PERFORMANCE ROTOR DISC » RN1150DSET

Specification

Outter Ø
296
Num. of holes
10
Disc Thickness (Max)
32
Height
50.7
Centering Diameter
62.3
Pitch Circle Ø
114.3
Front/Rear
Front
Type 1:
Vented
Drum Ø:
143
Structure Material
GG20
Disc Thickness (Min)
30

Variation

RN1150V[NiBK]

Cross Reference

BENDIX
561644B
LEXUS
43512-30180
LEXUS
43512-53020
LEXUS
4351250100
LEXUS
4351250120
OEM
4351250040
OEM
4351250060
TOYOTA
43512-14190
TOYOTA
43512-24051
TOYOTA
43512-30180
TOYOTA
43512-30181
TOYOTA
43512-30190
TOYOTA
43512-30240
TOYOTA
43512-30241
TOYOTA
43512-30300
TOYOTA
43512-50060
TOYOTA
43512-50100
TOYOTA
43512-50110
TOYOTA
43512-50112
TOYOTA
43512-53010
TOYOTA
43512-53020
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
03.93~08.97 3000 2JZ-GE JZS147 RN1150V PN1324 RN1488V PN1363 FN0567
08.97~01.05 3000 2JZ-GE JZS160L RN1150V PN1324 RN1225 PN1421 FN0567
08.97~07.00 4000 1UZ-FE UZS160 RN1150V PN1324 RN1225 PN1421 FN0567
07.00~01.05 4300 3UZ-FE UZS161 RN1150V PN1324 RN1225 PN1421 FN0567
01.99~07.05 2000 1G-FE GXE10 RN1150V PN1324 RN1225 PN1421 FN0567
05.00~07.05 3000 2JZ-GE JCE10 RN1150V PN1324 RN1225 PN1421 FN0567
05.00~07.05 3000 2JZGE JCE10L RN1150V PN1324 RN1225 PN1421 FN0567
07.01~07.05 3000 2JZGE JCE10R RN1150V PN1324 RN1225 PN1421 FN0567
05.89~10.94 4000 1UZ-FE UCF10 RN1150V PN1324 RN1488V PN1326 FN0567
01.01~07.10 4300 3UZ-FE UZZ40 RN1150V PN1324 RN1225 PN1421 FN0567
10.98~07.05 2000 1G-FE GXE10 RN1150VRN1305V PN1550PN1228PN1324 RN1485RN1225 PN1421 FN0692
06.01~07.05 2000 1G-FE GXE10W RN1305VRN1150V PN1324PN1550 RN1485RN1225 PN1421 FN0692
01.02~07.05 2000 1G-FE GXE15W RN1150VRN1305V PN1228PN1324 RN1485RN1225 PN1421 FN0692
10.98~07.05 2000 3S-GE SXE10 RN1150VRN1305V PN1550PN1324 RN1485RN1225 PN1421 FN0567
06.01~07.05 3000 2JZ-GE JCE10W RN1150V PN1324 RN1225 PN1421 FN0567
06.01~07.05 3000 2JZ-GE JCE15W RN1305VRN1150V PN1324 RN1225 PN1421 FN0567
10.91~08.97 3000 2JZ-G#E JZS147 RN1531VRN1150V PN1231PN1324PN1228 RN1488V PN1363 FN0567
01.97~01.05 3000 2JZ-GE JZS160 RN1150V PN1324 RN1225 PN1421
10.91~08.97 3000 2JZ-GTE JZS147 RN1150V PN1231PN1324 RN1488V PN1363
08.97~01.05 3000 2JZ-GTE JZS161 RN1150V PN1324 RN1225 PN1421 FN0567
11.89~10.94 4000 1UZ-FE UCF10 RN1150V PN1228PN1324 PN1326PN1363PN1252
11.89~10.94 4000 1UZ-FE UCF11 RN1150V PN1324PN1228 RN1488V PN1326PN1252
10.92~09.96 2500 1JZ-G## JZX90 RN1150VRN1305V PN1228PN1324 RN1487RN2029V PN1323PN1363 FN0669
09.96~07.01 2500 1JZ-GTE JZX100 (TOURER V) RN1150V PN1324PN1228 RN2029V PN1409PN1421 FN0669
09.96~07.01 2500 1JZ-GTE JZX100 RN1150V PN1228PN1324 RN2029V PN1421PN1409 FN0669
10.92~09.96 2500 1JZ-GTE JZX90 RN1150V PN1324 RN2029V PN1323 FN0669
09.99~07.04 4000 1UZ-FE UZS173 RN1150V PN1324 RN1225 PN1421 FN0567
09.99~12.03 2500 1JZ-G## JZS171 RN1305VRN1150V PN1324PN1550 RN1225RN1485 PN1421 FN0692FN0567
01.95~01.01 4000 1UZ-FE UZS155 RN1150V PN1324 RN1488V PN1363
01.00~06.07 2500 1JZ-##E JZX110 RN1150VRN1305V PN1324PN1550 RN1485RN1225 PN1421 FN0567
05.91~01.94 2500 1JZ-GTE JZZ30 RN1150V PN1231 RN1488V PN1363 FN0567
07.01~04.04 2500 1JZ-##E JZX110 RN1150VRN1305V PN1550PN1324 RN1485RN1225 PN1421 FN0692FN0567

Exemption from liability: the catalog data is advisory and can be used for reference only
