BRAKE SHOE » FN9801
Specification
Radius
110
Width
35
Thickness
6
Pcs In Set
4
Cross Reference
FMSI
S954-1641
KASHIYAMA
K9003
KASHIYAMA
K9983
MARUTI
53200M55K00
MARUTI
53200M55K10
SUZUKI
53200-80J00
SUZUKI
53200-80J01
SUZUKI
53200-80J02
SUZUKI
53200M55K10
SUZUKI
53200M55K10-000
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 04.12~10.15 | 1300 | D13A | RN2449V | PN5562 | FN9801 | |||
| 10.15~ | 1300 | D13A | RN2449V | PN5562 | FN9801 | |||
| 04.12~10.15 | 1400 | K14B | RN2449V | PN5562 | FN9801 |
| 02.11~02.13 | 1300 | D13A | PN2201 | FN9801 | ||||
| 05.07~09.09 | 1600 | M16A | PN2201 | FN9801 | ||||
| 09.09~02.13 | 1600 | M16A | PN2201 | FN9801 | ||||
| 08.10~02.13 | 1600 | M16A | PN2201 | FN9801 |
| 03.12~04.18 | 1400 | K14B | YZE81S LHD | RN2449V | PN5544 | FN9801 | ||
| 03.12~04.18 | 1400 | K14B | ZE81S LHD | RN2449V | PN5562 | FN9801 | ||
| 03.12~04.18 | 1400 | K14B | ZE81S RHD | RN2449V | PN5562 | FN9801 | ||
| 03.19~ | 1500 | K15B | R3 | PN9814 | FN9801 |
| 06.06~12.15 | 1500 | M15A | RW415 | PN2201 | PN8398FN9801 | |||
| 05.06~ | 1500 | M15A | YA11S | RN1320V | PN2201 | DN1372 | FN9801 | |
| 05.06~10.14 | 1500 | M15A | YB11S | RN1320V | PN2201 | DN1372 | FN9801 | |
| 06.07~ | 1500 | M15A | YC11S | RN1320V | PN2201 | DN1372 | FN9801 | |
| 07.06~03.16 | 1600 | M16A | GYA21S | RN1320V | PN2201 | RN1524RN1755DN1372 | FN9801PN8398 | |
| 06.06~12.15 | 1600 | M16A | GYC21S SDN | RN1320V | PN2201 | RN1755RN1524DN1372 | PN8398FN9801 | |
| 11.11~12.15 | 1600 | M16A | RW416-6 RHD | RN1320V | PN2201 | RN1524 | PN8398FN9801 | |
| 06.06~01.10 | 2000 | J20A | JS2YA4 | RN1320V | PN2201 | RN1524 | FN9801PN8398 | |
| 04.07~07.12 | 2000 | J20A | JS2YC4 SDN | RN1320V | PN2201 | RN1524DN1372 | PN8398FN9801 | |
| 07.09~04.14 | 2000 | J20B | JS2YC5 SDN | RN1320V | PN2201 | RN1524DN1372 | PN8398FN9801 | |
| 01.10~06.12 | 2000 | J20B | YB41S | RN1692VRN1320V | PN2201 | RN1524RN1693 | FN9801PN8398 | |
| 06.12~03.14 | 2000 | J20B | YB5A | RN1320V | PN2201 | RN1524DN1372 | PN8398FN9801 |
