NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1755

ROTOR DISC » RN1755

Specification

Type

Solid

Outter Ø

278

Num. of holes

5

Disc Thickness (Max)

9

Height

43.2

Centering Diameter

62

Pitch Circle Ø

114

Front/Rear

Rear

Drum Ø:

168

Disc Thickness (Min)

8

Structure Material

G3000

Cross Reference

FIAT

71750932

FIAT

71768089

SUZUKI

55611-55L00

SUZUKI

55611-55L01

SUZUKI

55611-55L01-000

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

FIAT » Sedici

03.06~09.09

1900

D19AA

189

RN1320V

PN9803

RN1755 DN1371

FN0634 PN8398

SUZUKI » SX-4

06.06~12.15	1600	9HX	YY5	RN1320V	PN9803	RN1755	PN8398 FN0634
07.06~03.16	1600	M16A	GYA21S	RN1320V	PN2201	DN1372 RN1524 RN1755	FN9801 PN8398
06.06~12.15	1600	M16A	GYC21S SDN	RN1320V	PN2201	DN1372 RN1755 RN1524	FN9801 PN8398
06.06~12.11	1600	M16A	RW416 MAGYAR	RN1320V	PN9803	DN1371 RN1755	FN0634 PN8398
07.09~01.16	2000	D20AA	GY	RN1320V	PN9803	RN1755	FN0634 PN8398
