE1 RN1415V PN8802 RN1259 PN8807PN8398 FN8003
01.06~09.09 2000 R20A RE2 RN1415V PN8802 RN1259 PN8807PN8398 FN8003
09.09~08.12 2000 R20A RE2 RN1415V PN8802 RN1259 PN8807PN8398 FN8003
10.11~01.19 2000 R20A RM1 JPN RN1415V PN8802 RN1259 PN8807 FN8003
10.11~01.19 2000 R20A RM1 RHD RN1415VRN1243V PN8802 RN1259 PN8807 FN8003
08.12~12.18 2000 R20A# RE5 LHD RN1243V PN8808 RN1618 PN8809 FN8003
10.06~09.09 2000 R20A2 RE5 LHD RN1243V PN8808 RN1618 PN8809 FN8003
09.09~08.12 2000 R20A2 RE5 LHD RN1243V PN8808 RN1618 PN8809 FN8003
10.06~09.09 2000 R20A2 RE5 RHD RN1243V PN8808 RN1618 PN8809 FN8003
09.09~08.12 2000 R20A2 RE5 RHD RN1243V PN8808 RN1618 PN8809 FN8003
10.11~01.19 2000 R20A5 RM1 LHD PH RN1415V PN8802 RN1259 PN8807 FN8003
12.11~10.14 2000 R20A5 RM2 RHD RN1415V PN8802 RN1259 PN8807 FN8003
10.14~01.19 2000 R20A5 RM2 RHD RN1243V PN8802 RN1259 PN8807 FN8003
10.14~01.19 2000 R20A5 RM6 MEX RN1415V PN8802 RN1259 PN8807 FN8003
01.10~01.11 2200 N22A1 RE6 RN1243V PN8808 RN1618RN1259 PN8809 FN8003
11.04~01.07 2200 N22A2 RD9 RN1177V PN8485 RN1259 PN8807 FN8003
10.06~09.09 2200 N22A2 RE6 RN1243V PN8808 RN1618 PN8809 FN8003
09.09~12.12 2200 N22B3 RE6 RN1243V PN8808 RN1618 PN8809 FN8003
09.11~09.16 2400 K24 RM3 RN1415V PN8802 RN1259RN1618 PN8807 FN8003
12.11~08.15 2400 K24 RM4 RHD RN1415V PN8802 RN1259 PN8807 FN8003
09.04~09.06 2400 K24A RD6 JPN RN1177V PN8485 RN1259 PN8807 FN8003
09.04~10.06 2400 K24A RD7 JPN RN1177V PN8485 RN1259 PN8807 FN8003
10.06~11.11 2400 K24A RE3 JPN RN1415V PN8802 RN1259 PN8807 FN8003
10.06~11.11 2400 K24A RE4 JPN RN1415V PN8802 RN1259 PN8807 FN8003
12.11~09.16 2400 K24A RM4 JPN RN1415V PN8802 RN1259 PN8807 FN8003
08.11~08.15 2400 K24A RM4 LHD RN1415V PN8802 RN1259 PN8807 FN8003
11.04~12.06 2400 K24A1 RD6 RN1177V PN8485 RN1259 PN8807 FN8003
09.04~09.06 2400 K24A1 RD7 RN1177V PN8485 RN1259 PN8807 FN8003
10.14~10.16 2400 K24W RM3 LHD KY RN1415V PN8802 RN1259 PN8807 FN8003
03.07~03.13 2400 K24Z RE3 RN1415V PN8802 RN1259 PN8807 FN8003
09.09~08.12 2400 K24Z RE4 RN1415V PN8802 RN1259 PN8807 FN8003
09.06~09.09 2400 K24Z RE4 CHN LHD RN1415V PN8802 RN1603 PN8807 FN8003
12.11~10.14 2400 K24Z RM3 LHD KK RN1415V PN8802 RN1259 PN8807 FN8003
12.11~10.14 2400 K24Z RM3 RHD KU RN1415V PN8802 RN1259 PN8807 FN8003
12.13~10.16 2400 K24Z RM3 RHD KU RN1243V PN8802 RN1259 PN8807 FN8003
09.06~09.09 2400 K24Z1 RE4 RN1415V PN8802 RN1259 PN8807 FN8003
03.07~03.10 2400 K24Z4 RE7 LHD RN1243V PN8808 RN1618 PN8809 FN8003
03.10~08.12 2400 K24Z4 RE7 LHD RN1243V PN8808 RN1618 PN8809 FN8003
03.10~08.12 2400 K24Z4 RE7 RHD RN1243V PN8808 RN1618 PN8809 FN8003
06.15~12.18 2400 K24Z9 MAKRM4 RHD KU RN1243V PN8802 RN1259 PN8807 FN8003
09.12~01.21 2400 K24Z9 RM3 VTN RN1415V PN8802 RN1259RN1618 PN8807 FN8003
06.15~12.18 2400 K24Z9 RM4 RHD RN1243V PN8802 RN1259 PN8807 FN8003

