ROTOR DISC » RN2492

Specification

Type
Solid
Outter Ø
305
Num. of holes
5
Disc Thickness (Max)
10
Disc Thickness (Min)
8.5
Height
61
Centering Diameter
64
Pitch Circle Ø
114.3
Drum Ø:
200
Front/Rear
Rear
Structure Material
G3000

Alternative

RN1603[NiBK]

Cross Reference

GREAT WALL
3502012XKZ16A
HAVAL
3502012XKZ16A
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
08.11~12.14 2000 GW4D20 H6 RN1415V PN8802 RN2492 PN8397 FN8003
09.14~ 1500 GW4G15 H6 RN1415VRN2556V PN8802 RN2492 PN8813PN8397 FN8003
09.14~ 2000 GW4D20 H6 RN1415V PN8802 RN2492 PN8397 FN8003

Exemption from liability: the catalog data is advisory and can be used for reference only
