NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2227V

Product
Application

ROTOR DISC » RN2227V

Specification

Type

Vented

Outter Ø

312

Num. of holes

5

Disc Thickness (Max)

25

Disc Thickness (Min)

23

Height

47.2

Centering Diameter

64.1

Pitch Circle Ø

114.3

Front/Rear

Front

Structure Material

G3000

Drum Ø:

154

Hole Ø:

12.5

Cross Reference

HONDA

45251-3W0-A01

HONDA

45251-TLA-A00

HONDA

45251-TNY-A00

HONDA

45251-TRN-H00

HONDA

45251-TVC-A00

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

ACURA » CDX

05.16~

1500

L15B9

RH4

RN2227V

PN0647

RN1603

PN8807

FN8003

ACURA » Integra

06.22~

1500

L15CA

DE4

RN2227V

PN8819

RN2470

PN8813

HONDA » Accord

07.17~10.20	1500	L15BE	CV1 US	RN2227V RN1418V	PN8819 PN28005	RN1409	PN8822
10.17~	2000	K20C4	CV2	RN2227V	PN8819	RN1409	PN8822
10.18~	2000	LFA-H4	CV3	RN2227V	PN8819	RN1409	PN8822 PN8828
09.22~	2000	LFC5	CY2 US	RN2227V	PN8819	RN1409	PN8813

HONDA » Civic (USA)

11.20~

1500

L15C

FE1

RN2227V RN1218V

PN8823 PN8819

RN2157 RN2470

PN8813

HONDA » CR-V

10.16~09.19	1500	L15B#	RW1 VTN	RN2227V	PN8818	RN2228	PN8817
09.19~03.22	1500	L15B#	RW2 KH LHD	RN2227V	PN8818 PN0647	RN2228	PN8817
08.17~12.20	2000	R20A9	RW4 LHD	RN2227V	PN8818	RN2228	PN8817
10.16~	2400	K24W9	RW5	RN2227V	PN8818	RN2228	PN8817 PN8807
10.16~	2400	K24W9	RW6	RN2227V	PN8818	RN2228	PN8817
01.16~	2400	K24Z	RW3	RN2227V	PN8818	RN2228	PN8817

HONDA » CR-V (USA)

10.16~09.19	1500	L15B7	RW1 KA	RN2227V	PN8818	RN2228	PN8817
09.19~02.23	1500	L15B7	RW1 KK	RN2227V	PN8818	RN2228	PN8817
09.19~	1500	L15B7	RW2 US/CND	RN2227V	PN8818	RN2228	PN8817
09.22~	1500	L15BE	RS4	RN2227V	PN8818	RN2228	PN8817

HONDA » E:NY1

03.23~

MCF62

RS1

RN2227V

PN8818

RN1409

PN8812

HONDA » HR-V

06.22~	2000	K20#	RZ2H US/CND	RN2227V	PN8818		PN8828
08.22~	2000	K20C2	RZ1	RN2227V	PN8818		PN8828

HONDA » ZR-V

07.22~

1500

L15CD

RZ3 CN

RN2227V

PN8818

RN2228

PN8828