HONDA   »   CR-V (USA)

12.11~10.14 2400 K24 RM4 US RN1415V PN8802 RN1259 PN8807 FN8003
10.14~10.16 2400 K24 RM4 US RN1415V PN8802 RN1259 PN8807 FN8003
09.04~01.07 2400 K24A1 RD7 RN1177V PN8485 RN1259 PN8807 FN8003
10.06~09.09 2400 K24Z RE3 RN1415V PN8802 RN1259 PN8807 FN8003
09.09~01.12 2400 K24Z RE3 RN1415V PN8802 RN1259 PN8807 FN8003
09.06~09.09 2400 K24Z RE4 RN1415V PN8802 RN1259 PN8807 FN8003
09.09~12.11 2400 K24Z RE4 RN1415V PN8802 RN1259 PN8807 FN8003
12.11~10.14 2400 K24Z7 RM3 US KA, KK RN1415V PN8802PN8485 RN1259 PN8807 FN8003

HONDA   »   Elysion

05.04~06.12 2400 K24A RR1 RN2091V PN2389 RN1383 PN8506 FN8003
05.04~11.13 2400 K24A RR2 RN2091V PN2389 RN1383 PN8506 FN8003
05.04~06.12 3000 J30A RR3 RN2091V PN2389 RN1383 PN8506 FN8003
05.04~10.13 3000 J30A RR4 RN2091V PN2389 RN1383 PN8506 FN8003
01.07~10.13 3500 J35A RR6 RN2091V PN2389 RN1383 PN8506 FN8003

HONDA   »   Odyssey

02.16~ 2000 LFA RC4 JPH RN1418V PN28005 RN1259 PN8807 FN8003
10.03~10.08 2400 K24A RB1 RN1540VRN1322V PN8465 RN1383 PN8506 FN8003
10.03~10.08 2400 K24A RB2 JPN RN1322V PN8465 RN1383 PN8506 FN8003
10.08~10.13 2400 K24A RB3 RN1540VRN1322V PN8465 RN1383 PN8506 FN8003
10.08~10.13 2400 K24A RB4 JPN RN1322V PN8465 RN1383 PN8506 FN8003
10.13~ 2400 K24W MRC1 RN1418VRN1218V PN28005 RN1259 PN8807 FN8003
10.13~ 2400 K24W RC1 JPN RN1218V PN28005 RN1259 PN8807 FN8003
10.17~10.20 2400 K24W RC1 LHD RN1418V PN28005 RN1259 PN8807 FN8003
02.14~01.18 2400 K24W RC1 RHD RN1418V PN28005 RN1259 PN8807 FN8003
11.13~ 2400 K24W RC2 RN1218V PN28005 RN1259 PN8807 FN8003
10.08~10.13 2400 K24Z RB3 RN1322V PN8465 RN1383 PN8506 FN8003

HONDA   »   Stepwgn

04.15~10.21 1500 L15B RP2 RN1218V PN28005 RN1259 PN8807 FN8003

HONDA   »   Stepwgn Spada

04.15~10.21 1500 L15B RP3 JPN RN1218V PN28005 RN1259 PN8807 FN8003
04.15~10.21 1500 L15B RP3 RHD RN1218V PN28005 RN1259 PN8807 FN8003
04.15~10.21 1500 L15B RP4 RN1218V PN28005 RN1259 PN8807 FN8003
